- Page 1 WIRELESS HOME SECURITY SYSTEM OWNER’S MANUAL INSTALLATION AND OPERATION BEFORE INSTALLING OR OPERATING THE SYSTEM, PLEASE READ THIS MANUAL, MODEL: Table of Contents SY4100...
-
Page 2: Table Of Contents
Table of Contents Introduction…………………………………………………………………………….…... System Package…………………………………………………………….…. Optional Accessories…………………………………………………………... Planning for Installation Choosing a Location………………………………………………………..…... Setting Alarm Zones…………………………………………………………... Installing the Back-up Battery………………………………………………... Powering the Main Console……………………………………………………. Connecting the Telephone Line……………………………………………...… Setting the Antenna………………………………………………………….…. Mounting the Main Console…………………………………………………..… About Passw ords…..…………………………………………………………... Others………………………………………………………………………….…. Operation –... -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE OR POWER ADAPTER TO WATER OR MOISTURE Read Instructions – All the safety and operating instructions should be read before operating this equipment. These instructions should be retained for future reference Heed Warnings –... -
Page 4: Introduction
Thank you for choosing the Sylvania® SY4100 Wireless Home Security System. These security systems are high-quality, reliable and versatile. This system has a built in Auto- dialer for increased security. To ensure the best performance of your system, please read this manual thoroughly and follow the precautions and instructions presented. -
Page 5: Planning For Installation
Planning for Installation The security system is designed to be as flexible as possible in order to meet your present needs, and also to adapt as your needs change. For the reason, we recommend that you read and consider the following information and plan your system before installing these devices. -
Page 6: Connecting The Telephone Line
Connecting the Telephone Line To connect the Main Console to the telephone line, Please follow these steps: Locate the two phone jacks at the top of the main console. These phone jacks are marked “ Phone “ and “ Line “. Connect one end of the telephone cord that came with the system into the connector, labeled”... -
Page 7: Operation - Main Console
Operation – Main Console The Main Console is the heart of the security system. It monitors the sensors and responds according to how it is programmed, whenever a sensor is activated. The illustration shown for the Main Console may look complex at first, however, most procedures are straightforward and easy. -
Page 8: Function For Installer Menu
13. Armed LED : When the light is ‘on’, the system is armed; When the light is ‘off’, the system is disarmed. 14. LCD Panel : Displays messages 15. Speaker : Sounds alarm and plays back messages 16. Antenna : Used for wireless reception 17. -
Page 9: System Option Menu
3.1: System Option menu : Press 0 to start setting Setting : 0 – T 1 2 3 4 5 6 – P 7 – MSG 8 – DIAL 9 - CODE (1) 0-T : For time setting (Default is 30 seconds.) minimum 1 second, maximum 255 seconds. - Page 10 Setting 5 Setting 6 Note: The dialer will work w ith a touch tone service line only (3) 7- MSG : To set a recorded message which contains 1 segment of message for a maximum of 25 seconds. If the recorded message is less than 25 Sec, press ENTER to end the recorded message.
-
Page 11: 3.2: Sequence Programming Menu
Press 1 to change the Install code menu. Setting : Change Code 1 – Install Press 2 to change the Master code menu. Setting : Change code 2 – Master : 1 3 5 2 4 6 3.2: Sequence Programming Menu This menu for code learning establishes a link between all sensors/other wireless devices and the main console. -
Page 12: 3.3: Replacement Menu
If the sensor that was learnt into the main console is sending a signal during the learning mode, the main console will indicate on the LCD, as shown below and will not allow duplication. If the sensors “learned” reaches 63 zone numbers, the LCD panel will show a full message memory. -
Page 13: Function For Master Menu
Clear Sensor 1 – Single Press 1 , and key-in the sequence learning order number. Press ENTER , to clear the sensor. Clear Sensor 1 – Single Clear Sensor Clear OK Press 2 , It will display the words “Are you sure ? ”. Press ENTER to clear all learned sensors. -
Page 14: Check Function
Now the system will select the arm mode and set the system in either Away arm/Home Arm mode (see below ): A - AWAY : Press the AWAY button to set the “ Armed - Away “ alert. After the exit delay the Arm LED will illuminate steady and the system is armed in the AWAY mode. -
Page 15: Arm Or Disarm Via The Telephone Line
SP DIAL + 5 , the autodial order is: : Preset 5 Preset 3 (Fire condition) SP DIAL + 6 , the autodial order is: : Preset 6 Preset 3 (Medical help condition) Arm or Disarm Via the Telephone Line (for Tone Mode) This function allow s you to dial your home telephone from outside and remotely control/change the arm/disarm status of your security system. -
Page 16: Lcd Messages
24 Hour & Home-Away Functions 24 Hour Mode The Sylvania® security system can work for you 24 hours a day,7 days a week. The system features a 24 hour status capability which is important for use with some accessory sensors. The s ensors that belong to the 24 hour mode include the Smoke... -
Page 17: Remote Control Handset
Remote Control Handset The key chain Remote Control Handset is a convenient way to arm (Home / Away mode) or disarm this system. Before using this device, please program it into the main console via the sequence programming menu. LEGEND 1. -
Page 18: Pir Motion Detector
PIR Motion Detector The PIR Motion Detector is designed to detect the movement of objects in a room or hallway. The effective range of the motion sensor is 30 feet long, with an 84degree horizontal angle. Before using this sensor, please program this sensor into the main console via the sequence programming menu. - Page 19 Replace the Battery When the sensor sends a low battery message to main console, remove the old battery and replace it with a fresh alkaline battery. The LCD is shown below 63 PIR SENSOR 01 Low battery Zone Address Setting Enter the Installer password and press “1”...
-
Page 20: Door/Window Detector
To install the PIR Motion Sensor, please follow these steps : Take out the screws or double sided adhesive and install the mounting bracket on the wall. Press the ball joint portion into the bracket until it snaps securely. (Secure the mounting bracket on the wall, 2 meters above the floor). Place the PIR sensor on the mounting bracket. - Page 21 Change the Battery When the sensor sends a low battery message to the main console, remove the old battery and replace it with a fresh alkaline battery. The low battery message on the LCD is shown below 63 WINDOW SENSOR 01 Low battery Zone address setting You can set the sensor as “...
- Page 22 When the system is in the process of arming, and the sensor has been opened prior to the arming. (message shown on main console) Window opened 63 WINDOW SENSOR 01 Open Window battery cover opened 63 WINDOW SENSOR 01 Tamper Installing the Door/Window Detector Installing for( DC 12V Detector): To install a Door/Window Detector, follow these steps:...
-
Page 23: Mini Siren
Mini Siren The siren is an effective deterrent to intruders. Choose a location inside your home where the siren is not plainly visible, but can be heard throughout the house. It is important to install the siren where the cable can be hidden, and discreetly out of reach of potential intruders (or anyone likely to tamper with the system.) When the siren is installed and the system is set to Arm, it will emit a piercing 110 decibel siren, once a sensor/detector activates the alarm. -
Page 24: Summary Of Program - Main Console
Summary of Program – Main Console Use the following form to record your programming choices for future reference. Item Install Code Master Code Exit Time Alarm Time Entry Time Auto-dialing Mode Preset Telephone No. for Auto-dialing : No. 1 No. 2 No. -
Page 25: Summary Of Sensors And Zone Settings
Summary of Sensors and Zone Settings Use the following form to record the setting detail of sensors Learning Place of Number Installation 2F-xx room Learning Place of Number Installation Learning Zone Label Number Window 1 Learning Zone Label Number Place of Zone Label Installation Place of... -
Page 26: Specifications
Items Frequency Power Source Power Consumption Back-up Battery (Optional) Temperature Range RF Range Security Code Alarm Activation Time Dialing Type Voice Message Playing Time Preset Telephone Numbers Material Weight Dimensions Specifications Specifications - 303Mhz or 433Mhz - AC120V, DC 12V - 70mA (idle), 170mA (activated) - Approximate 7 hours ( NO AC adaptor) - 0°C ~ 40°C... -
Page 27: Installation Template
Installation Template “Installation template for wall mounting of main control panel” 1. Use the template on the right to mark positions for mounting screws to install the main control panel on the wall. 2. Once the mounting screw positions have been marked, drill 3/16” pilot holes and install the plastic wall anchors supplied.
