G0890 Machine Data Sheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0890 15" 3 HP FIXED‐TABLE PLANER
Product Dimensions:
Weight.............................................................................................................................................................. 300 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 25 x 49 x 47-1/2 in.
Footprint (Length x Width)..................................................................................................................... 21 x 18-1/2 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 374 lbs.
Length x Width x Height....................................................................................................................... 30 x 24 x 49 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 230V, Single-Phase, 60 Hz
Full-Load Current Rating........................................................................................................................................ 12A
Minimum Circuit Size.............................................................................................................................................. 20A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length............................................................................................................................................... 10 ft.
Power Cord Gauge......................................................................................................................................... 12 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type................................................................................................................................................ 6-20
Switch Type..................................................................................... Magnetic Switch w/Thermal Overload Protection
Motors:
Main
Horsepower................................................................................................................................................ 3 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 12A
Speed................................................................................................................................................ 3450 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer ............................................................................................................................................ Belt
Bearings..................................................................................................... Shielded & Permanently Lubricated
Centrifugal Switch/Contacts Type......................................................................................................... External
Main Specifications:
Main Specifications
Planer Size................................................................................................................................................ 15 in.
Max. Cut Width.......................................................................................................................................... 15 in.
Min. Stock Length........................................................................................................................................ 6 in.
Min. Stock Thickness.............................................................................................................................. 3/16 in.
Max. Stock Thickness.................................................................................................................................. 6 in.
Number of Cuts Per Inch.......................................................................................................................... 81, 46
Number of Cuts Per Minute..................................................................................................................... 15,600
Cutterhead Speed............................................................................................................................. 5200 RPM
Planing Feed Rate........................................................................................................................... 16, 28 FPM
Max. Cut Depth Planing Full Width........................................................................................................... 1/8 in.
Max. Cut Depth Planing 6-Inch Wide Board........................................................................................... 3/16 in.
The information contained herein is deemed accurate as of 8/20/2019 and represents our most recent product specifications.
Model G0890
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
-6-
MACHINE DATA
SHEET
G0890/G0891 (Mfd. Since 06/19)
PAGE 1 OF 2
