Suburban SH-35F Installation Instructions Manual

SUBURBANMANUFACTURINGCOMPANY
676 B r o a d w a y Street
Dayton, Tennessee 37321
a subsidiary of
A I R X C E L , ' ~ ~ ~ .
SUBURBAN GAS FURNACES
CER~FIU
INSTALLATION INS'TRUCTIONS
FOR MODELS SH-35F SH-42F
T h e de s i gn o f t he fu rn ac e h a s be en listed f or installation i n recreational vehicles only. I n o r d e r f o r t h e furnace t o operate i n c on fo rm it y
w i t h generally accepted safety regulations, the installation i n s tr u ct io n s m u s t b e followed. Failure t o c o m p l y w i t h th e installation
i ns t r u c ti o ns w i l l v o i d t h e warranty o n t h e furnace a n d a n y r e s p o n si b i l it y o n th e p a r t o f S u b u r b a n M a n u fa c tu r i n g Company.
Th e furnace w a s i n sp e c t ed before it lef t t he factory. I f any p a r ts a r e f o u n d t o b e damaged, d o n o t install th e furnace. Immediately contact
t he transportation c o m p a n y a n d file a claim.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS:
Extinguish any open flame.
Evacuate all persons from the vehicle.
Shut off the gas supply at the gas
container or source.
Do not touch anv electrical switch. or
use any phone or radio i n the vehicle.'
Do not start the vehicle's engine or
electric generator.
Contact the nearest gas supplier or
qualified service technician for repairs.
If you cannot reach a gas supplier or
qualified service technician, contact the
nearest fire department.
Do not turn o n the gas supply until the
gas leak(s) has been repaired.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS OR
ANY OTHER APPLIANCE.
WARNING! I m p r o p e r installation,
adjustment, alteration, service or
maintenance can cause property damage,
personal injury or loss of life. Refer to the
installation instructions and/or owners
manual provided with this appliance.
Installation and service m u s t be
performed b y a qualified installer, service
agency or the gas supplier.
I 1
T h i s b o o k c o n tai n s i ns t ruct i ons cov er in g t h e operation a n d
maintenance o f y o u r furnace. Keep w i t h unit a t a l l times.
IWARNING!
Be sure the furnace and all!
S h o u l d y o u require f urt her information, c on t act y o u r dealer o r
nearest S ub u rba n Service Center.
ignition systems are "OFF" during any
type of refueling and while vehicle is in
1
motion or being iowed.
INSTALLATION INSTRUCTIONS
WARNING! Installationof thisappliancemustbe madeinaccordancewith
the written instructionsprovided i n this manual. No agent. representative
or employee of Suburban or other person has the authority to change,
modify or waive any provision of the instructions contained i n this
manual.
These furnaces are designed and installed in such a manner as to be removable
only from within living area of the recreational vehicle.
CAUTION: If possible, do not install the furnace to where the vent can be
covered or obstructed when any door on the trailer is opened.lf this is not
possible, then the travel of the door must be restricted in order to provide
a 6" minimum clearance between the furnace vent andany door whenever
the door is opened.
NOTE: The exhaust temperature of this furnace could discolor or warp some
CAUTION: Due to the differences invinyl siding, this appliance should not
be installed onvinyl sidingwithoutfirst consultingwith the manufacturer of
the siding or cutting the siding away from the area around the appliance
vent
CAUTION: In any installation i n which the vent of this appliance can be
covered due to the construction of the RV or some special feature of the RV
such as slide out, pop-up etc. always insure that the appliance cannot be
operated by setting the thermostat to the positive "OFF" position and
shutting off all electrical and gas supply to the appliance. Never operate
furnace with vent covered.
NOTE: These furnaces must be installed and vented as described in this manual
so that the negative pressure created by the air circulating (return air) fan cannot
affect the combustion air intake or venting of any other appliance. It is imperative
that the products of combustion be properly vented to the atmosphere and that all
combustion air suoolied to burner be drawn from the outside atmosohere. (See
materials. You should verrfy that the material used on the coach door, panel, or
Installing Vent ~ ~ i e m b l ~ . )
cover will not discolor or warp from the exhaust temperature whenever any door.
panel, or cover is in the open pos~t~on.
NOTE: Do not install the furnace with the vent facing toward the forward end of
the coach.
Form No. 2532-C
