This User's Guide describes the characteristics, operation, and use of the
TPS65020EVM-110 evaluation module (EVM). This EVM is designed to help the user
evaluate and test the various operating modes of the TPS65020. This User's Guide
includes setup instructions for the hardware and software, a schematic diagram, a bill
of materials (BOM), and PCB layout drawings for the evaluation module.
1
2
3
4
5
1
2
3
4
5
6
1
1
Introduction
The Texas Instruments TPS65020EVM is an integrated Power Management IC for applications that are
powered with one Li-Ion or Li-Polymer cell, and require multiple power rails. The TPS65020 contains three
highly efficient switching step-down converters, two LDOs, and additional status and I/O pins. The device
is controlled via an I
1.1
Requirements
In order for this EVM to operate properly, the following components must be connected, and properly
configured.
1.2
Personal Computer (PC)
A computer with a USB port is required to operate this EVM. The TPS65020 interface software, which is
run on the PC, communicates with the EVM via the PC USB port. The user sends commands to the EVM
as well as reads the contents of the TPS65020 internal registers through the USB port.
2
I
C is a trademark of Philips Electronics.
SLVU138 - August 2005
..........................................................................................
.................................................................................................
........................................................................................
..........................................................................
.....................................................................................
............................................................................................
................................................................................
.................................................................................
.............................................................................
....................................................................................
2
C™ interface.
TPS65020EVM-110 User's Guide
...................................................................
List of Figures
...................................................................
List of Tables
User's Guide
SLVU138 - August 2005
1
2
3
8
10
4
5
6
7
8
9
10
TPS65020EVM-110 User's Guide
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments TPS65020EVM-110
Summary of Contents for Texas Instruments TPS65020EVM-110
-
Page 1: Table Of Contents
HPA110A BOM Introduction The Texas Instruments TPS65020EVM is an integrated Power Management IC for applications that are powered with one Li-Ion or Li-Polymer cell, and require multiple power rails. The TPS65020 contains three highly efficient switching step-down converters, two LDOs, and additional status and I/O pins. The device is controlled via an I C™... -
Page 2: Setup
EV2300 receives the information on the I Software Texas Instruments has provided software to assist the user in evaluating this EVM. To install the software, insert the enclosed CD into your computer. The software should start automatically. If it does not, simply go to <Start>, <Run>, and type “D:\SLVU138.exe”, and click <OK>... -
Page 3: Board Layout
5. Connect the USB cable between the computer and the EVM. 6. Turn on all supplies and loads. 7. Run the TPS65020EVM software. Board Layout This section provides the TPS65020EVM-110 board layout and illustrations. SLVU138 – August 2005 DESCRIPTION TPS65020EVM-110 User's Guide Board Layout to GPIO1. -
Page 4: Assembly Layer
Board layout is critical for all switch mode power supplies. layout for the TPS65020EVM-110 PWB. The nodes with high switching frequencies and currents are short and are isolated from the noise sensitive feedback circuitry. Careful attention has been given to the routing of high frequency current loops. -
Page 5: Top Layer
Board Layout Figure 2. Top Layer SLVU138 – August 2005 TPS65020EVM-110 User's Guide... -
Page 6: Routing, Gnd Plane
Board Layout Figure 3. Routing, GND Plane TPS65020EVM-110 User's Guide SLVU138 – August 2005... -
Page 7: Routing, Vin Plane
Board Layout Figure 4. Routing, VIN Plane SLVU138 – August 2005 TPS65020EVM-110 User's Guide... -
Page 8: Schematic And Bill Of Materials
Schematic and Bill of Materials Schematic and Bill of Materials This section provides the TPS65020EVM-110 schematic and bill of materials. TPS65020EVM-110 User's Guide Figure 5. Routing, Bottom Layer www.ti.com SLVU138 – August 2005... -
Page 9: Tps65020Evm-110 Schematic
Schematic and Bill of Materials Schematic Figure 6. TPS65020EVM-110 Schematic SLVU138 – August 2005 TPS65020EVM-110 User's Guide... -
Page 10: Related Documentation
