- Page 1 ..................WIRELESS OFFICE HEADSET SYSTEM...
-
Page 2: Table Of Contents
Additional Parts (If required) Maintenance Technical Assistance Regulatory Notices REGISTER YOUR PRODUCT ONLINE Visit www.plantronics.com/productregistration to register your CS50/CS55 product online so we can provide you with the best possible service and technical support. PACKAGE CONTENTS Headset and Wearing Options Headset... -
Page 3: Features
FEATURES Base - Top View Base - Top View CS55 CS55 CS50 CS50 FEATURES Base - Bottom View Front: Front: Indicator Lights Indicator Lights Talking (Green) Talking (Green) Power (Red) Power (Red) Charging (Amber) Charging (Amber) Charging Cradle Charging Cradle Headset Telephone Telephone... -
Page 4: Setup
SETUP Unplug the handset cord from phone. Plug the phone cord that is connected to the CS50/CS55 base into the handset jack on the phone. CAUTION: Your phone may have two similar jacks. Put the cord only in the jack from which the handset came. -
Page 5: Setup - Handset Lifter (Optional)
SETUP - HANDSET LIFTER (Optional) 1. Plug handset lifter power cord into handset lifter jack on base. Push firmly into base. 2. Position handset lifter under the handset on your phone. Verify that the lifter is located on top of the telephone speaker. If not, you will need to attach the ringer microphone as described on page 22. -
Page 6: Adjusting Fit
ADJUSTING FIT Wearing Options Retaining Ring Snap speaker into retaining ring of desired 1. Adjust headband to fit. wearing option (headband or earloop). 2. Rotate headset in retaining ring until microphone is pointing toward your chin. MAKING/ANSWERING/ENDING CALLS Without Handset lifter To make a call: 1. -
Page 7: Checking Compatibility
MAKING/ANSWERING/ENDING CALLS With Handset Lifter (Optional) With Handset Lifter (Optional) To first test proper set up of the handset lifter: 1. Press the call control button on headset to activate handset lifter and lift handset from phone. Dial tone should sound in headset if the handset is raised high enough. 2. -
Page 8: Volume
LISTENING VOLUME Note: Be sure to set your telephone’s volume at the mid range before adjusting the CS50/CS55 volume. Minor Adjust Major Adjust Rock the headset volume control back and Use listening volume major adjust forth to adjust listening volume in minor control on the back of the base for large incremental adjustments. -
Page 9: Headset Controls
HEADSET CONTROLS Feature Action Listening volume Rock back minor adjust and forth Short key press Mute straight in Making/answering/ Short key press ending calls Low battery Return headset — warning to charging cradle Out of range Move closer — warning—when to base on active call Incoming call... -
Page 10: Troubleshooting
• Check that the AC charger is securely connected to a working come on. wall outlet. • Check that the AC charger is the model supplied by Plantronics. My headset does • Check that the phone is connected to the base unit’s phone cord not work with the jack and it is pushed in firmly. -
Page 11: Subscription
BATTERY REPLACEMENT The custom battery inside the headset should last 2-3 years. When talk time decreases significantly, you should replace the battery. Call Plantronics at (800) 544-4660 ext.5538 to order one. Once you receive it, follow directions below to replace. -
Page 12: Additional Parts (If Required)
Telephone companies report that electrical surges, typically lighting transients, are very destructive to customer terminal equipment connected to AC power sources. NOTE: Changes or modifications not expressly approved by Plantronics, Inc. could void the user's authority to operate the equipment.
