Brother PT-P710BT Quick Setup Manual

Hide thumbs Also See for PT-P710BT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
PT-P710BT
Please read this guide, including all Precautions, before using this label
printer. After reading this guide, keep it in a safe place.
For FAQs, Troubleshooting, and to download the label printer's software and
manuals, visit support.brother.com.
Supplies
Brother TZe Tape Cassette
Compatible widths
Head Cleaning Tape
Cassette
Rechargeable Li-ion Battery PA-BT-005
• The available supplies may vary depending on the country or region.
• Brother reserves the right to make changes without notice in the
specifications and materials contained herein and shall not be
responsible for any damages (including consequential) caused by
reliance on the materials presented, including but not limited to
typographical and other errors relating to the publications.
• Unauthorized duplication or reproduction of any or all content of this
document is prohibited.
• Please note that we cannot assume any responsibility for any
damage or lost profit arising from the use of the label created with
this label printer or the disappearance or change of data due to
failure, repair or consumables using battery, or any claim from a third
party.
(USA and Canada)
Quick Setup Guide (English)
0.13, 0.23, 0.35, 0.47, 0.70, 0.94 in.
3.5, 6, 9, 12, 18, 24 mm
TZeCL4
D014E0001

Advertisement

Table of Contents
loading

Related Manuals for Brother PT-P710BT

Summary of Contents for Brother PT-P710BT

  • Page 1 Rechargeable Li-ion Battery PA-BT-005 • The available supplies may vary depending on the country or region. • Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publications.

  • Page 2: Safety Precautions

    Safety Precautions Follow these guidelines to avoid the risk of heat generation, smoking, explosion, fire, or injury. Failure to observe instructions and warnings will result in death or DANGER serious injuries. Rechargeable Li-ion Battery • Do not allow the battery to come into contact with liquids. •...

  • Page 3: General Precautions

    • Do not use in any way or for any purpose not described in this guide. Doing so may result in accidents or damage. • Use Brother Tape Cassettes. • Do not put any foreign objects into the Tape Exit Slot, the USB Port, battery compartment, etc.

  • Page 4: Parts Description

    1. Components D00N52001 2. Parts Description Power LED Tape Exit Slot Power Button Battery LED Cassette USB Port Cover Tape Guide End of Tape...
  • Page 5 3. Insert the Tape Cassette 1. Place your fingers on the Tape Exit Slot. 2. Open the Cassette Cover by pulling the Tape Exit Slot to the left. 3. Confirm that the tape is pointed at the Tape Exit Slot and gently press the Tape Cassette into the label printer until it locks into place.

  • Page 6: Charge The Battery

    4. Charge the Battery 1. Pull out the protective sheet (first time only). 2. Connect the label printer to the USB Port (on computer) computer using the included USB 5 V DC, 0.5 A – 2 A cable, or connect the USB cable to a USB AC Adapter suitable for charging mobile devices, and plug the adapter into a power source.

  • Page 7: Print From Your Mobile Device

    5. Turn Power On or Off Power on Press the Power Button. Press and hold the Power Button until the Power Power off LED turns off. 6. Print from Your Mobile Device Download the P-touch app from the App Store or Google Play™. Create labels for business use, including barcodes, iPrint&Label...
  • Page 8 1. Go to the settings menu and make sure the Bluetooth option is on. 2. Select PT-P710BT**** (where **** is the last four digits of your label printer’s serial number. The unit's serial number is located inside the Cassette Cover, underneath the TZe Tape Cassette.).

  • Page 9: Print From Your Computer

    8. Print from Your Computer Visit install.brother and install the printer driver and P-touch Editor by follow- ing the on-screen instructions. The following software can Features be selected for installation: Printer Driver Software required to print from a label printer.

  • Page 10: Led Indications

    LED Indications Power Lit/Flashing Condition • Bluetooth connection established • Feeding or cutting tape • Printing • Receiving data from a mobile device or Flashing Green a computer (0.5 second intervals) • Transferring program Lit for 3 seconds, then Standby off for 1 second Initializing Orange...

  • Page 11: Led Troubleshooting

    Cutter error Restart the label printer. Transfer the program again. Program transfer If the problem is still not resolved, failure contact Brother customer service. Flashing Contact Brother customer service. (0.3 second System error (The flashing pattern may change if you intervals) touch the Power Button.)

  • Page 12: Troubleshooting

    Troubleshooting If you need additional help, visit support.brother.com. Problem Solution • Check that the Tape Cassette is inserted correctly. • If the Tape Cassette is empty, replace it. • Check that the Cassette Cover is securely closed. • Check that the charge is not low.

  • Page 13: Troubleshooting (Cont)

    Windows Use the P-touch Update Software to confirm if you have the latest I want to check I am using version. See the User’s Guide: Windows, Update Software. the latest version of the software. See support.brother.com...
  • Page 14 Remove Battery for Replacement or Disposal 1. Turn the label printer off. 2. Open the Cassette Cover. 3. Remove the two screws from the Battery Cover using a flat- bladed screwdriver. 4. Remove the battery. • Dispose of batteries at an appropriate collection point.
  • Page 15 • The enclosed interface cable should be used in order to ensure compliance with the limits for a Class B digital device. • Changes or modifications not expressly approved by Brother Industries, Ltd. could void the user's authority to operate the label printer.

  • Page 16: Contact Information

    Please call 1-800-8-BATTERY for information on how to recycle this battery. Contact Information Phone : 1-877-BROTHER (1-877-276-8437) Fax : 1-901-379-1210 Customer Service for USA To order supplies and accessories : www.brothermall.com...
