6.16 Editing Numerical values in dialogs

To edit numerical values in a dialog you can either use the Rotary
Control to increase or decrease the value or the on-screen numeric
keypad.
With the dialog displayed:
1. Select the numeric data field you want to edit so that the value
is highlighted.
2. To access the on-screen numeric keypad:
• Using touch select and hold on the current value for 5
seconds (HybridTouch displays only). Or
• Using the UniControl press and hold the Ok button for 5
seconds
The on-screen numeric keypad is displayed.
3. Enter the new value using the numeric keypad.
4. Select SAVE to save the new value.
Getting started

6.17 Basic touchscreen operations

Placing and moving the cursor using touch
This only applies to HybridTouch displays.
1. Touch the screen at any position on the screen to place the
cursor there.
Selecting the active window using touch
This only applies to HybridTouch displays.
With a page featuring multiple applications displayed:
1. Tap anywhere inside the application you want to make active.
A border appears around the application, indicating that it is
active.
Touchscreen lock
You can lock the touchscreen to prevent accidental use.
This only applies to HybridTouch displays.
For example, locking the touchscreen is particularly useful in rough
water or weather conditions.
The touchscreen is locked from the home screen. An icon in the
home screen indicates the lock status:
You must use the UniControl to unlock the touchscreen.
Locking the touchscreen
This only applies to HybridTouch displays.
With the homescreen displayed:
1. Select the Touch Lock icon.
It changes color to indicate that the touchscreen is disabled. All
functions are still available using the buttons and UniControl.
Unlocking the touchscreen
This only applies to HybridTouch displays.
With the homescreen displayed:
1. Use the UniControl to highlight the Touch Lock icon.
2. Press the OK button.
The Touchscreen is enabled.
Touchscreen is unlocked.
Touchscreen is locked. All functions remain
available using the buttons and softkeys.
