- Page 1 EN User manual 26HFL5561L/27 26HFL5561V/27 32HFL5561D/27 32HFL5561L/27 32HFL5561V/27 32HFL4441D/27 32HFL4461F/27 37HFL4481F/27 37HFL5581D/27 37HFL5581L/27 37HFL5581V/27 42HFL5581L/27 42HFL5581V/27 52HFL5581L/27 52HFL5581V/27 ...
-
Page 3: Table Of Contents
Product information Safety Screen care and sterilization Environmental care Your TV Side controls and indicators The guest remote control (optional) The Philips Hospitality setup remote control (not included in box) SmartInstall Software TV setup: access setup menu Select a language Select mode of communication Select the communication protocol Use Multi RC Automatically install channels Select a virtual or physical channel ... -
Page 4: Important Safety Instructions
1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. -
Page 5: Notice
Notice 2010 Koninklijke Philips Electronics N.V. All rights reserved. © Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners. Philips reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. The material in this manual is believed adequate for the intended use of the system. If the product, or its individual modules or procedures, are used for purposes other than those specified herein, confirmation of their validity and suitability must be obtained. Philips warrants that the material itself does not infringe any United States patents. No further warranty is expressed or implied. Philips cannot be held responsible neither for any errors in the content of this document nor for any problems as a result of the content in this document. Errors reported to Philips will be adapted and published on the Philips support website as soon as possible. Pixel characteristics LCD products contain a high number of pixels and it is normal and ... -
Page 6: Important
Important Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don’t miss out. Complete and return your Product Registration Card at once, or register online at www.philips.com/welcome to ensure: • Proof of Purchase Returning the enclosed card guarantees that your date of purchase is on file, so no additional paperwork is required from you to obtain warranty service. • Product Safety Notification By registering your product you receive notification - directly from the manufacturer - in the rare case of a product recall or safety defect. • Additional Benefits of Product Ownership Product information This TV consumes minimal energy in standby mode to minimize environmental impact. The active power consumption is given on the type plate at the back of the TV. The model and serial number of your TV can be found on the TV as well as on the packaging. Safety • Risk of electric shock or fire! • Never expose the TV to rain or water. Never place liquid containers, such as vases, near the TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips Consumer Care to have the TV ... -
Page 7: Your Tv
Disposal of used batteries The batteries supplied do not contain the heavy metals mercury and cadmium. Nevertheless, in many areas batteries may not be disposed of with your household waste. Please ensure you dispose of batteries according to local regulations. Your TV Congratulations on your purchase, and welcome to Philips! Side controls and indicators POWER: Switches the product on or off. The product is not powered off completely unless it is physically unplugged. P/CH +/- : Switches to the next or previous channel. SOURCE: Selects connected devices. VOLUME +/- : Increases or decreases volume. These televisions are shipped in accordance with Energy Star settings and as such the side buttons will not function in the default settings. -
Page 8: The Guest Remote Control (Optional)
Searches forward. SMART PICTURE Launches the picture menu. SLEEP Sets a delay after which the TV switches to standby. Confirms an entry or selection. Navigation buttons Navigates menus. CH +/- Switches to the next or previous channel. Mutes or restores volume. 0-9 (Numeric buttons) Selects a channel or setting. FORMAT Selects a picture format. A/CH Toggles between the current channel and the last viewed channel. VOL +/- Increases or decreases volume. MENU Toggles the main menu on or off. SMART SOUND Launches the sound menu. (STOP)* Stops playback. (PAUSE)* Pauses play. Displays closed captions settings. SOURCE Selects connected devices. * This remote control is a unified DVD remote control, not a universal remote control, and as such these buttons are for use with Philips DVD players only,... -
Page 9: The Philips Hospitality Setup Remote Control
The Philips Hospitality setup remote control (not included in box) POWER RECALL TEXT SMART SLEEP GUEST SETUP GUIDE RESET A/CH CLOCK A / V (Standby-On) Switches the product on or off. The product is not powered off completely unless it is physically unplugged. SLEEP Sets a delay after which the TV switches to standby. SMART Launches the picture menu. 0-9 (Numeric buttons) Selects a channel or setting. CH GUIDE Displays the list of channels. A/CH Toggles between the current channel and the last viewed channel. -
Page 10: Smartinstall Software
When the security level is HIGH, you must use the Philips setup remote control to access the Philips Hospitality setup menu (see ‘Select the security level’ on page 16). To navigate through the Philips Hospitality setup menu, Press on the remote control to select a menu. Press to configure or modify the settings of the selected function. Press M on the Philips setup remote control or MENU on the guest remote control to return to the previous menu. Access the Philips Hospitality setup menu with guest remote control Switch on the TV and select a TV channel. Press 3-1-9-7-5-3 followed by Mute within 10 seconds. » The Philips Hospitality setup menu is displayed. ENGLISH > > >... -
Page 11: Select A Language
Access the Philips Hospitality setup menu with Philips setup remote control RECALL TEXT SMART GUEST SETUP SETUP RESET Switch on the TV and select a TV channel. Set the switch at the side of the remote control to SETUP. Press M to display the Philips Hospitality setup menu. » The Philips Hospitality setup menu is displayed. Select a language Enter the Philips Hospitality setup menu. Press POWER » The setup and guest menus will now be displayed in the selected language. SLEEP Note ... -
Page 12: Select Mode Of Communication
Select mode of communication Enter the Philips Hospitality setup menu. Press to select COMMUNICATION. Press to select one of the following options : • COMMUNICATION: To select the communication protocol between the TV and the external device connected to the TV. • STORE: To store the settings that are modified using the COMMUNICATION menu. • PENDANT: To enable or disable the healthcare pendant control. This is available only when you select COMMUNICATION > OFF. Select the communication protocol Enter the Philips Hospitality setup menu. Press to select COMMUNICATION > COMMUNICATION. COMMUNICATION COMMUNICATION STORE Press ... -
Page 13: Automatically Install Channels
USE CHANNEL TABLE CURRENT RING DIGITAL SETUP CONFIGURATION SMARTCLONE Note • This option is available only when you select CHANNEL INSTALL > CHANNEL > INPUT > TUNER. Select a channel ring Channels are organized in rings in Philips commercial televisions. To make the channels visible to the guest, they must be assigned to the same ring that the television is set to display as the current ring. Enter the Philips Hospitality setup menu. to select CURRENT RING. Press Press to select a list of channels to watch. Note • If you select COMMUNICATION > SMART RC, RING4 is not available ... -
Page 14: Select A Source Of Input
Select a source of input Enter the Philips Hospitality setup menu. to select CHANNEL INSTALL > INPUT. Press Press to select a source of input. Note • External inputs can also be assigned to a program number Select a logo for a channel Enter the Philips Hospitality setup menu. Press to select CHANNEL INSTALL > CHANNEL LOGO. Press to enter a page containing logos. Press to select a logo for the channel. Press “0” to save the logo and exit the menu. Map to a digital channel ... -
Page 15: Name A Channel
Press to save or remove a channel from the ring. » The ring is marked by an ‘X’ when the channel is saved in it. Press to select a category option (HIGH DEFINITION, SPORTS, NEWS, etc) to save the channel. Press to select YES to save the channel to this category or NO to remove the channel. Name a channel Enter the Philips Hospitality setup menu. Press to select CHANNEL INSTALL > LABEL. Press to select a slot to enter a character. » A flashing red mark underlines the selected slot. Press to select a character. CHANNEL INSTALL CHANNEL INPUT... -
Page 16: Enable Or Disable Emergency Alert
Enable or disable emergency alert Enter the Philips Hospitality setup menu. to select DIGITAL SETUP > EMERGENCY ALERT. Press Press to select one of the following options: • ALWAYS: To enable emergency alerts at all times. • SKIP LOW PRIORITY: To skip the emergency alerts of low priority. • SKIP MEDIUM LOW PRIORITY: To skip the emergency alerts of medium and low priorities. Note • Emergency alerts of high priority cannot be disabled for safety reasons. 11 Configure the switch-on settings Enter the Philips Hospitality setup menu. Press ... -
Page 17: Preset The Picture Format
Preset the picture format Enter the Philips Hospitality setup menu. to select CONFIGURATION > SWITCH ON / OSD > Press SWITCH ON PIC FMT. Press to select one of the available picture formats: » The selected picture format is used to display pictures when the TV is turned on. Select the switch-on channel Enter the Philips Hospitality setup menu. Press to select CONFIGURATION > SWITCH ON / OSD >... -
Page 18: 12 Configure The Security Settings
12 Configure the security settings Enter the Philips Hospitality setup menu. Press to select CONFIGURATION > SECURITY. SECURITY SECURITY KEYBOARD LOCK REMOTE CONTROL LOCK DECRYPTION CONTROL Press to select one of the following: • SECURITY: To specify the security level. • KEYBOARD LOCK: To enable or disable local TV controls. • REMOTE CONTROL LOCK: To enable or disable the guest remote control keys. • DECRYPTION CONTROL: To convert the TV from Pay-Per- View mode to standalone protected mode. Select the security level ... -
Page 19: Configure Different Settings
• MIN VOLUME: Set the minimum volume. • MAX VOLUME: Set the maximum volume. • LODGENET CARD: Select YES to allow the use of Lodgenet. Note • The SMART GUIDE will show only those programs that have been assigned to one (or more) categories. 13 Configure different settings Enter the Philips Hospitality setup menu. Press to select CONFIGURATION. CONFIGURATION SWITCH ON / OSD PICTURE / SOUND SECURITY CONTROL SMARTFEATURES AUDIO FEATURES CC / V-CHIP... - Page 20 • SMARTSECURE is a feature in the new range of commercial TVs from Philips. This feature requires a Philips Smart Gateway (PSG) as part of the installed system. The PSG must be configured to broadcast a security key. Then, when SMARTSECURE is enabled in the TV, the TV will not operate from a “cold start” unless it first “sees” this security key being broadcast. Download software from an RF channel Enter the Philips Hospitality setup menu. to select CONFIGURATION > SMARTFEATURES > Press SW DOWNLOAD. SW DOWNLOAD SOURCE DIRECTION CABLE TUNING RF CHANNEL RF TO TV Press • ...
-
Page 21: Configure The V-Chip And Closed Caption Settings
• The STANDBY FIRMWARE is rarely updated and is not included when SW TYPE > ALL is selected. To update the STANDBY FIRMWARE, the SW TYPE > STANDBY FIRMWARE must be uniquely selected. Configure the V-chip and closed caption settings Enter the Philips Hospitality setup menu. to select CONFIGURATION > CC/ V-CHIP. Press CC / V-CHIP SAVE CC DIGITAL CC MODE ANALOG CC MODE... -
Page 22: Connect Devices
RF TO TV: Press to start the download. 15 Connect devices This section describes how to connect various devices with different connectors and supplements examples provided in the Quick Start. RF TO TV Note • Different types of connectors may be used to connect a device to your TV, depending on availability and your needs. A comprehensive > interactive guide to help you connect your product is available at www. connectivityguide.philips.com. Back connectors TV ANTENNA Signal input from an antenna, cable or satellite. CVI (Y Pb Pr and AUDIO L/R) Analog audio and video input from analog or digital devices such as DVD players or game consoles. Audio input from devices that require a separate audio connection, such as a computer. RS 232 Serial Xpress communication with external connected devices. You must select [COMMUNICATION] > [SERIAL XPRESS] to use this ... -
Page 23: Side Connectors
16 Troubleshooting This section describes commonly encountered issues and accompanying solutions. TV power on/ off issues The TV does not power on: • Ensure that the TV is connected to the AC mains power outlet. If it does not power on, pull the plug out of the power outlet, wait for 60 seconds, plug it back and turn the TV on again. The TV does not switch on: • Check that the TV controls are not locked. Use Philips Hospitality setup remote control to access the Philips Hospitality setup menu and select CONFIGURATION > SECURITY > KEYBOARDLOCK > NO to unlock all TV control keys (see ‘Enable or disable the TV controls’ on page 16). • Check that the remote control is not locked. Use Philips Hospitality setup remote control to access the Philips Hospitality setup menu and select CONFIGURATION > SECURITY > REMOTE CONTROL > LOCK > YES to enable the guest remote control (see ‘Enable or disable the remote control’ on page 16). -
Page 24: No Access To Philips Hospitality Setup Menu
The TV cannot be turned off: • Check if the power mode has been set to FORCED ON. If it is, change selection to any other setting. No access to Philips Hospitality setup menu The Philips Hospitality setup mode cannot be accessed using the guest remote control: • Check that the high-security mode has been turned off. Use the Philips Hospitality setup remote control to access the Philips Hospitality setup menu and select CONFIGURATION > SECURITY > SECURITY > STANDARD to allow the use of guest remote control (see ‘Select the security level’ on page 16). - Page 27 © 2010 Koninklijke Philips Electronics N.V. All rights reserved.
