Cornelius FCB Cord Kit Installation Instructions

INSTALLATION INSTRUCTIONS

FCB C K
ORD IT FOR
The following instructions should be used for installation of a power cord for a V-Series 4 Flavor unit.
Each kit will supply power to 1 unit.

Parts List

Item
Number
1
2

Tools Required

Phillips Screwdriver
Flat Screwdriver
Pliers
CAUTION – Only trained and certified electrical technicians should service this unit. ALL WIRING
MUST CONFORM TO NATIONAL AND LOCAL CODES.
DANGER – To avoid possible serious injury or death the ELCB (earth leakage circuit breaker) must
be installed in the electrical circuit of all units.
WARNING – To avoid possible electrical shock make sure the unit is properly grounded by con-
necting the earth ground cable, in the power cord to any connection in the machine marked with a
ground symbol.
CAUTION – The wiring must be properly grounded and connected through a disconnect switch
(slow-blow fuse or equivalent HVAC/R circuit breaker).

Electrical Requirements

Refer to the nameplate to determine the power requirements before connecting electrical power to the
unit. Voltage across contactor terminals L1 and L2, with the compressor running, must be within voltage
limits described in Table 1.
V-Series 4 Flavor Integral Condense
V-Series 4 Flavor Water Condense
If the line voltage does not meet these requirements see the possible corrective actions in Table 2.
Below 180 VAC
180-190 VAC
191-207 VAC
208-230 VAC
231-246 VAC
247-262 VAC
Above 262 VAC
Revision Date: March 24, 2014
© 2003-2014, Cornelius Inc.
FCB Cord Kit for V-Series 4 Flavor Installation Instructions
V-S 4 F
ERIES LAVOR
Description
50 Amp Power Cord
Strain Relief
Table 1
Unit
Table 2
Voltage
Do Not Connect Unit
Boost voltage by +32 V
Boost voltage by +16 V
Use line voltage
Reduce voltage by –16 V
Reduce voltage by –32 V
Do Not Connect Unit
www.cornelius.com
- 1 -
Qty
1
2
Requirements
208-230V, 60Hz, 50 Amp
208-230V, 60Hz, 50 Amp
Corrective Action
Publication Number: 629088373INS
Revision: B
