Page AN-X2-ABDHRIO Remote I/O HMI Interface
The block transfer must be at the lowest address in the rack where the block transfer is
found. For example, if the rack is a quarter rack, rack 1, starting at I/O group 2 (second
quarter), any block transfers must be at rack 1, I/O group 2, slot 0.
If you are using block transfer by length mode, only one rack number can be defined in
the configuration.
The configuration file must contain a line with the keyword BtByLen before the rack and
block transfer definitions.

Sample Configuration

RioCfg, ; start of configuration
Baud, 57k6, ;define baud rate for 1771 IO network (57k6,115k2,230k4)
Rack, 0o01, 1, 4, ;define rack at octal 01, start quarter 1, end quarter 4
btr, 0o01, 0, 0, 31, 0, 64, ;define btr, rack 01, group 0, slot 0 -> N31:0,
length is 64
btw, 0o01, 0, 0, 31, 128, 64, ;define btw, rack 01, group 0, slot 0 -> N31:128,
length is 64
EndRioCfg,

Sample Block Transfer by Length Configuration

RioCfg, ; start of configuration
Baud, 57k, ;define baud rate for 1771 IO network
BtByLen, ;emulate SRIO configuration and map BT by len
Rack, 0o01, 1, 1, ;in BtByLen user can define only one rack
btr, 0o01, 0, 0, 31, 0, 1, ; each BTR definition must have a different length
btr, 0o01, 0, 0, 32, 0, 2, ; each BTR definition must have a different length
btw, 0o01, 0, 0, 33, 0, 1, ; each BTW must have a different length
btw, 0o01, 0, 0, 33, 3, 32 ; all BTs use group 0, slot 0
EndRioCfg

Downloading Configurations

To download a configuration to the AN-X-AB-RIO, start the web interface and select
Automation Network/Configure RIO to Enet/IP to download a configuration file to the
AN-X.
