4.4 Network connections

You can connect a number of digital devices to your multifunction display using the Network connector(s) at the rear of the unit.
A typical network of digital devices may include:
• Up to 6 Raymarine multifunction displays.
• SeaTalk hs or RayNet digital devices such as a Digital Sounder Module (DSM) or radar scanner.
• Thermal camera.
Note: The display includes either 1 (e7 / e7D only) or 2 network connectors, networks requiring additional connections will require a
Raymarine network switch. This is a hub used for connecting multiple devices.
hs
Typical SeaTalk network
1
hs
SeaT alk
1. Raymarine network switch.
2. Multifunction display.
3. Digital radar scanner.
4. Thermal camera.
Network hardware
Item Part number
hs A80007
HS5 SeaTalk network
switch
SeaTalk hs network E55058
switch
SeaTalk hs crossover E55060
coupler
Cables and connections
2
/ RayNet
hs
SeaT alk / RayNet
hs
SeaT alk / RayNet
Notes
5–port switch for
network connection
of multiple SeaTalk
devices featuring
RayNet connectors.
Equipment with
SeaTalk hs connectors
can also be connected
via suitable adaptor
cables.
8–port switch for network
connection of multiple
SeaTalk hs devices.
Enables direct
connection of SeaTalk
devices to smaller
systems where a switch
is not required. Also
enables the connection
of SeaTalk hs
to an HS5 SeaTalk
network switch (in
conjunction with a
RayNet to RJ45 cable).
2
SeaT alk hs / RayNet
Network cable connector types
There are 2 types of network cable connector — SeaTalk
RayNet.
hs
Network cable types
There are 2 types of SeaTalk
"network".
hs
• Patch — for connecting the following devices to a Raymarine
network switch:
– Thermal camera via PoE injector.
– Additional Raymarine network switch.
devices
– PC or laptop using Voyager planning software.
hs
• Network — for connecting the following devices to a Raymarine
network switch:
– Digital Sounder Module (DSM) sonar.
– SR100 Sirius weather receiver.
– Additional compatible Raymarine multifunction displays.
RayNet network cables
Cable
1 m (3.28 ft) RayNet to SeaTalk
(RJ45) cable
2 m (6.56 ft) RayNet to RayNet cable
5 m (16.4 ft) RayNet to RayNet cable
3
SeaTalk hs connector — used for connecting
SeaTalk hs devices to a Raymarine network switch
via SeaTalk hs cables.
RayNet connector — used for connecting
Raymarine network switches and SeaTalk
devices to the multifunction display via RayNet
cables. Also required for connecting a crossover
coupler if only one device is being connected to
the display's Network connector.
hs network cable — "patch" and
Part number
hs A62360
A62361
A80005
4
D12251-1
hs and
hs
