- Page 1 All manuals and user guides at all-guides.com USER'S MANUAL Model No. WETL39710.0 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, please contact us: Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu...
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 All manuals and user guides at all-guides.com 19. Never leave the treadmill unattended while it 24. Never drop or insert any object into any is running. Always remove the key, unplug opening on the treadmill. DANGER: the power cord, and press the power switch to the off position when the treadmill is not in Always unplug the power use.
-
Page 5: Before You Begin
All manuals and user guides at all-guides.com BEFORE YOU BEGIN Thank you for selecting the new WESLO CADENCE ing this manual, please see the front cover of this man- ® 16.0 treadmill. The CADENCE 16.0 treadmill offers a ual. To help us assist you, note the product model selection of features designed to make your workouts number and serial number before contacting us. -
Page 6: Assembly
All manuals and user guides at all-guides.com ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 7 All manuals and user guides at all-guides.com 2. Attach the Handrails (69) to the Uprights (73) with four M10 x 45mm Bolts (2). Start all four Bolts, and then tighten each of them. 3. With the help of a second person, hold the con- sole assembly near the Uprights (73).
- Page 8 All manuals and user guides at all-guides.com 5. Attach the Latch Housing (72) to the Left Upright (73) with two #10 x 1" Tek Screws (83); start both Screws, and then tighten each of them. 6. Identify the rod end of the Gas Spring (85). See the two small inset drawings.
-
Page 9: Operation And Adjustment
All manuals and user guides at all-guides.com OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT 2. If you are plugging in the power cord in Australia, go to step 3. Your treadmill features a walking belt coated with high- performance lubricant. IMPORTANT: Never apply sil- If you are plugging in the power cord in the UK, icone spray or other substances to the walking belt first press the pins on the power cord into the metal... - Page 10 All manuals and user guides at all-guides.com CONSOLE DIAGRAM Thumb Pulse Sensor Clip FEATURES OF THE CONSOLE IMPORTANT: If there is a sheet of plastic on the face of the console, remove the plastic. To prevent damage to the walking platform, wear clean ath- The treadmill console offers a selection of features de- letic shoes while using the treadmill.
- Page 11 All manuals and user guides at all-guides.com HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power.
- Page 12 All manuals and user guides at all-guides.com 4. Follow your progress with the displays. 5. Measure your heart rate if desired. The track—The track To measure your heart rate, stand on the foot rails and place your thumb on the pulse sensor represents a distance of (see the drawing on page 10).
- Page 13 All manuals and user guides at all-guides.com HOW TO USE A PRESET WORKOUT and the next segment of the profile will begin to flash. If a different speed setting is programmed for 1. Insert the key into the console. the next segment of the workout, the new speed setting will flash in the display to alert you.
- Page 14 All manuals and user guides at all-guides.com THE INFORMATION MODE HOW TO CHANGE THE INCLINE OF THE TREADMILL The console features an information mode that allows To vary the intensity of your exercise, you can change you to turn on and turn off the demo mode and to se- the incline of the treadmill.
-
Page 15: How To Fold And Move The Treadmill
All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before folding the treadmill, remove the key and Before moving the treadmill, fold it as described at the unplug the power cord. -
Page 16: Troubleshooting
All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 17 All manuals and user guides at all-guides.com Remove the five indicated M4.2 x 19mm Washer Head Screws (9). Then, carefully remove the Motor Hood (56). Locate the Reed Switch (42) and the Magnet (44) on the left side of the Pulley (46). Turn the Pulley until the 1/8 in.
- Page 18 All manuals and user guides at all-guides.com PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt has shifted to the left, first re- move the key and UNPLUG THE POWER CORD. Using the hex key, turn the left idler roller bolt clock- wise 1/2 of a turn.
-
Page 19: Exercise Guidelines
All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning any time. During the first few minutes of exercise, your exercise program, consult your physician. -
Page 20: Part List
All manuals and user guides at all-guides.com PART LIST—Model No. WETL39710.0 R0610A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description M10 x 65mm Bolt Walking Platform M10 x 45mm Bolt Right Foot Rail... -
Page 21: Exploded Drawing
All manuals and user guides at all-guides.com EXPLODED DRAWING A—Model No. WETL39710.0 R0610A... - Page 22 All manuals and user guides at all-guides.com EXPLODED DRAWING B—Model No. WETL39710.0 R0610A...
- Page 23 All manuals and user guides at all-guides.com EXPLODED DRAWING C—Model No. WETL39710.0 R0610A...
-
Page 24: Ordering Replacement Parts
All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to pro- vide the following information when contacting us: • the model number and the serial number of the product (see the front cover of this manual) •...
