Summary of Contents for JDS Uniphase PathTrak HCU200

  • Page 1 Artisan Technology Group is your so new and certified-used/pre-owned SERVICE CENTER REPAIRS WE B • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell at our full-service, in-house repair center • TENS OF THOUSANDS OF IN-STOCK ITEMS • EQUIPMENT DEMOS View REMOTE INSPECTION Instra...
  • Page 2 JDSU PathTrak™ HCU200 Install User’s Guide...
  • Page 4 Notice The information contained in this document is the sole property of JDSU and may not be reproduced, copied, or communicated to third parties without written notice and permission by JDSU. This material will be given to direct partners and developers working with JDSU who have signed non-disclosure agreements.
  • Page 5 PathTrak™ HCU200 Install User’s Guide Rev. 000...

  • Page 6: Table Of Contents

    Table of Contents Section 1 Getting to know the HCU200 Section 2 HCU200 Unpacking and Setup Section 3 Related Information Section 4 Technical Assistance Section 5 Warnings Section 6 Equipment Ratings PathTrak™ HCU200 Install User’s Guide Rev. 000...
  • Page 7 PathTrak™ HCU200 Install User’s Guide Rev. 000...

  • Page 8: Getting To Know The Hcu200

    Section 1: Getting to know the HCU200 Section 1: Getting to know the HCU200 The front panel consists of: The power button The 4 cursor or arrow keys The "Enter" or "Accept" button The "Exit or "Cancel" button The information LCD PathTrak™...

  • Page 9: Section 2: Hcu200 Unpacking And Setup

    Section 2: HCU200 Unpacking and Setup Section 2: HCU200 Unpacking and Setup 1 Remove HCU200 from box and carefully remove all packaging material. 2 Mount HCU200 module in rack using the four holes provided on the front panel. 3 Connect grounding strap of chassis to Earth Grounding termination screws on the rear panel of the HCU200.
  • Page 10 Section 2: HCU200 Unpacking and Setup Figure 1 LCD Display Screen and Keypad Figure 2 LCD Display at Start-Up NOTE The actual IP address that appears may be different than shown below. 10 After approximately 20 seconds the LCD will display: Figure 3 IP Address of HCU200...
  • Page 11 Section 2: HCU200 Unpacking and Setup There are five different fields that may be viewed on the LCD by using either the up or down arrow keys to scroll. Three may be edited, the other two which are for infor- mational purposes only.
  • Page 12 Section 2: HCU200 Unpacking and Setup Figure 8 Physical (MAC) address of the HCU200 Ethernet adapter Figure 9 IP address of the PathTrak server that this HCU200 is connected to (This will change/ update when the HCU200 is added to a new server) CAUTION Before setting any IP address information in the HCU200,...
  • Page 13 Section 2: HCU200 Unpacking and Setup Figure 10 IP Address in Edit Mode 13 Use the up or down arrow keys to set the first number of the first IP address octet (range blank thru 2). If the first octet is less than 100, scroll until the digit is blank.
  • Page 14 Section 2: HCU200 Unpacking and Setup 17 There is no need to reboot the HCU200. Once you press the "Enter" button at the end of each field, the address is set and applied. When all the addresses are set, verify network connectivity from the Path- Trak server to the HCU200.

  • Page 15: Section 3: Related Information

    Section 3: Related Information Section 3: Related Information Use this guide in conjunction with the following informa- tion: – JDS Uniphase Corporation DSAM Product Family Series Server/Client Complete DSAM Meter Func- tionality Installation Guide (P/N 6510-30-0416) – JDS Uniphase Corporation DSAM Product Family...

  • Page 16: Section 4: Technical Assistance

    Section 4: Technical Assistance Section 4: Technical Assistance If you need assistance or have questions related to the use of this product, call or e-mail JDS Uniphase Corpo- ration’s Technical Assistance Center for customer support. Table 1 Technical assistance centers...
  • Page 17 Section 4: Technical Assistance During off-hours, you can request assistance by doing one of the following: leave a voice mail message at the Technical Assistance number in your region; e-mail North American Technical Assistance Center, tac@jdsu.com, or European Technical Assistance Center, support.uk@jdsu.com;...

  • Page 18: Section 5: Warnings

    Section 5: Warnings Section 5: Warnings The HCU200 is a Measurement Category I device for measurements on circuits and SHOULD NOT be used for measurements within measurement categories II, III and IV circuits*. WARNING If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.

  • Page 19: Section 6: Equipment Ratings

    Section 6: Equipment Ratings Section 6: Equipment Ratings Input Connection Description – 16 RF Input Ports, 75 ohm, dynamic voltage range 0-50 dBmV – 1 Serial RS232 port – 1 10/100 baseT Ethernet port – 1 USB port – 1 Trigger I/O port –...
  • Page 21 Test and Measurement Regional Sales North America Latin America Asia Pacific EMEA www.jdsu.com Toll Free: 1 800 638 2049 Tel: 954-688-5660 Tel: +852 2892 0990 Tel: +49 7121 86 2222 Tel: +1 240 404 2999 Fax:954-846-8856 Fax:+852 2892 0770 Fax:+49 7121 86 1222 Fax:+1 240 404 2195 Doc.
  • Page 22 Artisan Technology Group is your so new and certified-used/pre-owned SERVICE CENTER REPAIRS WE B • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell at our full-service, in-house repair center • TENS OF THOUSANDS OF IN-STOCK ITEMS • EQUIPMENT DEMOS View REMOTE INSPECTION Instra...
