G0890/G0891 Wiring Diagram - Grizzly G0890 Owner's Manual

G0890/G0891 Wiring Diagram

A
L1/1 L2/3 L3/5
SDE
MA-18
240V
T1/2 T2/4 T3/6
1/2 3/4 5/6
MAGNETIC SWITCH
ASSEMBLY SDE MP-18
READ ELECTRICAL SAFETY
-48-
NO13
NC21
SDE
NC22
NO14
B
RA-20
AMP
18 12
15
ARC
96 98
95
GND
ON PAGE 47!
Hot
230
VAC
Hot
G
Ground
Start Capacitor
400MFD
125VAC
Run Capacitor
70uF
250VAC
The motor wiring shown here is
current at the time of printing, but it
may not match your
Always use the wiring diagram
inside the motor junction box.
6-20 Plug
G0890/G0891 (Mfd. Since 06/19)
machine.
