Observe the following before installing and using this product:
A readily accessible disconnect device shall be incorporated in the building installation wiring.
Installation and servicing should be done only by qualified service personnel and should conform to all local codes.
Use stainless steel hardware to fasten the unit to outdoor surfaces.
Connect conduit hubs to the conduit before connecting them to the enclosure.
Use only UL Listed conduit hubs rated 4X and UL Listed strain-relief bushings rated 4X.
Protect against risk of unintentional operation or damage.
Table 1. Power and fuse specifications
Power Supply
KTP-24C
KTP-24CE4
CAUTION:
Complete all instruction steps before supplying power to the unit.
I
F
NSTALLING ON A
1)
Loosen the four cover screws and remove the cover with the screws attached.
2)
Mark the location of the four mounting holes using the included mounting template.
3)
Prepare the four mounting holes in accordance with the type of mounting surface (concrete, wood, etc.) and
fasteners (not provided).
4)
Secure the unit to the wall with the appropriate fasteners.
A
C
TTACHING TO A
A
DAPTER
See Figure 1 and perform the following.
1)
Loosen the four cover screws and remove the cover with the
screws attached.
2)
Secure the power supply to the adapter with the supplied
fasteners.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
You are cautioned that any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment..
1035033D / October 2003
Power Source
115 VAC
230 VAC
V
S
LAT
ERTICAL
URFACE
-
P
-M
ORNER
OR
OLE
Technical Support: 800-469-1676
KTP-24C/KTP-24CE4 Outdoor Power Supply
Fuse F1
1.5 ASB 3 AG
0.63 ASB 5 x 20 mm
OUNT
Figure 1. Mounting the power supply to the corner- and pole-
mount adapters
Fuse F2
2.5 ASB 3 AG
2.5 ASB 5 x 20 mm
1
Advertisement
Related Manuals for GE KTP-24C
Summary of Contents for GE KTP-24C
- Page 1 KTP-24C/KTP-24CE4 Outdoor Power Supply Observe the following before installing and using this product: A readily accessible disconnect device shall be incorporated in the building installation wiring. Installation and servicing should be done only by qualified service personnel and should conform to all local codes.
- Page 2 When you replace the cover, properly align the keyed tabs and slots on the cover and housing to prevent the cover from leaking. See Figure 3. Replace the cover by aligning the keyed tabs and slots. Tighten the screws securely to ensure a watertight seal. 1035033D / October 2003 © 2003 Kalatel, a GE Interlogix company...
- Page 3 Installation Instructions KTP-24C/KTP-24CE4 Outdoor Power Supply OUNTING EMPLATE in. (6.0 cm) in. (12.0 cm) 1035033D / October 2003 Technical Support: 800-469-1676...
