INTERMEZZO 1.2s

Mechanical/Packaging Parts List

Ref No.
MECHANICAL
1
2
3
4
5
6
7
8
9
PACKAGING
10
11
12
13
14
15
16
17
18
Description
GASKET, REAR
12" Woofer C.M.M.D. Shielded, DCR 7.6 ohms ±10%,
RABOS ASSEMBLY
SCREW, 8-32 x .5 BLK, MS,PPH (16)
GRILLE CUP (14)
Front BAFFLE
SCREW, 6-32 x .5 BLK, MS,PPH (12)
AMPLIFIER
GRILLE (See options below)
DÉCOR TRIM PANEL (See options below)
RABOS KIT
FOOT PAD (4)
POWER CORD (15 ft)
TOP END PAD
BOTTOM END PAD
CARTON
OWNERS MANUAL
WARRANTY CARD
SURVEY CARD
Description
Grille, Warm Platinum
Grille, Midnight Blue
Grille, Rich Burgundy
Décor Trim Panel, Black
Décor Trim Panel, Cherry
Décor Trim Panel, Maple
Part Number
335735-040
335735-050
335735-060
335739-030
335739-020
335739-010
11
Part Number
331106-001
335036-001
336202-001
900201-008
333249-003
335270-001
900301-008
(NOT FOR SALE)
335735-040
335739-030
335852-002
335459-001
336658-115
336213-001
336213-002
336504-001
336204-001
335841-001
335868-002
