Operation

Icon Function Description
D
Flame Speed Press multiple times to toggle through flame
speeds (minimum, medium, maximum). Display
will show current speed number (F1, F2, F3
respectively).
E
Color Themes Press multiple times to change the media and
flame base colors. This feature is active only
when the flame effect is On. Display will show
theme (t0, t1, t2, etc.)
XHD28L, XHD26L or XHD23L (Log Unit) themes:
• Theme t0 - no flame
• Theme t1 - Natural (flame base off)
• Theme t2 - Red Highlights (flame base red/
• Theme t3 - Blue Highlights (flame base blue)
F
Brightness Press to change the flame and logs brightness.
Display will show b3, b1, b2 respectively.
• High
• Low
• Medium
G
Flame Press to turn the flame effect On. Press again to
turn the flame effect Off.
H
Timer Press multiple times to change the sleep timer
by 0.5 hr from 0.5 hr to 8 hr before turning off.
Press again, the remaining time on the timer
displays.
12
orange)
Operation
User Modes:
Mode Name /Discription Action (Actions cannot be input by remote control)
Press both Temp Button (
Change Celsius ( C) to
0
on the unit and hold until beep is heard and display
Fahrenheit ( F)
0
flashes. (To revert back to Celsius repeat this action)
Hold both Heat Button (
Disable / Enable Heat ( ), on the unit, for 2 seconds, when the heater has
Options been disabled the display will read "--" and beep. To
enable heat repeat this action.

Resetting the Temperature Cutout Switch

Should the heater overheat, an automatic cutout will turn the heater off. It will not
come back on without being reset.
To reset the cutout switch, unplug the unit and wait 5 minutes before plugging it
back in.
Remote Control
The maximum range of use is ~ 5 metres.
NOTE: It takes time for the receiver to respond to the transmitter.
NOTE: The reciever for the remote control is located in the display, aim the remote
control in this direction when inputting commands.
Do not press the buttons more than once within two seconds for correct operation.
Battery Information
1. To activate the remote control remove the clear battery isolation strip at the base
of the remote control, which is used to ensure your remote control reaches you fully
charged.
2. To replace the remote control battery, turn over the remote control, and follow
the diagram embossed on the remote control
) and flame speed( )
) and Temp Button
