- Page 1 Group 0+ : 0-13 KG, Universal Installation & User Manual Picaboo Grand Car Seat...
- Page 2 PICABOO GRAND Notice 1) This is a "universal " child car seat. It is approved to Regulation No. 44 ,04 series of amendments,for general use in vehicles and it will fit most,but not all,car seats. 2) A correct fit is likely if the vehicle manufacturer has declared in the vehicle handbook that the vehicle is capable of accepting a “Universal”child car seat for this age group.
- Page 3 PICABOO GRAND Warning For the child 's safety, Please read the instructions carefully below. Carelessness or improper operations may cause damage that should be avoided. 1. The instruction can be kept in the reserved place of the car seat within the usage period 2.
-
Page 4: Name Of Parts
PICABOO GRAND 2. Name of parts Handle headrest pad Strap Shoulder pad buckle buckle pad comfort pad cover shoulder straps adjuster handle adjuster adjustable straps hook Lock-off device lap belt hook lap belt hook Fixed bar PAGE 4... - Page 5 PICABOO GRAND 3. Installation location and adjustment of child seat 3.1 The right fitting position in the car right fitting wrong fitting Only suitable use in the listed vehicles fitted with lap /3 point/static /with retractor safety-belts, approved to ECE Regulation No.16 or other equivalent standards.
- Page 6 PICABOO GRAND Step 1: Loosen the shoulder straps, open the buckle Step 2: Pull out the buckle tongues from the chest pad and slots on the cover and the shell, then thread them into the corresponding belt slots. Ensure that both of the shoulder belts go through the slots at the same height, and not twisted.
- Page 7 PICABOO GRAND Pull the adjustment straps until the harness straps are totally tight. The shoulder restraint shall be adjusted as tightly as possible without causing discomfort to your child. Check whether the straps are adjusted tightly enough and not twisted when the child is sitting in the seat.
- Page 8 PICABOO GRAND The bottom two steel rods of the carrier are aligned with the four clasps of the base and pressed down. When you hear the "click", the carrier and the base are completely combined. Make sure all the belts position is right and they have not gone twisted. Also check that the cover is not impeding the movement or fit of the belt webbing in any way.
- Page 9 PICABOO GRAND Position one : Rearward facing installed in the car. This position (only this position) is suitable for the baby car seat installed on the vehicle seat. Position two : Straight up for carrying. Position three : Handle clicked back to initiate the rocking feature.
- Page 10 PICABOO GRAND Step 3. Put the diagonal belt through the guide hook behind the child seat. Step 4. Tighten the vehicle's own3-point seat belt by pulling hard on the positions showed in fig. 1 and fig. 3. Step 5. The satisfactory position of the adult safety-belt buckle car seat relative to the child restraints is as the Fig 5.
- Page 11 PICABOO GRAND 1. Release the harness, open the buckle. 2. Pull out the buckle tongues and the harness straps from the slots of the harness. 3. Take off the buckle. 4.Take off the comfort pad and headrest pad. 5. Take off the cover.
- Page 12 R for Rabbit Baby Products Pvt. Ltd. A1-305, Palladium, Corporate Road, Makarba,Ahmedabad, Gujarat - 380015 +91-79-410-57595 | www.rforrabbit.com customercare@rforrabbit.com...
