SUBURBAN MANUFACTURING COMPANY
Post Office Box 399
Dayton, Tennessee 37321
SUBURBAN GAS FURNACES
IIVSTALLATION INSTRUCTIONS
FOR MODEL SF-42F
The design of the furnace has been listed for installation i n recreational vehicles only. In order for the furnace to operate in conformity
with generally accepted safety regulations, the installation instructions must be followed. Failure to comply with the installation
instructions will void the warranty on the furnace and any responsibility on the part of Suburban Manufacturing Company.
The furnacewas inspected before it left the factory. If any parts are found to be damaged, do not install the furnace. Immediately contact
the transportation company and file a claim.
r-
I
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS:
Extinguish any open flame.
Evacuate all persons from the vehicle.
Shut off the gas supply at the gas
container or source.
I
Do not touch any electrical switch, or
use any phone or radio i n the vehicle..
Do not start the vehicle's engine or
electric generator.
Contact the nearest gas supplier or
qualified service technician for repairs.
If you cannot reach a gas supplier or
qualified service technician, contact the
nearest fire department.
Do not turn on the gas supply until the
gas leak@) has been repaired.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS OR
ANY OTHER APPLIANCE.
WARNING! I m p r o p e r i n s t a l l a t i o n ,
adjustment, alteration, service o r
maintenance can cause property damage,
personal injury or loss of life. Refer to the
illstallation instructions andlor owners
manual provided with this appliance.
Installation and service m u s t be
performed by a qualified installer, service
agency or the gas supplier.
1 his hook contains instructions covering the operation and
maintenance of your furnace. Keep with unit at all times.
WARNING! Be sure the furnace and all1
Should you require further information, contact your dealer or
nearest Suburban Service Center.
ignition systems are "OFF" during any
type of refueling and while vehicle is in
1
motion or being towed.
WARNING! Installation of this appliance must be made in accordance with
the written instructions provided in this manual. No agent, representative
or employee of Suburban or other person has the authority t o change,
modify or waive any provision of the instructions contained i n this
manual.
INSTALLATION INSTRUCTIONS
CAUTION: Due to the differences i n vinyl siding, this appliance should not
be installed on vinyl siding withoutfirst consulting with the manufacturer of
the siding or cutting the siding away from the area around the appliance
vent.
CAUTION: In any installation i n which the vent of this appliance can be
covered due t o the construction of the RV or some special feature of the RV
These furnaces are designed and installed in such a manner as to be removable
S U C ~
as slide out, pop-up etc. always insure that the appliance cannot be
only from w~thin livtng area of the recreational veh~cle
operated by setting the thermostat t o the positive "OFF" position and
shutting off all electrical and gas supply to the appliance. Never operate
CAUTION: If possible, do not install the furnace to where the vent can be
furnace with vent covered.
covered or obstructed when any door on the trailer i s opened. If this is not
possible, then the travel of the door must be restricted in order to provide
NOTE These furnaces must be installed and vented as described in this manual
a 6" minimum clearance between the furnace vent and any door whenever
SO
that the negatlve pressure created by the air clrculating (return air) fan cannot
the door is opened.
affect the combustion air intake or venting of any other appliance. It is imperative
that the products of combustton be properly vented to the atmosphere and that all
The exhaust temperature of this furnace could discolor or warp some
combustion air supplted to burner be drawn from the outside atmosphere. (See
materials You should verify that the material used on the coach door, panel, or
lnstalljng Vent Assembly.)
cover wlll not d~scolor or warp from the exhaust temperature whenever any door,
panel, or cover
IS
in the open posttion
NOTE. Do not install the furnace with the vent facing toward the forward end of
the coach
Form No. 2557-C
