  • Page 1 7000 FIM-7904E Interface Module Guide...
  • Page 2 FORTINET DOCUMENT LIBRARY http://docs.fortinet.com FORTINET VIDEO GUIDE http://video.fortinet.com FORTINET BLOG https://blog.fortinet.com CUSTOMER SERVICE & SUPPORT https://support.fortinet.com  http://cookbook.fortinet.com/how-to-work-with-fortinet-support/ FORTIGATE COOKBOOK http://cookbook.fortinet.com FORTINET TRAINING SERVICES http://www.fortinet.com/training FORTIGUARD CENTER http://www.fortiguard.com FORTICAST http://forticast.fortinet.com END USER LICENSE AGREEMENT http://www.fortinet.com/doc/legal/EULA.pdf FEEDBACK Email: techdocs@fortinet.com Friday, June 23, 2017 FIM-7904E Interface Module Guide 01-540-374567-20170623...

  • Page 3: Table Of Contents

    Installing QSFP+, SFP+, and SFP transceivers To install transceivers FIM-7904E mounting components Inserting a FIM-7904E module into a chassis Shutting down and removing a FIM-7904E board from a chassis Troubleshooting FIM-7904E does not startup FIM-7904E status LED is flashing during system operation...

  • Page 4: Fim-7904E Interface Module

    FPM processor modules. The FIM-7904E can be installed in any FortiGate-7000 series chassis. Normally you would install two FIM-7904E modules in chassis hub/switch slots 1 and 2. Two FIM-7904Es provide a total of eight Quad Small Form-factor Pluggable plus (QSFP+) interfaces for a FortiGate-7000 chassis.

  • Page 5: Physical Description

    -31 to 158°F (-35 to 70°C) Relative Humidity 10% to 90% (Non-condensing) Front panel LEDs From the FIM-7904E font panel you can view the status of the module LEDs to verify that the module is functioning normally. State Description The FIM-7904E is powered off.

  • Page 6: Front Panel Connectors

    Connection at 10Mbps. Front panel connectors You connect the FIM-7904E to your 100Gbps networks using the C1 to C4 front panel CFP2 interfaces. The front panel also includes M1 and M2 SFP+ interfaces for the base channel, four Ethernet management interfaces FIM-7904E Interface Module Guide Fortinet Technologies Inc.

  • Page 7: Supported Transceivers And Breakout Cables

    You can split the interfaces of the FIM-7904Es in slot 1 and slot 2 at the same time by entering a single CLI command. Splitting the interfaces requires a system reboot so Fortinet recommends that you split multiple interfaces at the same time according to your requirements to avoid traffic disruption.

  • Page 8: Turning The Module On And Off

    FIM-7904E interface module For example, to split the B1 interface of the FIM-7904E in slot 1 (this interface is named 1-B1) and the B1 and B4 interfaces of the FIM-7904E in slot 2 (these interfaces are named 2-B1 and 2-B4) connect to the CLI of your...
  • Page 9 FIM-7904E interface module FIM-7904E hardware architecture FIM-7904E hardware architecture Data Management Heartbeat (B1 - B8) (MGMT1-4) (M1 M2) Integrated Switch Fabric Chassis Fabric Backplane Chassis Base Backplane FIM-7904E Interface Module Guide Fortinet Technologies Inc.

  • Page 10: Hardware Installation

    This chapter describes installing a FIM-7904E interface module into a FortiGate-7000 chassis. Installing QSFP+, SFP+, and SFP transceivers You must install QSFP+ transceivers into the FIM-7904E B1 to B8 interfaces before connecting them to 40Gbps networks. See FIM-7904E front panel on page 4 for the locations of the B1 to B8 interfaces.

  • Page 11: Fim-7904E Mounting Components

    (when open the latch slides up about 2 mm) The FIM-7904E handles align the module in the chassis slot and are used to insert and eject the module from the slot. The latches activate micro switches that turn on or turn off power to the module. When both latches are raised the module cannot receive power.

  • Page 12: Inserting A Fim-7904E Module Into A Chassis

    If the module is not receiving power all LEDs remain off. FIM-7904Es are hot swappable. The procedure for inserting a FIM-7904E into a chassis slot is the same whether or not the chassis is powered on.
  • Page 13 In the photograph an example FIM-7904E is being installed into chassis slot 1 of a FortiGate-7040E chassis. 2. Unlock the left and right handles by pushing the handle latches up about 2 mm until the handles pop open.
  • Page 14 Inserting a FIM-7904E module into a chassis Hardware installation 3. Carefully slide the module into the slot until the handles engage with the sides of the chassis slot, partially closing them. Insert the module by applying moderate force to the front faceplate (not the handles) to slide the module into the slot.
  • Page 15 Hardware installation Inserting a FIM-7904E module into a chassis 5. Tighten both retention screws to secure the module in the chassis. You can tighten the retention screws by hand with a Phillips screwdriver. If you use a power screwdriver the tightening torque needs to be adjusted between 3 In-lb to 4 In-lb (0.4 N-m to 0.48 N-m).

  • Page 16: Shutting Down And Removing A Fim-7904E Board From A Chassis

    Disconnect all cables from the FIM-7904E module, including all network cables and USB cables or keys. FIM-7904Es are hot swappable. The procedure for removing a FIM-7904E from a chassis slot is the same whether or not the chassis is powered on.
  • Page 17 Hardware installation Shutting down and removing a FIM-7904E board from a chassis 1. Fully loosen the retention screws. You must fully loosen the screws or the handles may be damaged when used to eject the board from the chassis slot.

  • Page 18: Troubleshooting

    4. Hold the module front panel sides and slide it part way out of the slot. Then grasp the module by the sides and carefully slide it out of the slot. Troubleshooting This section describes some common troubleshooting topics: FIM-7904E Interface Module Guide Fortinet Technologies Inc.

  • Page 19: Fim-7904E Does Not Startup

    Latches and handles not fully closed If the latches or handles are damaged or positioned incorrectly the FIM-7904E may not start up. Make sure the latches are fully closed and the handles are correctly aligned, fully inserted and locked and the retention screws are tightened.

  • Page 20: Quick Fim-7904E Configuration

    CLI. You can connect to the GUI using HTTP or HTTPS, You can connect to the CLI using SSH or Telent or by a direct console connection to the FIM-7904E Console port. Use a terminal emulator with the following settings to connect to the console port: bits per second: 9600, data bits: 8, parity: none, stop bits: 1, flow control: none.
  • Page 21 Quick FIM-7904E configuration Changing network settings At any time during the configuration process, if you run into problems, you can reset the FIM-7904E to the factory defaults and start over. From the CLI enter execute factoryreset. Connect to the GUI by connecting MGMT1 of the module in slot 1 to your network and browsing to https://192.168.1.99.

  • Page 22: Cautions And Warnings

    Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips). FIM-7904E Interface Module Guide Fortinet Technologies Inc.

  • Page 23: Safety

    Attention: Débranchez les cordons de la source d’alimentation avant tout entretien. Grounding — To prevent damage to your equipment, connections that enter from outside the building should pass through a lightning / surge protector, and be properly grounded. Use an electrostatic discharge workstation FIM-7904E Interface Module Guide Fortinet Technologies Inc.
  • Page 24 Fiber optic transceiver must be rated 3.3V, 22mA max, Laser Class 1, UL certified component. Le transceiver optique doit avoir les valeurs nominales de 3.3 V, maximum 22 mA, Laser Class 1, homologué UL FIM-7904E Interface Module Guide Fortinet Technologies Inc.

  • Page 25: Regulatory Notices

    European Conformity (CE) - EU This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FIM-7904E Interface Module Guide Fortinet Technologies Inc.

  • Page 26: Voluntary Control Council For Interference (Vcci) - Japan

    此 为 A级 产 品 ， 在 生 活 环 境 中 ， 该 产 品 可 能 会 造 成 无 线 电 干 扰 。 这 种 情 况 下 ， 可 能 需 要 用 户 对 其 采 取 切 实 可 行 的 措 施 。 FIM-7904E Interface Module Guide Fortinet Technologies Inc.
  • Page 27 Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests. In no event does Fortinet make any commitment related to future deliverables, features, or development, and circumstances may change such that any forward-looking statements herein are not accurate.
