HANDBOOK
PEUGEOT 108

Advertisement

Table of Contents
loading

Related Manuals for PEUGEOT 108

Summary of Contents for PEUGEOT 108

  • Page 1 HANDBOOK PEUGEOT 108...
  • Page 2 Access to the Handbook The Handbook is available on the PEUGEOT website, in the "MY PEUGEOT" section or at the following address: http://public.servicebox.peugeot.com/APddb/ Select: From the appropriate Store, download the Scan the language, MyPeugeot APP smartphone application. the vehicle, its body style, the print edition of your handbook appropriate for the date of 1 registration of your vehicle.
  • Page 3 Contributes to the protection of the environment The descriptions and illustrations are given as indications only. Automobiles PEUGEOT reserves the right to modify the technical Left-hand drive vehicle specifications, equipment and accessories without having to update this edition of the guide.

  • Page 4: Table Of Contents

    Contents Overview Access Lighting and visibility Instruments and controls Keys Lighting control stalk " Keyless Entry and Starting" system Automatic headlamp illumination Doors Direction indicators Boot Headlamp adjustment Front electric windows Wiper control stalk Eco-driving Quarter windows Changing a wiper blade Eco-driving Electric fabric roof Advice on care...
  • Page 5 Contents Audio equipment and telematics Driving In the event of a breakdown Starting/Switching off the engine with the Radio Temporary puncture repair kit Spare wheel 7-inch touch screen tablet Starting/Switching off the engine with the Changing a bulb system Keyless Entry and Starting Changing a fuse Manual parking brake 12 V battery...

  • Page 6: Instruments And Controls

    Overview Instruments and controls Door mirrors Heating, ventilation Electric windows Manual air conditioning Central locking Automatic air conditioning Front demist/defrost Rear screen demisting/defrosting Bonnet release 12 V accessory socket USB port Dashboard fuses Auxiliary Jack socket Instrument panel Manual gearbox Rev counter ETG gearbox Central display...
  • Page 7 Overview Instruments and controls (continued) Lighting controls Wiper control stalk Direction indicators Ignition, starting/switching off (key) Stop & Start Ignition, starting/switching off ("Keyless Entry and Starting" system) Active City Brake Electric mirrors adjustment Headlamp adjustment Deactivating the DSC/TRC systems. Hazard warning lamps Front foglamps (accessory) Opening the fuel filler flap ETG gearbox steering mounted control...
  • Page 8 Eco-driving Eco-driving Drive smoothly Switch off the headlamps and front foglamps when the ambient light level does not require Maintain a safe distance between vehicles, their use. Eco-driving is a range of everyday practices use engine braking rather than the that allow the motorist to optimise their fuel brake pedal, and press the accelerator Avoid running the engine before moving off,...
  • Page 9 Eco-driving Limit the causes of excess Do not forget the spare wheel and the tyres on consumption any trailer or caravan. Have your vehicle serviced regularly (engine Spread loads throughout the vehicle; place oil, oil filter, air filter, passenger compartment the heaviest items in the bottom of the boot, filter…) and observe the schedule of as close as possible to the rear seats.
  • Page 10 Instruments Instrument panels Type 2 instrument panel 6. Rev counter. The engine speed is indicated by the Type 1 instrument panel display of bright orange coloured bars. Above the maximum engine speed, the bars light up in red to indicate the need to shift up a gear.

  • Page 11: Displays

    Instruments 2. Vehicle information with: Warning lamps display for Warning lamps Total distance and trip recorders. the passenger seat belts and Trip computer information. Displayed as symbols, visual indicators the front passenger airbag which inform the driver of the occurrence Speed limiter information.

  • Page 12: Warning And Indicator Lamps

    (1 ): You must stop as soon as it is safe to do so and switch off the ignition. (2): Contact a PEUGEOT dealer or a qualified workshop. (3): Go to a PEUGEOT dealer or a qualified workshop.
  • Page 13 Brakes Fixed. The brake fluid level has dropped Top up with brake fluid approved by PEUGEOT. significantly. If the problem persists, carry out (3). The braking system is faulty. Carry out (1) then (2).
  • Page 14 Instruments Warning/indicator lamp State Cause Actions/Observations Front seat belts Flashing, The driver has not fastened or has accompanied by an unfastened his/her seat belt. audible signal. The front passenger has unfastened his/her seat belt. Airbags Fixed. One of the airbags or seat belt Carry out (3).
  • Page 15 Instruments Warning/indicator lamp State Cause Actions/Observations Orange warning/indicator lamps Anti-lock Fixed. The anti-lock braking system has The vehicle retains conventional braking. braking system a fault. Drive carefully at moderate speed, then carry out (3). (ABS) Emission Fixed. The emission control system is Quickly carry out (3).
  • Page 16 Instruments Warning/indicator lamp State Cause Actions/Observations Dynamic Fixed. With the vehicle stopped, the Press the button to activate the systems. stability control button has been pressed for more The DSC system is activated automatically when the (DSC) than 3 seconds. vehicle is started.
  • Page 17 Instruments Warning/indicator lamp State Cause Actions/Observations Stop & Start Fixed. The Stop & Start system has been Reactivate the system by pressing the button again. deactivated. Flashing. The Stop & Start system has a fault. Carry out (3). Speed limiter Fixed.
  • Page 18 Instruments Warning/indicator lamp State Cause Actions/Observations Lane Departure Flashing (orange), A lane is being crossed, left side. Turn the steering wheel in the opposite direction to Warning System accompanied by an return to the correct trajectory. audible signal. Rear foglamp Fixed.
  • Page 19 Instruments Warning/indicator lamp State Cause Actions/Observations Speed limiter Fixed. The speed limiter is active. Gear efficiency Fixed. The next higher/lower gear may be indicator engaged. Direction Direction indicators The direction indicators are on. indicators with audible signal. Sidelamps or Fixed. The sidelamps or dipped beam dipped beam headlamps are lit.

  • Page 20: Indicators

    Instruments Indicators trip recorder with TRIP displayed. Trip computer To reset the trip recorder to zero, while it is Total/trip distance recorder displayed, press one of the two buttons 1. System that gives you information on the current journey (range, fuel consumption…). Data displays Fuel level indicator When the ignition is switched on, the distance...

  • Page 21: Outside Temperature

    Instruments Outside temperature Trip reset In some situations, it may happen that the outside temperature is displayed after a delay or not at all, including: when stationary or moving at a slow speed (less than about 16 mph (25 km/h), in the case of a change that is too high (entering or leaving a garage, tunnel, etc.), during very short journeys (less than about...

  • Page 22: Adjusting The Time

    Instruments Trip computer, some Average speed The time is adjusted using the "MENU" dial: press the dial to access the menus and to definitions (mph or km/h) confirm a selection, Calculated since the last time the trip recorder turn the dial to select a function, an item in Range was reset to zero.

  • Page 23: Touch Screen

    Instruments Touch screen Adjust the day, month, year, hours and minutes using the arrows shown on the screen. Press "Configuration". Choose the format for the hours. Press "OK" to confirm and quit the menu. Press "General". Select "Date/Time".

  • Page 24: Remote Control

    Access Keys Unlocking The high frequency remote control is a sensitive system; do not operate it while These allow operation of the front door locks, it is in your pocket as there is a possibility the boot lock, the steering lock, the control that it may unlock the vehicle, without you for deactivating the passenger airbag and the being aware of it.

  • Page 25: Changing The Remote Control Battery

    Take them to a PEUGEOT dealer or to any other approved collection point. For security, the detection zones in which the electronic key is operational have a radius of about 70 cm around each opening button.
  • Page 26 Access F With the electronic key on your person and Opening the vehicle The direction indicators flash once. in the recognition zone at the rear, press the Unlocking via the doors button on the handle of the boot to unlock the vehicle and partially open the boot lid.

  • Page 27: Emergency Procedure

    Access Emergency procedure Unlocking Locking The integral key is used to lock or unlock the vehicle when the electronic key cannot operate and if there is a malfunction of the " Keyless Entry and Starting" system: key battery flat, vehicle battery discharged or disconnected, etc.
  • Page 28 To reactivate the electronic key, press one of Advice the label bearing the key code. the buttons (open or closed padlock). The PEUGEOT dealer will be able to look up the key code and the transponder code Remote control/electronic key Changing the battery of the required to order a new key.

  • Page 29: With The Remote Control

    Access To lock/unlock a door, press/pull button A. Locking/unlocking and With the remote control opening the boot Vehicles without central locking An action at button A locks/unlocks only the With the key door concerned. Vehicles with central locking An action at button A on the driver's side locks/ unlocks all the doors and the boot.

  • Page 30: Emergency Control

    Access With the " Keyless Entry and Front electric windows When closing the boot, be careful not to Starting" system slam the boot lid: guide it as it closes and (Depending on version). release it towards the end of its travel. Emergency control Measures for mechanically unlocking the boot in the event of a battery or central locking fault.

  • Page 31: Quarter Windows

    Access Quarter windows Electrically operated Depending on the level of charge of the opening and closing battery, if the roof is operated with the On the 5-door versions, device for providing ignition switched on, starting the engine ventilation to the rear seats while limiting the may cause the roof to stop moving.
  • Page 32 (engine running). F Press the control in the opening direction If the problem persists, contact a PEUGEOT and keep it pressed until the beginning dealer or a qualified workshop. An acoustic air deflector is available in order to of operation, to fully open the roof.
  • Page 33 Do not sit or place anything on the "TECHNATURE" range. To obtain this crossbar of the roof when it is open. product, visit a PEUGEOT dealer. Fabric roof To avoid damaging the roof, do not open it if there is snow or ice present.

  • Page 34: Front Seats

    Ease of use and comfort F Take your weight off the backrest. Front seats F Turn the control knob to adjust the seat backrest angle. For safety reasons, only adjust seats when the vehicle is stationary. Height of driver's seat Before moving the seat backwards, (Depending on version).
  • Page 35 Ease of use and comfort With the engine running, the front seats can be Access to rear seats Prolonged use at the highest setting is heated separately. (3-door) not recommended for those with sensitive F Press the switch. The indicator lamp comes skin.

  • Page 36: Rear Seats

    Ease of use and comfort Rear seats Folding up the backrest of Folding down the backrest of the bench seat the bench seat Your vehicle is equipped with a rear bench seat that has a fixed one-piece cushion and, Folding down is performed at the rear of the depending on version: vehicle with the boot open.
  • Page 37 Ease of use and comfort To raise the head restraint, pull it upwards. Electric door mirrors For more information on Demisting and To lower it, press the catch A then push down defrosting the rear window, refer to the the head restraint. associated section.

  • Page 38: Steering Wheel Adjustment

    2. Central vent. have it checked regularly. 3. Side vents. If the system does not produce cold air, do 4. Air outlets to the front footwells. not use it and contact a PEUGEOT dealer or a qualified workshop.

  • Page 39: Manual Air Conditioning

    Ease of use and comfort Temperature adjustment Central, side and footwell air vents. The condensation created by the air conditioning results in a discharge of water F Turn control 1 from blue (cold) to red (hot) to under the vehicle which is perfectly normal. adjust the temperature to your liking.

  • Page 40: Automatic Air Conditioning

    Ease of use and comfort 3. Air distribution adjustment. Central and side air vents. The air conditioning does not operate 4. Recirculation of interior air. when the air flow is deactivated. 5. Air conditioning On/Off. Central, side and footwell air vents. Temperature adjustment Automatic air conditioning F Turn control 1 from blue (cold) to red (hot) to...

  • Page 41: Manual Control

    Ease of use and comfort passenger compartment temperature, air flow The "AUTO" symbol disappears if you change Air flow adjustment and air distribution. a setting. F Press button 2 (filled fan or empty fan) to This system is designed to operate effectively Temperature adjustment in all seasons, with the windows and the increase or reduce the air flow.
  • Page 42 Ease of use and comfort Deactivating the system With a manual air conditioning With Stop & Start, when demisting – system defrosting has been activated, STOP F Press air flow button 2 (empty fan) until the mode is not available. F Move the manual control 4 to the left to be fan symbol disappears.

  • Page 43: Switching Off

    Ease of use and comfort With the automatic air Switching off The courtesy lamp is permanently off. conditioning system F Press this button again to switch off the The courtesy lamp is F Press the dedicated button, its indicator demisting/defrosting. The indicator lamp permanently on.

  • Page 44: Front Fittings

    Ease of use and comfort Front fittings Sun visor. Glove box 2. Glove box. 3. Radio, Touch screen or storage compartment. 4. 12 volt accessory socket (120 W max). Observe the maximum power rating to avoid damaging your accessory. 5. USB port. 6.
  • Page 45 The connection of an electrical device Connected to the USB port during not approved by PEUGEOT, such as use, the portable device may recharge a USB charger, may adversely affect the The USB port and jack socket also allow automatically.
  • Page 46 To remove the shelf: The use of mats not approved by F open the boot lid, PEUGEOT may interfere with access to F unclip the two cords, the pedals and hinder the operation of the F pull the shelf hard to release it from its speed limiter or the ETG gearbox.

  • Page 47: Boot Fittings

    Ease of use and comfort F clip the shelf into both hinges, Hooks Depending on configuration, it includes F pass the two cords through the guide hooks dedicated storage fittings for: on each side of the struts, towing eye, F clip both cords into place. temporary puncture repair kit.

  • Page 48: Lighting Control Stalk

    Contact a PEUGEOT dealer or a qualified conditions: workshop. sidelamps, to be seen, Turn the ring to align the desired symbol with dipped beam headlamps to see without the marking.
  • Page 49 Lighting and visibility With the dipped beams on, push the control Front foglamps and rear In good or rainy weather, both day and forwards to switch on the main beams. Pull the foglamp night, using the front foglamps and the control towards you to return to dipped beams.

  • Page 50: Automatic Headlamp Illumination

    Lighting and visibility Automatic headlamp Manual guide-me-home you put the lighting control in another position, illumination lighting you switch on the ignition. (Depending on version) Direction indicators When a low level of ambient light is detected by a light sensor, the sidelamps and dipped beam headlamps are switched on automatically, without any action on the part of the driver.

  • Page 51: Headlamp Adjustment

    Lighting and visibility Headlamp adjustment Wiper control stalk Single wipe. In wintry conditions, remove snow, ice or For a single wipe of the windscreen, raise the frost present on the windscreen, around control then release it. the wiper arms and blades and the Off.

  • Page 52: Changing A Wiper Blade

    Lighting and visibility Rear wiper Changing a wiper blade Removing the front wiper blade F Raise the wiper arm. F Take off the blade by sliding it to the outside. Refitting the front wiper blade Turn the ring to this position for F Put the new wiper blade in place and continuous wiping.

  • Page 53: Horn

    (risk information, skills and equipment required, of malfunctions of the vehicle's all of which a PEUGEOT dealer is able to Horn electronic systems that could cause provide. breakdowns or serious accidents).

  • Page 54: Hazard Warning Lamps

    The ESC programme incorporates the following braking. an increase in the effectiveness of the braking. systems: anti-lock braking system (ABS) and Drive carefully at a moderate speed and electronic brake force distribution (EBFD), contact a PEUGEOT dealer or a qualified workshop.
  • Page 55 You must stop as soon as it is safe to do so. for the DSC system. Contact a PEUGEOT dealer or a qualified Deactivation workshop without delay. Reactivation The TRC and DSC systems reactivate When changing wheels (tyres and rims), automatically each time the engine is started.

  • Page 56: Seat Belts

    Safety Drive carefully at a moderate speed and Seat belts Rear seat belts contact a PEUGEOT dealer or a qualified workshop for verification of the system. Front seat belts The TRC and DSC systems offer exceptional safety in normal driving, but this should not encourage the driver to take extra risks or drive at high speed.
  • Page 57 Safety Release 3. Rear right seat belt not fastened/unfastened Advice warning lamp, in the seat belt and front The driver must ensure that passengers F Press the red button on the buckle. passenger airbag warning lamps display. F Guide the seat belt as it reels in. use the seat belts correctly and that they are all fastened before setting off.

  • Page 58: Airbags

    Depending on the nature and workshop with the skills and equipment occupants. seriousness of the impact, the needed, which a PEUGEOT dealer is able In the event of a slight impact, an impact pyrotechnic system may be deployed to provide.

  • Page 59: Front Airbags

    If this warning lamp comes on in the instrument panel it indicates a malfunction of the airbags. Contact a PEUGEOT dealer or a qualified workshop as soon as possible to have the system checked. The airbags may no longer be deployed in the event of a serious impact.

  • Page 60: Curtain Airbags

    Deployment All work on the airbag system must be carried out by a PEUGEOT dealer or The curtain airbag is deployed at the same a qualified workshop. time as the corresponding lateral airbag in the...

  • Page 61: Child Seats

    PEUGEOT dealer. Do not smoke as deployment of the Do not attach anything to or hang anything airbags can cause burns or the risk of from the seat backrests (clothes, etc.) as...

  • Page 62: Deactivating The Front Passenger Airbag

    Safety Child seat at the front "Rearward facing" The warning label present on both sides of the Passenger seat adjusted to the rearmost passenger sun visor repeats this advice. longitudinal position. In line with current legislation, the following tables contain this warning in all of the When a "rearward facing"...
  • Page 63 Safety Deactivating the To ensure the safety of your child, passenger's front airbag the passenger's front airbag must be deactivated when you install a rearward facing child seat on the front passenger seat. Otherwise, the child would risk being seriously injured or killed if the airbag were deployed.
  • Page 64 Safety НИКОГА НЕ инсталирайте детско столче на седалка с АКТИВИРАНА предна ВЪЗДУШНА ВЪЗГЛАВНИЦА. Това може да причини СМЪРТ или СЕРИОЗНО НАРАНЯВАНЕ на детето. NIKDY neumisťujte dětské zádržné zařízení orientované směrem dozadu na sedadlo chráněné AKTIVOVANÝM čelním AIRBAGEM. Hrozí nebezpečí SMRTI DÍTĚTE nebo VÁŽNÉHO ZRANĚNÍ. Brug ALDRIG en bagudvendt barnestol på...
  • Page 65 Safety NEKAD NEuzstādiet uz aizmuguri vērstu bērnu sēdeklīti priekšējā pasažiera sēdvietā, kurā ir AKTIVIZĒTS priekšējais DROŠĪBAS GAISA SPILVENS. Tas var izraisīt BĒRNA NĀVI vai radīt NOPIETNUS IEVAINOJUMUS. Qatt m'ghandek thalli tifel/tifla marbut f'siggu dahru lejn l-Airbag attiva, ghaliex tista' tikkawza korriment serju jew anke mewt lit-tifel/tifla Plaats NOOIT een kinderzitje met de rug in de rijrichting op een zitplaats waarvan de AIRBAG is INGESCHAKELD.
  • Page 66 Safety Child seat at the rear Recommended child Groups 2 and 3: from 15 to 36 kg seats "Rearward facing" Range of recommended child seats which are secured using a three-point seat belt. Group 0+: from birth to 13 kg When a "rearward facing"...
  • Page 67 Safety Locations for child seats secured using the seat belt In accordance with European regulations, this table indicates the options for installing child seats secured using the seat belt and universally approved (a) in relation to the weight of the child and the seat in the vehicle. Weight of the child/indicative age Under 13 kg 9-18 kg...

  • Page 68: Isofix Mountings

    Safety Seat suitable for the installation of There are three anchorages for each seat: This ISOFIX mounting system ensures fast, a child seat secured using a seat belt reliable and safe fitting of the child seat in your and universally approved, rearward vehicle.
  • Page 69 Safety Recommended ISOFIX "RÖMER Baby-Safe Plus and its ISOFIX Baby P2C Mini and its ISOFIX base child seats base" (size categories: C, D, E) (size category: E) Also consult the user guides from the child Group 0+: from birth to 13 kg Group 0+: from birth to 13 kg seat's manufacturer to find out how to install and remove the seat.
  • Page 70 Safety "Baby P2C Midi and its ISOFIX base" "RÖMER Duo Plus ISOFIX" (size categories: D, C, A, B, B1) (size category: B1) Group 1: from 9 to 18 kg Group 1: from 9 to 18kg Installed only in the forward facing position. Installed rearward facing using an ISOFIX Is attached to rings A and ring B, referred to base which is attached to rings A.
  • Page 71 Safety Summary table of locations for ISOFIX child seats In line with European regulations, this table indicates the options for installing ISOFIX child seats on the vehicle seats fitted with ISOFIX mountings. In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A to G, is indicated on the child seat next to the ISOFIX logo.

  • Page 72: Size Child Seats

    Safety Locations for i-Size child Advice i-Size child seats seat The incorrect installation of a child seat in i-Size child seats have two latches that engage a vehicle compromises the protection of on the two rings A. Front the child in the event of an accident. 1st row Not i-Size passenger seat...

  • Page 73: Child Lock

    Safety Child lock Children at the rear Installing a booster seat At rear seating positions, always leave The chest part of the seat belt must be sufficient space between the front seat positioned on the child's shoulder without and: touching the neck. a "rearward facing"...

  • Page 74: Driving On Flooded Roads

    If in doubt on the state of your vehicle, contact neutral or position N or P, depending on an enclosed area without adequate a PEUGEOT dealer or a qualified workshop. the type of gearbox. ventilation: internal combustion engines emit toxic exhaust gases, such as carbon monoxide.

  • Page 75: Starting/Switching Off The Engine With The System Keyless Entry And Starting

    Driving F Turn the key to position 2 (ACC). Starting/Switching off the Starting the engine F Press the key in and turn it to position 1 engine with the key F Insert the key into the ignition switch. (LOCK). F Turn the key to position 2. F Remove the key from the ignition switch.

  • Page 76: Switching Off The Engine

    Driving With the electronic key inside the vehicle: each Electronic key inside the vehicle. If one of the starting conditions is not met, F Vehicle with a manual gearbox: move the press of the "START/STOP" button, without the indicator for the "Keyless Entry and action on the pedals, allows the mode of the gear lever to the neutral position and press Starting"...

  • Page 77: Electronic Immobiliser

    F Press the "START/STOP" button. The the key). engine starts. If the engine does not start, contact a PEUGEOT dealer or a qualified workshop. Electronic immobiliser Locks the engine management system after the Emergency switching off ignition is switched off and prevents the vehicle being started by force.

  • Page 78: Manual Parking Brake

    Driving Manual parking brake When the vehicle is moving, if the Only engage reverse gear when the brake remains applied or is not fully vehicle is stationary with the engine at idle. Locking released, this warning lamp lights up, accompanied by an audible signal. ETG gearbox When parking on a slope, turn your wheels against the kerb to immobilise...

  • Page 79: Display In The Instrument Panel

    Driving F With your foot on the brake, select position M. Manual mode with sequential changing of Display in the instrument panel the gears: move the selector backwards R, E or M. F Release the parking brake. and then to the left to select this mode. F Gradually release the brake pedal.

  • Page 80: Manual Mode

    Driving Automatic mode (EASY) The gear change requests are acted upon only During braking or deceleration, the gearbox if the engine speed allows. If they are rejected, changes down automatically to be in the F Select position E with the gear selector. an audible signal sounds.

  • Page 81: Gear Shift Indicator

    Contact a PEUGEOT dealer or In all cases, you must apply the parking This function cannot be deactivated. a qualified workshop.

  • Page 82: Hill Start Assist

    If a fault in the system occurs, this warning lamp comes on. Contact Hill start assist a PEUGEOT dealer or a qualified workshop to have the system checked. This system keeps your vehicle briefly On an ascending slope, with the vehicle...

  • Page 83: Stop & Start

    Driving Stop & Start It is displayed in the trip computer as soon as the engine is needed to maintain the Stop & Start acts. a comfortable temperature in the passenger The Stop & Start system puts the engine Press one of the "DISP" buttons to return to the compartment, temporarily into standby –...

  • Page 84: Speed Limit Recognition And Recommendation

    For more information on Driving advice, the instrument panel. screen (especially the maximum authorised particularly on flooded roads, refer to the speed). corresponding section. Have it checked by a PEUGEOT dealer or a qualified workshop. Deactivation/Manual Maintenance reactivation Before doing anything under the bonnet, deactivate the Stop &...
  • Page 85 Driving Display The units for the speed limits (mph or To maintain correct operation of the km/h) depend on the country you are system: regularly clean the area in front of driving in. the camera. It should be taken into account so that you The internal surface of the windscreen can observe the speed limit.

  • Page 86: Speed Limiter

    Driving when towing, Speed limiter Steering mounted control driving with a space-saver type spare wheel or snow chains fitted, System which prevents the puncture repair using the temporary repair vehicle from exceeding the speed kit, programmed by the driver. young drivers, etc. The limiter is switched on manually: this The following situations may interfere with the can be done regardless of the vehicle speed.
  • Page 87 Driving Displays on the instrument panel Switching on Pause F Press the end of the control: the limiter is started. F You can temporarily stop the speed limiter This indicator lamp lights up on the Information is grouped together in the by pulling the control towards you.

  • Page 88: Active City Brake

    Driving Temporarily exceeding the Have it checked by a PEUGEOT dealer or Never look at the laser sensor through a qualified workshop. speed setting an optical instrument (magnifying glass, microscope…) at a distance of less than F Press firmly on the accelerator pedal, The use of mats not approved by 10 centimetres: risk of eye injury.
  • Page 89 Driving Conditions of activation Operation Unless the driver de-clutches quickly enough during automatic braking, Active City Brake functions if the following Three functional stages are possible: triggering of the system may cause the conditions are met: • Pre-collision warning: if risk of a collision engine to stall.
  • Page 90 Driving Setting the thresholds for Press this button again to reactivate the system. triggering the alert This indicator lamp lights up on the instrument panel. The system is reactivated automatically at every new start using the key or the "START/ STOP"...

  • Page 91: Operating Faults

    Never let snow build up on the bonnet panel. if the vehicle is passing through a plastic or any object above the bonnet nor at Have the system checked by a PEUGEOT curtain, the front of the roof: this could enter the dealer or a qualified workshop.

  • Page 92: Lane Departure Warning System

    Driving Lane departure warning Activation Displays in the instrument panel system Display in the Comments System that detects involuntary crossing of instrument panel longitudinal markings of roads, using a camera The function is activated that recognises the continuous or broken lines. (green indicator lamp).

  • Page 93: Reversing Camera

    (orange) comes on in the instrument Never reverse while looking only at the panel. screen. Contact a PEUGEOT dealer or a qualified workshop without delay. High-pressure jet wash When washing your vehicle, do not direct the lance at the lens of the camera from Detection may be disrupted: a distance of less than 30 cm.

  • Page 94: Under-Inflation Detection

    Driving Under-inflation detection The tyre under-inflation detection system The tyre pressure specifications for your does not replace the need for vigilance on vehicle can be found on the tyre pressure the part of the driver. label. This system still requires you to check the For more information on the tyre inflation pressure (including the spare Identification markings, refer to the...
  • Page 95 Driving F If you have a compressor (for example the The system must be reset with the ignition on Before reinitialising the system, ensure (switch in the "ON" position or "ON" mode) and one provided in the temporary puncture that the pressures of the four tyres the vehicle stationary.
  • Page 96 In this case, under-inflation monitoring of the tyres is no longer assured. Have the system checked by a PEUGEOT dealer or a qualified workshop. After any work has been done on the system, the pressures of the four tyres must be checked and the system reinitialised.
  • Page 97 PEUGEOT & TOTAL A PARTNERSHIP FOR PERFORMANCE! The PEUGEOT TOTAL team knows how to push back the limits of performance to win victories in the most difficult conditions, as confirmed by the first three places achieved in 2017. To obtain these exceptional results, the PEUGEOT Sport...
  • Page 98 Practical information Fuel tank Opening the filler cap may create a noise caused by an inrush of air. This is entirely The capacity of the tank is about 35 litres. normal and results from the sealing of the fuel system. Low fuel level When the fuel in the tank reaches a low level, this warning lamp...

  • Page 99: Compatibility Of Fuels

    For more information on snow chains, movement of your vehicle. Certain fuels could damage the engine of contact a PEUGEOT dealer or a qualified F Fit the chains following the instructions your vehicle. workshop.

  • Page 100: Energy Economy Mode

    5 minutes. Use the accessories recommended by PEUGEOT to install transverse roof bars, following the manufacturer's recommendations. For more information, contact a PEUGEOT F Pull the interior release lever, located in the dealer or a qualified workshop.

  • Page 101: Engine Compartment

    If a level drops significantly, have the caught by the fan blades. corresponding system checked by a PEUGEOT dealer or a qualified workshop. Because of the presence of electrical equipment under the bonnet, it is...

  • Page 102: Engine Oil Level

    If the level is above the MAX mark (risk of or indeed very corrosive. corresponding underbonnet layout view. damage to the engine), contact a PEUGEOT F Take the dipstick by its coloured grip and dealer or a qualified workshop. pull it out completely.

  • Page 103: Brake Fluid Level

    Practical information Topping up the engine oil level Access to the tank The check and top up must only be done with the engine cold. The location of the oil filler cap is shown in the A low coolant level presents a risk of serious corresponding underbonnet layout view.

  • Page 104: Checks

    Change the oil filter each time the Its replacement should be carried out Filling with pure water is prohibited under all engine oil is changed. only by a PEUGEOT dealer or a qualified circumstances (risk of freezing, limestone workshop. deposits, etc.).

  • Page 105: Parking Brake

    Using different size wheels and tyres from those specified can affect the lifetime of tyres, Brake pads This system must be checked by a PEUGEOT wheel rotation, ground clearance and the dealer or a qualified workshop. speedometer reading and have an adverse Brake wear depends on the style effect on road holding.

  • Page 106: Temporary Puncture Repair Kit

    In the event of a breakdown F Uncoil the pipe stowed under the Temporary puncture The vehicle's electric system allows the compressor. repair kit connection of the compressor for long enough to inflate a tyre after a puncture repair. Scan the QR code on page 3 to view Composition of the kit explanatory videos.
  • Page 107 7 minutes, this indicates that the field of vision, to remind you that a wheel tyre is not repairable; contact a PEUGEOT is in temporary use. dealer or a qualified workshop for assistance.
  • Page 108 The use-by date of the fluid is marked on the bottle. pressures After use, do not discard the bottle in standard waste, take it to a PEUGEOT You can also use the compressor, dealer or an authorised waste disposal without injecting sealant, to check and, if site.

  • Page 109: Spare Wheel

    Do not drive more than 120 mph the spare wheel using the tools provided with (200 km/h) with the repaired tyre; see the vehicle. a PEUGEOT dealer or a qualified workshop to change the tyre. Access to the spare wheel and the tools...

  • Page 110: Tyre Pressures

    F With an ETG gearbox, place the gear F Remove the trim using the end of the vehicle no longer has its original jack, selector in the N position. wheelbrace. contact a PEUGEOT dealer or a qualified workshop to obtain a jack as intended by the manufacturer.
  • Page 111 In the event of a breakdown F Undo the wheel bolts using the wheelbrace 1. F Extend jack 2 until its head comes into F Lift the vehicle, until there is a sufficient contact with jacking point A or B used, space between the wheel and the ground, with contact surface A or B on the vehicle for easily putting the spare wheel (not...
  • Page 112 In the event of a breakdown Refitting the wheel Fitting a steel or "space-saver" spare wheel If your vehicle is fitted with alloy wheels, when tightening the bolts on fitting it is F Lower the vehicle again fully. normal to notice that the washers do not F Fold jack 2 and detach it.

  • Page 113: Changing A Bulb

    Front lamps pressure of the spare wheel checked by of misting on the internal surface of the a PEUGEOT dealer or a qualified workshop glass of the headlamps and rear lamps is without delay. normal; it disappears after the lamps have Have the punctured wheel repaired and been on for a few minutes.
  • Page 114 F Do not touch the bulb directly with your order. fingers, use a lint-free cloth. In case of difficulty, contact a PEUGEOT dealer It is essential only to use anti-ultraviolet or a qualified workshop. (UV) type bulbs, so as not to damage the headlamp.

  • Page 115: Led Daytime Running Lamps

    Number plate lamps (W5W) These bulbs are changed by removing the lamp For the replacement of this type of lamp, contact a PEUGEOT dealer or a qualified unit: F Open the boot. workshop. F Turn the plastic cover and remove the screw.

  • Page 116: Changing A Fuse

    In the event of a breakdown Third brake lamp (4 W5W bulbs) Direction indicator side repeaters (WY5W amber) F Unclip the plastic cover, located at the bottom of the windscreen, by pressing on both tabs. F With the boot open, unclip the plastic cover. F Push the repeater to the front or to the rear F Press on the metal tabs to disengage the and disengage it by pulling it towards you.
  • Page 117 Before installing other electrical equipment or accessories on your vehicle, Tweezers contact a PEUGEOT dealer or a qualified workshop. Before changing a fuse, it is necessary: F to identify the cause of the failure and rectify PEUGEOT will not accept responsibility for...
  • Page 118 In the event of a breakdown Fuses in the dashboard The fusebox is placed under the dashboard (driver's side). F Unclip the white plastic tab to access the fuses. When you have finished, replace the cover carefully.
  • Page 119 In the event of a breakdown Fuse N° Rating (A) Functions Reversing lamp – Fuel injection system – Audio system – VSC system Front and rear screenwash Main supply unit – Instrument panel – Display screen – Air conditioning – Heated rear window and door mirrors – Heated seats –...
  • Page 120 In the event of a breakdown Sidelamps – Number plate lamps – Rear foglamp – Front foglamps – Rear lamps – Lighting dimmer Air conditioning Air conditioning – Engine self-diagnosis – Sidelamps – License plate lamps – Rear foglamps – Front foglamps –...

  • Page 121: Engine Compartment Fuses

    In the event of a breakdown Engine compartment fuses Fuse N° Rating (A) Functions Right dipped beam headlamp Left dipped beam headlamp – Headlamp adjustment Right main beam headlamp Left main beam headlamp – Instrument panel – Display screen Air conditioning Fuel injection system –...
  • Page 122 In the event of a breakdown Fuse N° Rating (A) Functions Courtesy lamp – Boot lighting Flashing indicators – Hazard warning lamps – Instrument panel – Display screen Horn Supply units ETG gearbox Fuel injection system "Keyless Entry and Starting" system Battery Fuel injection system –...

  • Page 123: Battery

    Electric fabric roof sparks, so as to avoid the risk of explosion or fire. Left heated seat Wash your hands afterwards. This fuse must be replaced only by a PEUGEOT dealer or by a qualified workshop.
  • Page 124 The two vehicles must not be in contact special technology and specification; the with each other. involvement of a PEUGEOT dealer or Switch off all the electrical consumers a qualified workshop is essential when on both vehicles (audio system, wipers, replacing or disconnecting the battery.

  • Page 125: Towing The Vehicle

    If the battery has frozen, have it checked slave battery B or the booster. Close the windows, the electric fabric roof and by a PEUGEOT dealer or by a qualified F Connect one end of the green or black the doors before disconnecting the battery.
  • Page 126 In the event of a breakdown F With an ETG gearbox: move the selector to General recommendations position N. Observe the legislation in force in the country where you are driving. Failure to follow this instruction may cause Ensure that the weight of the towing damage to some components (braking, vehicle is higher than that of the towed transmission, etc.) and the absence of...

  • Page 127: Engines

    …B1B Model codes: …H1A …H1C …H1B SCFBD SCFBD SCFB4 P… …P1A …P1C …P1B For more information, contact a PEUGEOT …W1A …W1C …W1B dealer or a qualified workshop. Cubic capacity (cm EU standard max. power (kW) Fuel Unleaded …B1: 3-door version …H1:...

  • Page 128: Dimensions

    Technical data Dimensions (mm) These dimensions have been measured on an unladen vehicle.

  • Page 129: Identification Markings

    Technical data Identification markings 3-door 5-door A. Vehicle Identification Number (VIN) on the bodywork This number is stamped on the middle door pillar or rear door pillar, right-hand side. B. Vehicle Identification Number (VIN) in the passenger compartment Stamped on the crossmember, under the front right-hand seat.
  • Page 130 Technical data...
  • Page 131 Radio Radio As a safety measure, the driver must only carry out operations which require close attention while the vehicle is stationary. On vehicles equipped with Keyless Entry And Starting, to protect the battery, the MODE system shuts down after activation of the energy economy mode, 20 minutes after the engine has been stopped.

  • Page 132: Audio System Glossary

    Radio Audio system glossary System details Meaning/corresponding actions Add contacts Add contact. Add SD Associate key with a contact. All calls All calls. ASL Mid/Low/High/Off Adjust the sound atmosphere (medium/low/high). AUX On/Off Enable or disable the AUX mode (Auxiliary). Back Back.
  • Page 133 Radio Device address System address. Device name System name. Digital radio. Dial by number Dial a telephone number. Disconnect Disconnect your telephone. Display Setting Enable or disable automatic display of connection. Enter new passkey Enter a new password. FM AF On/Off Enable or disable FM AM mode.
  • Page 134 Radio Passkey Change password. Phonebook Directory. Radio View radio mode. Region Code Enable or disable RDS mode. Reset Reinitialise settings. Reset all Reinitialise all. Ringtone Select a ringtone. Ringtone volume Adjust the volume of the call ringtone. Searching Search. Select Select.

  • Page 135: First Steps

    Radio First steps Radio AM buttons 1 to 6: Select Audio system with Bluetooth ® a preset radio station. Audio system Radio FM buttons 1 to 5: Select a preset radio station. MODE List FM: show radio stations received. MODE Long press: store a station.

  • Page 136: Steering Mounted Controls

    Radio Radio AM buttons 1 to 6: Select Selection: Radio: scroll through the radio a preset radio station. automatic from the radio, of presets in descending order. Radio FM buttons 1 to 5: Select a lower frequency. Media: previous track. a preset radio station.

  • Page 137: Radio

    Radio Radio Alternative frequency (AF)/ The external environment (hills, buildings, tunnels, car parks, basements, etc.) may Selecting a station block reception, including in RDS tracking mode, frequency search. When the alternative frequency (AF) Press "MODE" to select the FM or This behaviour is normal in the function is activated, the system selects AM waveband.
  • Page 138 Radio Listen to TA messages DAB (Digital Audio Press a button for an extended time to store the current station Broadcasting) radio being listened to. The station name The TA (Traffic Announcement) function is displayed and an audible signal Digital radio gives priority to TA alert messages.

  • Page 139: Media

    Radio Information and advice If "DAB AF" tracking is enabled, there The system builds playlists (in temporary is a lag of a few seconds while the memory), an operation which can take The audio system reads files with the following system switches to "FM"...

  • Page 140: Telephone

    Radio The system can play audio files alternately Once connected in streaming mode, the The classifications available are those of via the Bluetooth ® system and the USB telephone is considered to be a media the portable device connected (artists/ port.
  • Page 141 Radio Activate the Bluetooth function on the Press "MENU" to display the list. Press this button to accept the call. telephone and ensure that it is "visible to all" (telephone configuration). Turn the dial to select "TEL", press Press "MENU" to display the list. to display the list.
  • Page 142 Radio List the telephone menus Press MENU, turn the dial to select Level 2 Level 3 Related actions "TEL", press to display the list and navigate in the menu using this dial. Phonebook Add contacts Add contact. Add SD Associate key with a contact. Delete call history Delete call history.

  • Page 143: Bluetooth

    Radio ® Bluetooth Bluetooth List of Bluetooth ® menus Level 2 Level 3 Related actions Press MENU, turn the dial to select Pairing Connect a Bluetooth device. "Bluetooth", press to display the list and navigate in the menu using List Phone Display list of registered phones.

  • Page 144: Settings

    Radio Settings The audio settings are different and independent for each audio source. System settings Press "MENU" to display the list of options. Turn the dial to select "Bluetooth", press to view the list of Bluetooth settings. Turn the dial to select "Pairing", press to view the list.

  • Page 145: Frequently Asked Questions

    Check in the telephone settings that it is "visible to all". The Bluetooth telephone is not compatible with You can check the compatibility of your the system telephone at www.peugeot.co.uk (services). CarPlay ® and Android Auto do not work. CarPlay ®...
  • Page 146 RDS tracking mode. The antenna is missing or has been Have the antenna checked by a PEUGEOT damaged (for example in a car wash or in an dealer. underground car park).
  • Page 147 Radio I cannot find some radio stations in the list of The station is no longer being received or its stations received. name has changed in the list. The name of the radio station changes. Instead of their names, some radio stations transmit other information (song title, for example).

  • Page 149: Inch Touch Screen Tablet

    7-inch touch screen tablet 7-inch touch screen tablet The different functions and settings described vary according to the version and configuration of your vehicle. While a telephone is connected with MirrorLink , its temperature may rise. In this event, for safety reasons, the battery of the telephone discharges.

  • Page 150: First Steps

    7-inch touch screen tablet First steps Smartphone voice commands via the system. Pressing this button activates the voice commands function. In prolonged sunshine and extremely hot conditions, the system may go into stand-by for protection (screen and sound completely off) for a period of at least 5 minutes.

  • Page 151: Steering Mounted Controls

    7-inch touch screen tablet Steering mounted controls Menus Audio source Select an audio source, a radio station, view photos or videos. Accept an incoming call. Outside of a call: press to go into the list of contacts, a second press to Change the multimedia source.

  • Page 152: Mirror Screen

    7-inch touch screen tablet Configuration Vehicle information Select the desired setting. Activate or deactivate the automatic start-up of Set parameters for sounds, Access the trip computer. CarPlay ® or Android Auto. brightness and activate or deactivate some parameters according to use. The Wi-Fi connection is only available with the MirrorLink mode.
  • Page 153 7-inch touch screen tablet Select "Steering wheel position", then select The synchronisation of the smartphone The synchronisation of the smartphone the desired position. allows users to display smartphone allows users to display smartphone For this modification to be taken into account, applications, which are compatible with applications, which are compatible with disconnect and then reconnect the smartphone.
  • Page 154 7-inch touch screen tablet option: Once the connection is established, a page The synchronisation of a personal is displayed with the applications already When connecting a smartphone smartphone allows users to display downloaded to your smartphone and to the system, it is recommended applications adapted for the smartphone's compatible with the MirrorLink technology.

  • Page 155: Radio

    7-inch touch screen tablet Press "Android Auto" to start the Select the "Station" tab then Select "FM". application in the system. select a station among the stations received. During the procedure, several Select the "Manual" tab to search Select "FM radio configuration" screen pages relating to certain for a station.

  • Page 156: Dab (Digital Audio Broadcasting) Radio

    7-inch touch screen tablet Activating/Deactivating RDS DAB (Digital Audio If the "DAB" station being listened to is not Broadcasting) radio available, the "FM" band display appears Press "Audio source" to show the on the screen. rolling display of audio sources. Digital radio Select "FM".

  • Page 157: Media

    7-inch touch screen tablet DAB/FM tracking If the "DAB" station being listened to is not The system builds playlists (in temporary available, or if "L-Band" is not enabled, memory), an operation which can take Digital radio does not cover 100% of the the sound cuts out when the quality of the from a few seconds to several minutes at country.
  • Page 158 7-inch touch screen tablet Connect the portable device using an audio/ Select "Connection" in the system. The steering mounted "MODE" button can video cable suitable for playing back files be used to go directly to the next media recorded in PAL or NTSC standard. source, available if the source is active.

  • Page 159: Telephone

    7-inch touch screen tablet To avoid any playback or display issues, it is Connect the telephone: see the "Telephone" The classifications available are those of advisable to create file names that have less section, then "Bluetooth". the portable device connected (artists/ than 20 characters and without using any Choose the profile "Connect all"...
  • Page 160 7-inch touch screen tablet Activate the Bluetooth function on the The system offers to connect the telephone: The services available depend on telephone and ensure that it is "visible to all" as "Connect all", the network, the SIM card and the (telephone configuration).

  • Page 161: Making A Call

    7-inch touch screen tablet Select "Telephone/message Press "Telephone". To obtain the complete list of the directory, configuration". the system accesses the directory of the smartphone via the Bluetooth connection, Select "Connect the telephone" depending on compatibility. to display a list of the paired Press the keypad tab.

  • Page 162: Managing Messages

    7-inch touch screen tablet Managing contacts/entries Select "Telephone/message Press this button to edit and modify configuration". the quick message text, then confirm with "OK". Select "Sound configuration". to Press "Telephone". display a list of sound sources. On receipt of a message (with the smartphone connected), a window appears on the screen, letting you "Read", "Ignore"...

  • Page 163: Configuration

    7-inch touch screen tablet Press this button to edit and modify Follow these three steps to install a system On Apple players, you must enable the the quick message text and confirm update: "Notifications" option to display the with "OK". Prepare a USB device.
  • Page 164 7-inch touch screen tablet Installing the update Customising the homepage Press "General". image The download of the update must be Check that the "Animation" option is activated. It is advisable to restrict file names to carried out with the engine running, Press "Customise startup image".

  • Page 165: Navigation

    7-inch touch screen tablet Navigation Select "Go to". In the contextual menu, press the "Go to" button. Navigation system on Select "Address or postcode". Choose your route from the list offered. 7-inch touch screen Available as an option, this on-board navigation Set the parameters for "Country"...
  • Page 166 7-inch touch screen tablet Scroll through the list using the arrows and select the desired address. "Nearby town" "Nearby destination", Enter a name on the virtual keypad using the option "Search by name". Press the button "Go to" on the left- hand side of the map.
  • Page 167 7-inch touch screen tablet To GPS coordinates Sound volume of guidance instructions Press "NAVI". Upon activation of the navigation mode or applications, the sound volume of the guidance Select "Navigation". instructions is independent of the sound volume of other system applications. Select "Go to".

  • Page 168: Frequently Asked Questions

    Check in the telephone settings that it is "visible to all". The Bluetooth telephone is not compatible with You can check the compatibility of your the system. telephone at www.peugeot.co.uk (services). CarPlay ® and Android Auto do not work. CarPlay ®...
  • Page 169 7-inch touch screen tablet USB, portable device QUESTION RESPONSE SOLUTION The waiting time after inserting a USB stick is Upon insertion of new media, the system reads Limit the number of sub-folders in the file long. a certain amount of data (directory, title, artist, structure on the memory stick.
  • Page 170 RDS tracking mode. The aerial is missing or has been damaged (for Have the aerial checked by a PEUGEOT example in a car wash or in an underground dealer. car park).
  • Page 171 7-inch touch screen tablet Settings, configuration QUESTION RESPONSE SOLUTION There is a difference in sound quality between To enable optimum listening quality, the audio Check that the audio settings are suited to the the various audio sources (radio, USB, etc.). settings (Volume, Treble, Medium, Bass) sources being listened to.
  • Page 172 Demisting, front ..........40 Air vents ............36 Changing a fuse ......114-116, 119 Demisting, rear ..........41 Anti-lock braking system (ABS) ......52 Changing a wheel ....107-108, 110-111 Demisting, rear screen ........41 Apple CarPlay connection ........4 Changing a wiper blade ........50 Dimensions ...........126 Audible warning ..........
  • Page 173 Headlamps, dipped beam ....17, 46, 112 Filter, oil ............102 Headlamps, main beam .....17, 46, 112 Filter, passenger compartment .....102 Head restraints, rear ........34 Fitting a wheel ......107-108, 110-111 Heating ..........6, 37, 40 Fittings, boot ...........45 Hill start assist ..........80 Fittings, interior ..........42 Hooks ..............45...
  • Page 174 Lighting, guide-me home ........48 Removing and fitting a fuse ....114-116, 119 Opening the bonnet ........98-99 Lighting dimmer .........18-19 Removing a wheel ....107-108, 110-111 Opening the boot ........ 23-24, 27 Loading .............6 Removing the mat ...........44 Opening the doors ........23-24 Locating your vehicle ........23...
  • Page 175 Starting the vehicle ........72-79 Warnings and indicators ......... 11 Starting using another battery ......122 Washing (advice)..........99 Station, radio ..........7, 7-8 Wheel, spare ....103, 107-108, 110-111 Steering mounted controls, audio ....6, 3 Window controls ..........28 Steering wheel, adjustment ......36 Windows, rear quarter ........29 Steering wheel adjustment ......36...
  • Page 179 Automobiles PEUGEOT declares, by application Reproduction or translation of all or part of of the provisions of the European legislation this document is prohibited without written (Directive 2000/53) relating to End of Life authorisation from Automobiles PEUGEOT. Vehicles, that it achieves the objectives set by...
  • Page 180 *18108.0040* ANG. 18108.0040 www.peugeot.com...

Table of Contents
