KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Switch trim panel • D) Pocket • E) #8 x 3/8" Truss-head Phillips screws (4)
• F) #8 x 3/8" Pan-head Phillips screws (4) • G) #6 x 3/8" Phillips screws (4) • H) Panel clips (6)
A
B
Metra. The World's Best Kits.
®
Ford F-250/350/450/550 XL
*Visit MetraOnline.com for up-to-date vehicle specific applications.
KIT FEATURES
• ISO DIN radio provision with pocket
• Painted scratch-resistant matte black to match the
factory color and finish
C
D
G
E
MetraOnline.com
2017-up*
(w/o color screen)
E
E
F
E
H
E
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
99-5850B
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Dash Disassembly . .................................................2
Kit Preparation . ......................................................2
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: XSVI-5524-NAV
Antenna Adapter: 40-EU10
Steering wheel control interface: ASWC-1
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 9/32" socket wrench • Torx screwdriver
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
REV. 7/30/19 INST99-5850B
Advertisement
Related Manuals for Metra Electronics 99-5850B
Summary of Contents for Metra Electronics 99-5850B
- Page 1 Also, do not remove the factory radio with the key in the on position, or while the vehicle is running. Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 7/30/19 INST99-5850B...
- Page 2 1. Remove (4) Torx screws securing the climate exposed. (Figure A) control panel, then remove. (Figure A). 2. Unclip and remove the pocket, then 2. Unclip and remove the switches. (Figure A) remove (2) 9/32” screws exposed. 3. Unclip and remove the LINE IN jack. (Figure A) (Figure B) 4. Unclip and remove the power port assembly. 3. Unclip, unplug, and remove the climate- (Figure A) control/radio trim panel. To the 99-5850B climate-control/radio trim panel: Continue to Kit Preparation (Figure A) (Figure A) 5. Secure the climate control panel to the panel using (4) #6 x 3/8” Phillips screws provided. (Figure B) 6. Secure the switch trim panel to the panel using (3) #8 x 3/8” Phillips pan-head screws provided. (Figure B) 7. Snap the factory switches into the switch panel. (Figure B) 8. Snap the LINE IN jack to the panel. (Figure B)
- Page 3 KIT ASSEMBLY ISO DIN radio provision with pocket 5. Remove (4) screws in the dash cavity, then secure the completed assembly 1. Secure the pocket to the radio brackets into the dash using those screws. using the (4) #8 x 3/8” Phillips truss- (Figure C) head screws provided. (Figure A) 6. Snap the radio trim panel over the 2. Remove the metal DIN sleeve and trim completed assembly, then reassemble ring from the aftermarket radio. the dash in reverse order of disassembly 3. Slide the radio into bracket/pocket to complete the installation. assembly and secure with screws supplied with the radio. (Figure B) (Figure A) (Figure C) 4. Locate the factory wiring harness and antenna connector in the dash, and complete all necessary connections to the radio. Metra recommends using the proper mating adapter from Metra and/ or AXXESS. Test the radio for proper...
- Page 4 Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow. Metra recommends MECP certified technicians Metra. The World’s Best Kits. MetraOnline.com ® © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 7/30/19 INST99-5850B...
