Plantronics CS50 Tips For Installing

Air Talk 900™ Wireless Intercom
TIPS FOR INSTALLING THE PLANTRONICS CS50
Introduction
Air Talk 900™
Wireless Office Headset System. This system offers crystal clear, secure
communications. The headsets, with integrated battery, offer up to 8 hours of wireless,
hands-free talk time and up to 300 feet of roaming distance.
Making the Connections to the CS50
1. Connect the AC Power Adapter to the power jack on the bottom of the CS50.
2. Connect the provided short handset cable between the back of the
audio console and the bottom of the CS50.
a. There are two handset jacks on the bottom of the CS50; you must use the
Initial Setup of the CS50
1. There is a Configuration Dial on the left side of the CS50 – set this dial so that the
number "1" is facing to the right.
2. Set the Master Speak Volume (outgoing volume) located on the bottom of the CS50
to the "B" position.
3. Set the Master Listen Volume (incoming volume) located on the back of the CS50 to
the number "1" position.
Fine Tuning the CS50 Volumes
1. Fine tune the outgoing speaker volume by using the up (+) and down (-) buttons on
the back of the CS50 base.
2. Fine tune the incoming listen volume by using the small up and down button control
located at the very back end of the boom portion of the teller headset.
Other Hints When Using the CS50
HFEA-CS50AT900 (071807)
wireless audio consoles have integrated support for the Plantronics CS50
complete
one with the
telephone handset.
picture of the telephone, not just the picture of the
Air Talk 900™
Page 1 of 2
