  • Page 1 Notebook English EasyGuide AMILO Li Series...
  • Page 2 Are there..any technical problems or other questions that you need help with? Please contact: • our Hotline/Help Desk (see the enclosed Help Desk List or the Internet: "www.fujitsu-siemens.com/helpdesk)" • Your sales partner • Your sales office Additional information is contained in the Help Desk list and the "Warranty" manual. The "Warranty"...
  • Page 4 This manual was produced by Xerox Global Services Published by Fujitsu Siemens Computers GmbH AG 10/06 Edition 1 Order No.: 10600771542 Order No.: 440 N00183...
  • Page 5 AMILO Li Series EasyGuide Innovative technology... Ports and operating elements Important notes Using your notebook for the first time Working with the notebook Security functions Connecting external devices Removing and installing components during servicing Settings in BIOS Setup Utility Troubleshooting and tips Technical data Manufacturer’s notes...
  • Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright © Fujitsu Siemens Computers GmbH 2006 All rights, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole, are reserved.

  • Page 7: Table Of Contents

    Contents Contents Innovative technology..............Are you missing information? .
  • Page 8 Contents Adjusting the volume ..............34 Integrated 56k modem .
  • Page 9 Contents Power adapter, 65W ..............62 Manufacturer’s notes .
  • Page 10 Contents 10600771542, edition 1...

  • Page 11: Innovative Technology

    Innovative technology... Innovative technology... and ergonomic design make your AMILO a reliable and user-friendly notebook. Your notebook is available in several different versions. Most of the sections in this manual apply to all models – any differences are indicated separately. Some of the illustrations and features in this manual may differ from your model and are for guidance only.

  • Page 12: Are You Missing Information

    Innovative technology... Are you missing information? An overview with further information about your notebook can be found in "Information sources", Page Notational conventions Pay particular attention to text marked with this symbol. Failure to observe this warning may endanger your health, cause the equipment to malfunction or lead to loss of data.

  • Page 13: Ports And Operating Elements

    Ports and operating elements Ports and operating elements Ports and operating elements Modem port LCD screen Monitor port Built-in loudspeakers Loudspeaker port Wireless LAN Kensington Lock LAN port USB port ExpressCard slot Battery Battery release SIM card Hard disk Touchpad buttons Touchpad scroll bar Touchpad Notebook...

  • Page 14: Important Notes

    Important notes Important notes Important notes Notes Here you will find essential safety information regarding your notebook. The other notes provide helpful information on your notebook. Safety information Safety information Notes Please note the safety information provided in the "Safety" manual and in the safety notes below.

  • Page 15: Information Sources

    Important notes Information sources Information sources Detailed instructions and technical information for your notebook are provided in this manual. The manuals are only available as PDF files. You can print out the manuals if you connect a printer to your notebook. Information source Type of information Where?

  • Page 16: Travelling With Your Notebook

    Important notes Travelling with your notebook Mobile operation Notes Transport Notebook Please observe the points listed below when travelling with your notebook. Before you travel ► Back up important data stored on your hard disk. Notebook Travel, notebook ► Switch off the radio component for data security reasons. With data traffic via a wireless connection, it is also possible for unauthorised third parties to receive data.

  • Page 17: Cleaning The Notebook

    Important notes Cleaning the Notebook Do not clean any interior parts yourself; leave this job to a service technician. Only use cleaning products designed for computers. Normal household cleaners and polishes can damage the markings on the keyboard and the device, the paintwork or the notebook itself.

  • Page 18: Using Your Notebook For The First Time

    Using your notebook for the first time Using your notebook for the first time Please read the chapter entitled "Important notes", Page Getting started Notebook Getting started Notebook Before you can use your notebook for the first time you need to charge the battery and install the supplied software.

  • Page 19: Selecting The Location

    Using your notebook for the first time Selecting the location Location, selecting the Notebook Power adapter Select a suitable location for the notebook before setting it up. Consider the following points when selecting a location: • Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture, bed).

  • Page 20: Switching The Notebook On For The First Time

    Using your notebook for the first time Switching the notebook on for the first time Switching on for the first time When you switch your notebook on for the first time, the supplied software is installed and configured. Due to the fact that this installation procedure must not be interrupted, you should set aside enough time for it to be fully completed and connect the notebook to the mains outlet using the mains adapter.

  • Page 21: Working With The Notebook

    Working with the notebook Working with the notebook Notebook, operation Notebook This chapter describes the basics for operating your notebook. Please refer to "Connecting external devices", Page 42 for instructions on how to connect external devices such as a mouse and a printer to the notebook. Please refer to the notes in the chapter "Important notes", Page Switching on the notebook...

  • Page 22: Switching Off The Notebook

    Working with the notebook Switching off the notebook ► Shut down the operating system properly (e.g. in Windows XP by clicking Start then Turn off Computer). Notebook ► If the notebook is not switched off automatically, press the ON/OFF switch (1) for approx.

  • Page 23: Status Indicators

    Working with the notebook Status indicators Status indicators The status indicators provide information about the status of the power supply, the drives and the keyboard functions. Three indicators are also visible with the notebook closed: power-on indicator, wireless LAN indicator, battery indicator Power-on indicator Caps Lock indicator Wireless LAN indicator...

  • Page 24: Keyboard

    Working with the notebook Power-on indicator Standby indicator Power-on indicator • Indicator lights up: The notebook is switched on. • Indicator flashes: The notebook is in standby mode. • Indicator is off: The notebook is switched off. Wireless LAN indicator •...
  • Page 25 Working with the notebook The figure below shows how to access the different characters on keys with overlaid functions. The example applies when the Caps Lock indicator is not lit. Alt Gr Illustration (general example showing a German keyboard layout) Backspace key The Backspace key deletes the character to the left of the cursor.
  • Page 26 Working with the notebook Fn button key enables the special functions indicated on overlay keys (see "Key combinations", Page 17). The keyboard of your notebook has a separate numeric keypad on the right-hand side. Illustration (example of German keyboard layout) If the external keyboard does not feature a key, you can simultaneously press the...

  • Page 27: Virtual Numeric Keypad

    Working with the notebook Virtual numeric keypad Numerical keypad Virtual numeric keypad Num Lock The keyboard on your notebook does not have a separate numeric keypad. To provide the convenience of a numeric keypad your keyboard is equipped with a virtual numeric keypad. The special keys for the virtual numeric keypad are recognisable by the numbers and symbols printed in the upper right corner of each key.
  • Page 28 Working with the notebook Switching suspend mode on/off Use this key combination to switch suspend mode on/off. Fn+F1 Suspend mode Suspend mode Switching loudspeakers on/off This key combination switches your notebook’s loudspeakers off and on. Fn+F3 Loudspeakers Loudspeakers Switching between screen outputs If an external monitor is connected, the monitor on which the output is to be displayed can be selected with this key combination.

  • Page 29: Country And Keyboard Settings

    Working with the notebook Carrying out a warm restart This key combination triggers a reset and reboots the notebook. Ctrl SysRq First hold down the keys and then press the Ctrl key. First the Task Manager is displayed. Then you must press all three keys again to reboot.

  • Page 30: Touchpad And Touchpad Buttons

    Working with the notebook Touchpad and touchpad buttons Keep the touchpad clean. Protect it from dirt, liquids, and grease. Touchpad Touchpad Do not use the touchpad if your fingers are dirty. Do not rest heavy objects (e.g. books) on the touchpad or the touchpad buttons. 1 = Touchpad 2 = Touchpad buttons 3 = Touchpad scroll bar...
  • Page 31 Working with the notebook Dragging an object ► Select the desired object. Touchpad ► Press and hold the left button and drag the object to the desired position with the finger on the touchpad. The item is moved. Scrolling with the touchpad scroll bar ►...

  • Page 32: Lcd Screen

    LCD screen Notes High-quality TFT displays are installed in notebooks from Fujitsu Siemens Computers GmbH. For technical reasons, TFT monitors are manufactured for a specific resolution. An optimal, clear picture can only be ensured in the resolution intended for the particular TFT monitor. A monitor resolution which differs from the specification can result in an unclear picture.

  • Page 33: Monitor Settings

    Working with the notebook Monitor settings Setting the desktop area Optimised screen resolution settings for the LCD screen on your notebook are set at the factory. Changing the font size Changing the font size LCD screen Under Start – Control Panel – Appearance and Themes – Display – Settings you can choose between a larger and a smaller font in the Font size field.

  • Page 34: Charging, Caring For And Maintaining The Battery

    Working with the notebook Charging, caring for and maintaining the battery Battery Battery The notebook battery can only be charged, when the ambient temperature is between 5°C and max. 35°C. You can charge the battery by connecting the notebook to the power adapter (see "Connecting the power adapter", Page You can maintain long life from your battery by allowing it to discharge fully before you recharge...

  • Page 35: Removing And Installing The Battery

    Working with the notebook Removing and installing the battery Only use batteries approved by Fujitsu Siemens Computers for your notebook. Never use force when inserting or removing a battery. Make sure that no foreign bodies get into the battery connections.

  • Page 36: Using The Power-Management Features

    Working with the notebook Using the power-management features Energy Energy Battery The notebook uses less energy when the available energy saving functions are used. You will then be able to work longer when using the battery before having to recharge it. You can also use energy saving modes such as Standby or Hibernate for times when you are not using your notebook but want to keep coming back to it.

  • Page 37: Inserting The Expresscard

    Working with the notebook Inserting the ExpressCard ► Pull the placeholder for the ExpressCard out of the slot. ExpressCard Keep the placeholder for the ExpressCard in a safe place. If you remove the ExpressCard, you should reinsert the placeholder into the slot. This prevents foreign objects from entering the ExpressCard slot.

  • Page 38: Expresscard Removal

    Working with the notebook ExpressCard removal ExpressCard You can stop the ExpressCard using the icon in the task bar: ► Left-click on the icon. ► Select the ExpressCard you want to stop and remove. ► Press the Enter key. Wait for the dialogue box that tells you that it is now safe to remove the ExpressCard. ►...

  • Page 39: Cd/Dvd

    Working with the notebook CD/DVD CD/DVD data storage media (certain devices only) Data storage media CD/DVD CD/DVD drives can either only read or both read and write different CDs or DVDs. The meaning of the respective CD and DVD types is described in the following: CD-ROM CD-ROM Abbreviation for Compact Disc –...

  • Page 40: Handling Cd/Dvds

    Working with the notebook DVD+R DL / DVD-R DL (Double Layer) DVD+R DL / DVD-R DL Abbreviation for Digital Versatile Disc Recordable Double Layer or Digital Video Disc Recordable Double Layer. A DVD+R DL or a DVD-R DL is an optical data storage medium that can only be written once with a maximum of 8.5 GBytes of data.

  • Page 41: Cd/Dvd Drives (Device-Dependent)

    Working with the notebook CD/DVD drives (device-dependent) Your notebook is supplied with a CD/DVD drive. Depending on the variant, your notebook will be equipped with either a dual DVD±RW drive or a multi format DVD drive with double layer support. Please ask your local computer store for assistance if you are not sure which CD or DVD type best suits your needs, e.g.

  • Page 42: Inserting Or Removing A Cd/Dvd

    Working with the notebook Inserting or removing a CD/DVD CD/DVD CD/DVD The notebook must be switched on. ► Push the insert/eject button (1). The drive tray will open. ► Gently pull the drive tray (2) completely out. ► Place the CD/DVD in the drive tray with the label facing upwards.

  • Page 43: Regional Codes For Dvd Films And Dvd Players

    Working with the notebook Regional codes for DVD films and DVD players DVD film Regional codes DVD films and DVD players (e.g. the DVD drive of your notebook) are always provided with a regional code. The regional codes of DVD films and DVD players must match so that the DVD film can be played back.

  • Page 44: Loudspeakers

    Working with the notebook Loudspeakers 1 = Built-in loudspeakers Loudspeakers Two stereo loudspeakers are installed in your notebook. The built-in loudspeakers will be disabled if headphones or external loudspeakers are connected. Adjusting the volume ► Set the desired volume with the key combination Volume ►...

  • Page 45: Integrated 56K Modem

    Working with the notebook Integrated 56k modem 56k modem Modem The integrated 56k modem supports all data communication applications, such as: • Modem operation: High-speed downloads at up to 56,000 bit/s (V.9x). Down- ward-compatible to V.34 modems. • Fax operation: Transmitting and receiving at up to 14,400 bit/s •...

  • Page 46: Radio Componenets (Wireless Lan)

    Working with the notebook Radio componenets (Wireless LAN) The installation of a wireless LAN module not approved by Fujitsu Siemens Computers GmbH will invalidate the permits (CE!) issued for this device. Wireless LAN Wireless LAN is integrated in your notebook. Switching the wireless LAN module on and off Check whether the wireless LAN module is activated/deactivated in the installed wireless LAN software.

  • Page 47: Ethernet And Lan

    Working with the notebook Ethernet and LAN Ethernet LAN The internal LAN module of your notebook supports Ethernet-LAN (10/100 Mbps). With the LAN module you can establish a connection to a local network (LAN = Local Area Network). ► Connect the LAN cable to the notebook’s LAN connector (1).

  • Page 48: Security Functions

    Security functions Security functions Security functions Your notebook has several security features that you can use to secure your system from unauthorised access. This chapter will explain how to use each function, and what the benefits are. Please remember that in some cases, for example, forgetting your password, you can be locked out and unable to access your data.

  • Page 49: Configuring Password Protection In The Bios Setup Utility

    Security functions Configuring password protection in the BIOS Setup Utility Please note the following advice before using the various options for password protection in the BIOS Setup Utility to increase data security: • Make a note of the passwords and keep them in a safe place. If you forget your supervisor password you will not be able to access your notebook.
  • Page 50 Security functions Setting supervisor and user passwords ► Start the BIOS Setup Utility and go to the Security menu. ► Select the Set Supervisor Password field and press the Enter key. Type in a password when presented with the Enter new Password prompt. ►...

  • Page 51: Password Protection Of Operating System

    Security functions Password protection of operating system The supervisor password that you have set in the BIOS Setup Utility (see "Setting supervisor and user passwords", Page 40 section) can also be used to prevent booting of the operating system. Operating system Activating system protection ►...

  • Page 52: Connecting External Devices

    Connecting external devices Connecting external devices Always refer to the safety information provided in "Important notes", Page 4 before connecting or disconnecting any devices to or from your notebook. Always read the documentation supplied with the device you wish to connect. Never connect or disconnect cables during a thunderstorm.

  • Page 53: Ports

    Connecting external devices Ports 1 = USB ports 5 = Headphones/SPDIF port 2 = LAN port 6 = Microphone connection/Line In 3 = Monitor port 7 = Modem port 4 = Kensington Lock 10600771542, edition 1...

  • Page 54: Connecting An External Monitor

    Connecting external devices Connecting an external monitor An external monitor can be connected to the notebook. Monitor VGA connector Display port Monitor port ► Switch off the notebook and the external monitor. ► Connect the data cable for the external monitor to the monitor port on the notebook.

  • Page 55: Connecting Usb Devices

    Connecting external devices Connecting USB devices USB ports On the USB ports you can connect external devices that also have a USB port (e.g. a printer, a scanner or a modem). USB devices are hot-pluggable. This means you can connect and disconnect devices while your operating system is running.

  • Page 56: Connecting External Audio Devices

    Connecting external devices Connecting external audio devices Microphone connection/Line In Connecting audio devices Audio ports Connecting a microphone The microphone/line in connection allows you to connect an external microphone, a MiniDisc player, an MP3 player, a CD player or a tape deck to your notebook. ►...

  • Page 57: Headphones/Spdif Port

    Connecting external devices Headphones/SPDIF port Connecting audio devices Audio ports Connecting headphones You can use the Headphones/SPDIF port to connect headphones, external loudspeakers or an audio device with a digital optical input to your notebook. ► Connect the data cable to the external device.

  • Page 58: Removing And Installing Components During Servicing

    Removing and installing components during servicing Removing and installing components during servicing Only qualified technicians should repair your notebook. Unauthorised opening or incorrect repair may greatly endanger the user (electric shock, fire risk) and will invalidate your warranty. Servicing Components You may remove and install the components described in this chapter yourself after consulting the Hotline/Help Desk.

  • Page 59: Removing And Installing The Hard Disk

    Removing and installing components during servicing Removing and installing the hard disk Hard disk removal ► Switch the notebook off and pull the power plug out of the mains socket. ► Close the LCD screen so that it locks into place. ►...

  • Page 60: Hard Disk Installation

    Removing and installing components during servicing Hard disk installation When installing the hard disk ensure that the contacts in the hard disk compartment do not bend or become damaged. Please observe the notes in the operating instructions for the hard disk. Hard disk ►...

  • Page 61: Removing The Cover

    Page The second memory module is not accessible from the outside and must therefore only be removed or replaced by an authorised Fujitsu Siemens Computers service partner. ► Switch your notebook off. ► Close the LCD screen so that it locks into place.

  • Page 62: Removing Memory Modules

    Removing and installing components during servicing Removing memory modules ► Carefully push the two mounting clips outwards (1). Memory expansion Memory modules The memory module will snap upwards (2). ► Pull the memory module out of its slot in the direction of the arrow (3). Installing memory modules ►...

  • Page 63: Settings In Bios Setup Utility

    Settings in BIOS Setup Utility Settings in BIOS Setup Utility BIOS Setup Utility System settings, BIOS Setup Utility Configuration, BIOS Setup Utility Setup System configuration Hardware configuration The BIOS Setup Utility allows you to set system functions and the hardware configuration of your notebook.

  • Page 64: Exiting The Bios Setup Utility

    Settings in BIOS Setup Utility Exiting the BIOS Setup Utility BIOS-Setup-Utility Select the desired option in the Exit menu and activate by pressing the Enter key: Save Changes and Exit – Save settings and exit the BIOS Setup Utility ► Select Save Changes and Exit followed by Yes to save the current settings and exit the BIOS Setup Utility.

  • Page 65: Troubleshooting And Tips

    PC if you are running processor-intensive gaming software, e.g. games with intensive 3D graphics. Updating your hardware with drivers which have not been approved by Fujitsu Siemens Computers may result in performance losses, data losses or malfunction of the equipment. A list of approved drivers and current BIOS versions can be downloaded from: "http://www.fujitsu-siemens.de/support/downloads.html"...

  • Page 66: Restoring The Operating System, Drivers, Manuals And Special Software

    Troubleshooting and tips Restoring the operating system, drivers, manuals and special software You can find information on how to restore the operating system, drivers, manuals and special software in the "Recovery Process" manual. The notebook’s date or time is incorrect Summer time Time, daylight savings Time not correct...

  • Page 67: The External Monitor Remains Blank

    Troubleshooting and tips The external monitor remains blank Screen Cause Troubleshooting Monitor is switched off. ► Switch the external monitor on. Power saving has been activated (monitor is ► Press any key to continue. blank). Brightness is set to ’dark’. ►...

  • Page 68: The Notebook Stops Working

    Troubleshooting and tips The notebook stops working Notebook Disabling Standby mode Suspend mode Cause Troubleshooting The notebook is in Standby or Suspend mode. ► Disable Standby mode (press a key) or Suspend mode (switch notebook on). An application programme has caused the ►...

  • Page 69: Dvd Film Playback Stops

    Troubleshooting and tips DVD film playback stops DVD film does not continue to play Cause Troubleshooting Accelerated hardware decryption If the picture freezes when playing certain DVD films, activated. deactivate the accelerated hardware decryption (it is activated by default; which is indicated by the tick in the corresponding checkbox).

  • Page 70: The Printer Does Not Print

    Troubleshooting and tips The printer does not print Printer does not print Cause Troubleshooting The printer is not switched on. ► Make sure that the printer is switched on and is online (see the manuals supplied with the printer). The printer is not connected correctly. ►...

  • Page 71: Technical Data

    Technical data Technical data Technical data To find the correct technical data for your device please refer to the device information plate. The device information plate is located on the underside of the device. Type designation (e.g. AMILO Li 1820) 10600771542, edition 1...

  • Page 72: Notebook

    Technical data Notebook Technical data Environmental conditions Environmental class Temperature Operating (3K2) 5 °C – 35 °C Transport (2K2) 15 °C – 60 °C Dimensions Width x Depth x Height (front/back) 408 mm x 289 mm x 31.4/38.9 mm Weight (depending on configuration) approx.

  • Page 73: Manufacturer's Notes

    Declaration of conformity You will find the Declarations of Conformity for the AMILO on the Internet at: "www.fujitsu-siemens.com". Hereby, Fujitsu Siemens Computers, declares that the AMILO is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Copyright-protected technology...

  • Page 74: Ce Marking

    Manufacturer’s notes CE marking CE marking CE marking for devices without wireless component The shipped version of this device complies with the requirements of the EEC directives 89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage directive". CE marking for devices with radio component This equipment complies with the requirements of Directive 1999/5/EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and mutual recognition of conformity.

  • Page 75: Index

    Index Index 56k modem 35 emergency removal 32 handling 30 inserting 32 overview 29 A beep sounds every second 56 removing 32 Alt+Tab 18 CD/DVD drive 3 Anti-theft protection 38 AutoPlay function 33 Audio ports 46–47 CD-R 29 AutoPlay function 33 CD-ROM 29 CD-RW 29 CE marking 64...
  • Page 76 Index DVD film removal 49 regional codes 33 Hardware configuration 53 DVD film does not continue to play 59 HD DVD-R 30 DVD video 29 Headphone port 3 DVD+R 29 DVD-R 29 DVD+R DL / DVD-R DL 30 Important notes 4 DVD-R LF 30 Incorrect date/time 56 DVD-ROM 29...
  • Page 77 Index Memory module see virtual numeric keypad 17 important notes 50 Memory modules installation 52 ON/OFF switch removal 52 Notebook 3 Memory removal Operating system see Memory expansion 50 activating system protection 41 Menu key 16 cancelling system protection 41 Microphone port 3 protecting with password 41 Mobile operation 6...
  • Page 78 Index Silent Mode, Easy Launch key 14, 19 dragging items 21 SIM card 3 executing a command 20 Slot moving the pointer 20 ExpressCard 26 selecting an object 20 SPDIF port 3 Touchpad buttons 3 Standby indicator 14 Touchpad scroll bar 3 Start key 16 Transport 6 Status indicators 13...
