Welcome
Congratulations on your purchase of the BOSS BR-800. This TurboStart contains
step-by-step instructions that will quickly introduce you to the BR-800's major
features.
Listening to the Demo Song
Use the following procedure to load and play back the demo song in the BR-800.
Note:
To hear the BR-800, connect headphones to the headphone output or
connect the LINE OUT L and R jacks to your mixer.
1
Press MENU.
2
Turn the dial to select "SONG."
3
Press ENTER.
4
Turn the dial to choose "SELECT."
5
Press ENTER.
6
Turn the dial to select "DemoSong."
7
Press ENTER.
8
Press PLAY.
9
Raise the MASTER fader and the TRACK MIXER faders to adjust the levels
of the tracks.
10
Press STOP when you're finished.
Recording a Song
Here's how to record a guitar track while using the built-in effects and playing
along with the BR-800's Rhythm Guide.
First, start by creating a new blank song to record into as follows.
1
Press MENU.
2
Turn the dial to select "SONG."
3
Press ENTER.
4
Turn the dial to select "NEW."
5
Press ENTER three times.
©2012 Roland Corporation U.S.
BR-800
DIGITAL RECORDER
www.BOSSUS.com
Setting Up the Guitar
1
With a standard guitar or instrument cable, connect your guitar to the
GUITAR/BASS (Hi-Z) input.
2
Press MENU.
3
Turn the dial to choose "INPUT SELECT."
4
Press ENTER.
5
Turn the dial counterclockwise to select "GUITAR/BASS."
6
Press the
button to choose "MODE."
7
Turn the dial to select "MONO REC."
8
Press EXIT twice to return to the main screen.
9
While playing the guitar, adjust the REC LEVEL knob until the INPUT 1 meter
reaches the - 6 mark on the left side of the display.
10
Press the REC button below TRACK MIXER Fader 1 so that REC lights red—
this puts the BR-80 in Record Standby mode for Track 1.
Inserting a COSM Guitar Effect on the Guitar Input
1
Press the COSM EFFECTS button so its green indicator is lit.
2
Turn the dial to choose "P40 Blues Ld."
3
Press EXIT to return to the main screen.
Adding the Rhythm Guide
1
Press the RHYTHM button so its green indicator is lit.
2
Press
to choose "TYPE."
3
Turn the dial to select "PATTERN."
4
Press
once to select "PATRN."
5
Turn the dial to select Rhythm Pattern P020 ROCK4-V1.
6
Press
twice to choose "TEMPO."
7
Turn the dial to select the desired tempo.
8
Press EXIT to return to the main screen.
9
Press PLAY to start the drum pattern.
10
Raise the RHYTHM fader to the desired listening volume.
11
Press STOP, and then press ZERO.
