Topcom Butler 2900 / Twin / Triple

2. DISPLAY

ICON: MEANING:
You are online
New numbers in call list
Rechargeable battery level indicator
The antenna indicates the quality of reception.
The antenna blinks when the handset is out of range!
Microphone is muted
Memory records are being retrieved or set up
The keypad is locked
There are more digits on the left
There are more digits on the right
During hands free
When ring buzzer is turned off
There are new messages in your voice mail
During internal call
HS-x x = handset number

3. INSTALLATION

3.1 BASE

• Plug one end of the phone cable into the phone unit and the other end into the telephone line wall socket.
• Connect the small plug of the AC adaptor to the phone and the other end of the adapter cable to the electric socket.
Topcom Butler 2900 / Twin / Triple
Telephone cord
Power cable
TEL.
SOCKET
5
