  • Page 1 V19.2.00...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Erp Off Mode Power Consumption Statement

    Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
  • Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.

  • Page 6: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
  • Page 8 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 9: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 11: Servicing

    Preface Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and may expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions: •...

  • Page 12: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer.  • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply.

  • Page 13: Polymer/Lithium-Ion Battery Precautions

    Preface Polymer/Lithium-Ion Battery Precautions Note the following information which is specific to Polymer/Lithium-Ion batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer/Lithium-Ion batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern.

  • Page 14: General Battery Precautions

    Preface General Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 15: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Cleaning Instructions (For Computer Models Supplied with Light Blue Cleaning Cloth) Some computer models in this series come supplied with a light blue cleaning cloth.

  • Page 16: Servicing

    Preface Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply and then refer servicing to qualified service personnel under any of the following conditions: •...

  • Page 17: Travel Considerations

    Preface Travel Considerations As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 18 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 19 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 20 Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 21: Table Of Contents

    Preface Contents Notice ................................I ErP Off Mode Power Consumption Statement: ................... II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Servicing ..............................IX Power Safety ..............................X Polymer/Lithium-Ion Battery Precautions ....................XI General Battery Precautions ........................XII Cleaning ..............................
  • Page 22 Preface System Startup ............................1-4 System Software ............................1-5 LCD Panel Open ............................1-6 LED Indicators ............................1-7 Illuminated White LED Keyboard ......................1-8 Illuminated Color LED Keyboard ......................1-9 Keyboard Backlight LED Device ......................1-10 Keyboard Shortcuts ..........................1-11 Function/Hot Key Indicators ........................1-12 Control Center ............................1-13 Flexikey® Application ..........................1-14 Front &...
  • Page 23 Preface Video Features ............................1-27 Power Options ............................1-31 Features & Components Overview ..............................2-1 Hard Disk Drive/Solid State Drive ......................2-2 Multi-In-1 Card Reader ..........................2-3 Touchpad and Buttons/Mouse ........................2-4 Touchpad Sensitivity ..........................2-4 Mouse Properties Control Panel ........................2-5 Mouse & Touchpad Devices ........................2-7 Realtek Audio Console ..........................2-13 Realtek Audio Console - Main ........................2-14 Realtek Audio Console - Speakers ......................2-15 Realtek Audio Console - Microphone .....................2-16...
  • Page 24 Preface Shutting the Computer Down ........................3-4 Power Plans ...............................3-5 Power-Saving States ..........................3-7 Sleep ................................3-7 Hibernate ..............................3-8 Shut down ..............................3-8 Configuring the Power Buttons .........................3-9 Resuming Operation ..........................3-11 Settings Menu Power Controls ........................3-13 Battery Information ..........................3-16 Battery Power ............................3-16 Power Slider Settings ..........................3-17 Conserving Battery Power ........................3-18 Battery Life ..............................3-19 New Battery .............................3-19...
  • Page 25 Preface Driver Installation ............................4-2 Updating/Reinstalling Individual Drivers ....................4-5 User Account Control ..........................4-6 Windows Security Message ........................4-6 New Hardware Found ..........................4-6 Driver Installation Procedure ........................4-7 Chipset ...............................4-7 Intel Video (VGA) .............................4-7 NVIDIA Video (VGA) ..........................4-8 NVIDIA Apps ............................4-8 LAN ................................4-8 Card Reader ...............................4-8 Touchpad ..............................4-8 Intel®...
  • Page 26 Preface UEFI Boot ..............................5-3 Insyde BIOS Start Screen ..........................5-4 Insyde BIOS Start Screen Options: ......................5-5 Boot Manager ............................5-6 Boot From File / File Explorer ........................5-7 Administer Secure Boot ..........................5-8 Setup Utility - Main Menu ........................5-10 Setup Utility - Advanced Menu .......................5-12 Setup Utility - Security Menu ........................5-17 Setup Utility - Boot Menu ........................5-20 Setup Utility - Exit Menu ........................5-22...
  • Page 27 Preface WLAN Configuration in Windows 10 ....................6-10 Bluetooth & WLAN Combo Module ......................6-13 Intel Bluetooth Combo Driver Installation ....................6-14 Qualcomm Atheros Bluetooth Combo Driver Installation ..............6-14 Bluetooth Configuration in Windows ......................6-15 To Make your Computer Discoverable to Bluetooth Devices ..............6-18 Fingerprint Reader Module ........................6-19 Fingerprint Reader Driver Installation .....................6-20 Fingerprint Module Configuration ......................6-21...
  • Page 28 Preface Disabling Intel® Optane™ ........................6-43 PC Camera ...............................6-47 Camera App .............................6-48 Taking Pictures/Capturing Video ......................6-51 Trusted Platform Module .........................6-53 Enabling & Activating TPM ........................6-54 TPM Management in Windows .......................6-55 TPM Actions ............................6-57 4G Module ...............................6-59 4G Configuration in Windows 10 ......................6-61 Troubleshooting Overview ..............................7-1 Basic Hints and Tips ..........................7-2...
  • Page 29 Preface Notebook Ports and Jacks .........................A-2 Control Center Overview ..............................B-1 System Monitor ............................B-4 Basic Setting .............................B-7 LED Device Menu - Colored LED Keyboards ..................B-10 LED Device Menu - White LED Keyboards ..................B-14 Extra Setting ............................B-15 Flexikey® Application ...........................B-16 Profiles ..............................B-16 Flexikey®...
  • Page 30 Preface Mouse Settings - Express Text .......................B-34 Mouse Settings - Disable ........................B-36 Statistics ..............................B-37 Video Driver Controls Overview ..............................C-1 Microsoft Hybrid Graphics ........................C-2 Video Driver Installation ..........................C-4 Intel Video (VGA) ............................C-4 NVIDIA Video (VGA) ..........................C-5 NVIDIA Apps ............................C-5 NVIDIA GeForce Experience ........................C-6 Configure Other Displays Using Project ....................C-7 Configuring an External Display In Windows ..................C-8 HDMI Audio Configuration ........................C-10...
  • Page 31 Preface HDCP Status ............................C-30 Adjust Video Settings ..........................C-31 Configure Surround, PhysX® .........................C-32 Set Digital Audio ............................C-33 Intel® UHD Graphics Control Panel ......................C-34 Specifications Core Logic ..............................D-2 Display ..............................D-2 Memory ..............................D-2 Storage ..............................D-2 Audio ................................D-2 Pointing Device & Keyboard ........................D-2 Interface ..............................D-2 Card Reader ..............................D-3 Slot ................................D-3 Communication ............................D-3...
  • Page 32 Preface Indicators ..............................D-4 BIOS .................................D-4 Environmental Spec ..........................D-4 Dimensions & Weight ..........................D-4...

  • Page 33: Quick Start Guide Overview

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 34: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1 “BIOS Utilities” on page 5 - 1 in the remainder of the User’s Manual.

  • Page 35: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows 10) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...

  • Page 36: System Startup

    Quick Start Guide System Startup Remove all packing materials, and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. When first setting up the computer use the following procedure (as to safeguard the computer during shipping, the battery will be locked to not power the system until first connected to the AC/DC adapter and initially set up as below): •...

  • Page 37: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 10 (64-bit) operating system is supported.

  • Page 38: Lcd Panel Open

    Quick Start Guide LCD Panel Open Figure 1 - 2 LCD Panel Open  1. Built-in PC Camera 2. PC Camera LED Wireless Device 3. Built-In Array Operation Aboard Microphone Aircraft 4. LCD The use of any portable 5. Speakers electronic transmission 6.

  • Page 39: Led Indicators

    Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Orange DC Power is Plugged In Green The Computer is On Blinking Green The Computer is in Sleep Mode Orange The Battery is Charging Green...

  • Page 40: Illuminated White Led Keyboard

    Quick Start Guide Illuminated White LED Keyboard  The optional illuminated white LED keyboard has an embedded numerical keypad Other Keyboards for easy numeric data input, and features function keys to allow you to change oper- ational features instantly. See Table 1 - 4, on page 1 - 12 for full function key com- If your keyboard is dam-...

  • Page 41: Illuminated Color Led Keyboard

    Quick Start Guide Illuminated Color LED Keyboard  The optional illuminated colored LED keyboard has an embedded numerical keypad Other Keyboards for easy numeric data input, and features function keys to allow you to change oper- ational features instantly. See Table 1 - 4, on page 1 - 12 for full function key com- If your keyboard is dam-...

  • Page 42: Keyboard Backlight Led Device

    Quick Start Guide Keyboard Backlight LED Device (For Illuminated Color Keyboards Only) Press Fn plus the key to toggle the keyboard LED on/off. The keyboard LED may be configured using the Fn + key combination outlined in the table below. In addition press Fn plus the key to launch the keyboard backlight application to configure the settings (see “LED Device Menu - Colored LED Keyboards”...

  • Page 43: Keyboard Shortcuts

    Quick Start Guide Keyboard Shortcuts  The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navi- gation/operation in Windows 10. Windows Logo Keyboard Shortcut Windows Logo Description Use the Windows logo Key + + D key com- bination to switch be- Tap Winkey Toggle the Start menu tween the Start screen...

  • Page 44: Function/Hot Key Indicators

    Quick Start Guide Function/Hot Key Indicators Keys Function Keys Function Fn + Play/Pause (in Audio/Video Programs) Brightness Decrease/Increase Fn + *Fan Control Toggle Automatic Fan Control / Full PC Camera Fn + Fn + Power / Max-Q* (*NVIDIA Power Toggle video adapter dependent) Airplane Mode Fn +...

  • Page 45: Control Center

    Quick Start Guide Control Center When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Con- trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/touch pad on/off.

  • Page 46: Flexikey® Application

    Quick Start Guide Flexikey® Application The Flexikey® application is a quick hotkey configuration application, which allows you to assign a single key to launch multiple key combinations, or to launch programs and applications, to create text macros and to disable certain keys. The application can also be used to configure the mouse buttons to create hotkeys for gaming etc.

  • Page 47: Front & Left Views

    Quick Start Guide Front & Left Views Figure 1 - 7 Front & Left Views LED Indicators Security Lock Slot Vent/Fan Intake/ Outlet DC-In Jack HDMI-Out Port  *Mini DisplayPort 1 *Mini DisplayPort 2 USB Ports 2 * USB 3.1 Gen 2 (Type C) Ports The USB 3.0 ports capable of 5Gbps (SuperSpeed) are classified as USB 3.1 Gen 1.

  • Page 48: Right & Rear Views

    Quick Start Guide Right & Rear Views Figure 1 - 8 Right & Rear Views Microphone-In Jack 2-In-Audio Jack (Headphone / S/PDIF-Out Jack) USB 3.0 (USB 3.1 Gen 1 - Type A) Port  Multi-in-1 Card Reader Multi-In-1 Card Reader SIM Card Reader The card reader allows you to use the most popular digital storage card formats: (for 4G USIM Cards...

  • Page 49: Module Sim Card Installation

    Quick Start Guide 4G Module SIM Card Installation (For Models with 4G Modules) Insert the SIM card as illustrated below (pay careful attention to the orientation of the card as the gold contact side of the card should face upwards towards the top of the computer) until it clicks fully into position. To eject the card simply press it until it ejects, but do not attempt to eject the card while connected to a 4G network (see below).

  • Page 50: Bottom View

    Quick Start Guide Bottom View Figure 1 - 10 Bottom View  Vent/Fan Intake/ Outlet Overheating RJ-45 LAN Jack To prevent your com- SIM Card Reader puter from overheating (Design I Only) make sure nothing blocks the Vent/Fan  Intake while the com- puter is in use.

  • Page 51: Windows 10 Start Menu

    Quick Start Guide Windows 10 Start Menu Most of the apps, control panels, utilities and programs within Windows 10 can be accessed from the Start Menu by clicking the icon in the taskbar in the lower left corner of the screen (or by pressing the Windows Logo Key on the keyboard).

  • Page 52: Right-Clicking The Windows Logo In Start Menu

    Quick Start Guide Right-Clicking the Windows Logo In Start Menu Right-click the Start Menu icon (or use the Windows Logo Key + X key combination) to bring up an advanced Context Menu of useful features such as Apps and Features, Power Options, Task Manager, Search, File Explorer, Device Manager, Computer Management and Network Connections etc.
  • Page 53 Quick Start Guide Pining/Unpinning Apps & Programs to/from the Start Menu To make things easy to find you can add and remove tiles for apps and programs to the Start Menu. Right-Click on a program’s icon and select Pin to Start from the drop-down menu. To remove an app or program from the Start Menu right-click the icon and select Unpin from Start.

  • Page 54: Windows 10 Control Panel

    Quick Start Guide Windows 10 Control Panel In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel can be accessed in a number of ways in Windows 10. • Select Control Panel under the Windows System item in the Start Menu.

  • Page 55: Settings

    Quick Start Guide Settings The Settings item in the Start Menu (and also as an App) gives you quick access to a number of system settings control panels allowing you to adjust settings for System, Devices, Network & internet, Personalization, Apps, Accounts, Time &...

  • Page 56: Windows 10 Taskbar

    Quick Start Guide Windows 10 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar. The notification area of the taskbar in the bottom right of the screen. Some of the Control Panels and appli- cations referred to throughout the course of this manual can be accessed from here.

  • Page 57: Action Center

    Quick Start Guide Action Center The Action Center appears as a vertical panel on the right side of the screen (click Expand to view the full pan- el) when you swipe in from the right or click the button in the notification tray. This gives you access to com- monly needed functions like Network, All Settings, Airplane Mode, and Project etc.

  • Page 58: Video Features

    Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display settings (click the Start Menu and click Settings > System or right-click the desktop and select Display settings) control panel (see over). In Windows 10 it is possible to quickly configure external displays from the Project menu ( press the Windows logo key on your keyboard and the P key or Fn + F7).
  • Page 59 Quick Start Guide To access the Display Settings: You can quickly adjust the display by right-clicking the desktop and selecting Display Settings. Adjust the settings for Brightness and color, Scale and layout, Resolution and Orientation from the menus. When and external display is attached you can arrange the display configuration from the Multiple Displays menu, and arrange the configuration from Select and rearrange displays.
  • Page 60 Quick Start Guide To access the Intel(R) HD/UHD Graphics Control Panel: Access the Intel Graphics Control Panel from the Start menu in Windows. You can right-click the Intel Graphics Control Panel in the Start menu and pin the control panel to the taskbar. Use the Ctrl + Alt + F12 key combination shortcut to open the Intel Graphics Control Panel.
  • Page 61 Quick Start Guide To access the NVIDIA Control Panel: Access the NVIDIA Control Panel from the Start menu in Windows (or right-click the desktop and select NVIDIA Control Panel). Figure 1 - 21 - NVIDIA Control Panel Video Features 1 - 29...

  • Page 62: Power Options

    Quick Start Guide Power Options Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power button item in Start Menu (or the context menu) may be used to Shut down or Restart (you can also add Hibernate/Sleep to the menu - see page 13).
  • Page 63 Quick Start Guide You can also use the context menu (right-click the Start Menu icon or press the Windows logo + X key combination) to Sign out, Sleep, Hibernate, Shut down, and Restart.  Adding Hibernate/Sleep to the Power Men 1.
  • Page 64 Quick Start Guide Minimum Screen Resolution Settings Windows 10 has minimum screen resolution requirements. Right-click a blank area of the Desktop and select Display Settings. Adjust the Display Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above.

  • Page 65: Features & Components Overview

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive/Solid State Drive • Multi-In-1 Card Reader • Touchpad and Buttons/Mouse • Realtek Audio Console Overview 2 - 1...

  • Page 66: Hard Disk Drive/Solid State Drive

    Features & Components Hard Disk Drive/Solid State Drive   The hard disk drive/solid state drive is used to store your data in the computer. The Bottom Cover Bottom Cover hard disk can be taken out to accommodate other serial (SATA) hard disk drives, Removal Warning Removal Warning however you will need to contact your distributor/supplier to do this in order to avoid...

  • Page 67: Multi-In-1 Card Reader

    Features & Components Multi-In-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Push-Push Card card into the slot and it will appear as a removable device, and can be accessed in Reader the same way as your hard disk (s).

  • Page 68: Touchpad And Buttons/Mouse

    Features & Components Touchpad and Buttons/Mouse  The Touchpad is an alternative to the mouse; however, you can also add a mouse to Touchpad Cleaning your computer through one of the USB ports. The Touchpad buttons function in In order to improve pad much the same way as a two-button mouse.

  • Page 69: Mouse Properties Control Panel

    Features & Components Mouse Properties Control Panel  You can configure the functions from the Mouse control panel in Windows as fol- Disabling the lows. Touchpad Right-click the Start Menu icon. If you need to disable Select Control Panel. the Touchpad for any Click Mouse (Hardware and Sound >...
  • Page 70 Features & Components Figure 2 - 4 Mouse Properties Control Panels 2 - 6 Mouse Properties Control Panel...

  • Page 71: Mouse & Touchpad Devices

    Features & Components Mouse & Touchpad Devices You can configure the functions from the Mouse or Touchpad control panels in De- vices in the Settings control panel as follows. Click the Settings item in the Start Menu (or All Settings in the Action Center). Click Devices.
  • Page 72 Features & Components Mouse Settings You can select the primary mouse button and scrolling options and access Mouse Properties from Additional mouse options. Figure 2 - 6 Windows Settings Mouse 2 - 8 Mouse & Touchpad Devices...
  • Page 73 Features & Components Touchpad Settings You can disable the Touchpad by clicking the Touchpad button to turn it off. You can set the system to automatically disable the internal Touchpad when an ex- ternal USB point device (e.g a USB mouse) is attached. Click “Leave touchpad on when a mouse is connected”...
  • Page 74 Features & Components Touchapd Taps The Touchpad Sensitivity feature helps prevent recognizing taps on the pad by ac- cident, by recognizing when your palm is resting on it or brushing its surface while you are typing. Click in the check box to enable/disable the different gestures or taps on the surface of the pad to perform specific actions to manipulate documents, objects and applica- tions.
  • Page 75 Features & Components Touchapd Scroll and Zoom Click to enable/disable the two finger scrolling and pinch zooming gesture. Figure 2 - 9 Scroll and Zoom/ Scrolling Gesture The two-finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight con- tinuous motion).
  • Page 76 Features & Components The three-finger and four-finger swipes and taps can be configured for a number of different functions. Select the appropriate function from the drop-down menu. Figure 2 - 11 Three-Finger Gestures (Swipes & Taps) Figure 2 - 12 Four-Finger Gestures (Swipes &...

  • Page 77: Realtek Audio Console

    Features & Components Realtek Audio Console  You can configure the audio options on your computer from the Sound control Volume Adjustment panel in Windows, or from the Realtek Audio Console Windows Start menu. The sound volume level Make sure you have installed the driver and checked the Microsoft Store for can be clicking using the updates (see “Audio”...

  • Page 78: Realtek Audio Console - Main

    Features & Components Realtek Audio Console - Main You can adjust the Speaker and Microphone levels by using the sliders in the Re- altek Audio Console Main window. Figure 2 - 14 Realtek Audio Console (Main) 2 - 14 Realtek Audio Console...

  • Page 79: Realtek Audio Console - Speakers

    Features & Components Realtek Audio Console - Speakers Click Speakers to access controls for the format and speaker balance etc. Figure 2 - 15 Realtek Audio Console (Speakers) Realtek Audio Console 2 - 15...

  • Page 80: Realtek Audio Console - Microphone

    Features & Components Realtek Audio Console - Microphone Click Microphone to access advanced controls for recording on the microphone. Adjust the recording Main Volume level to around 60, to obtain the optimum re- cording quality. The On-Screen menu which appears will depend on whether or not you have enabled Cortana, Figure 2 - 16 Realtek Audio...
  • Page 81 Features & Components Figure 2 - 17 Realtek Audio Console (Microphone - Cortana Disabled) Realtek Audio Console 2 - 17...

  • Page 82: Realtek Audio Console - Device Advanced Settings

    Features & Components Realtek Audio Console - Device Advanced Settings  Device Advanced Settings allows for further configuration of the Connector Set- tings, Playback Device and Recording Device. Device Advanced Settings For the purposes of re- cording it is recommend- that enable “Separate...

  • Page 83: Power Management Overview

    Power Management Chapter 3: Power Management  OS Note Overview Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 84: The Power Sources

    Power Management The Power Sources  The computer can be powered by either an AC/DC adapter or a battery pack. Forced Off AC/DC Adapter If the system “hangs”, Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ and the Ctrl + Alt + Del DC adapter will damage the computer and its components.

  • Page 85: Turning On The Computer

    Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- er button on the front panel. When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down).

  • Page 86: Shutting The Computer Down

    Power Management Shutting the Computer Down Note that you should always shut your computer down by choosing the Shut down command as this will help prevent hard disk or system problems. Use the Power item in the Start Menu and select Shut down. You can also use the context menu (right-click the Start Menu icon or press the Windows logo...

  • Page 87: Power Plans

    Power Management Power Plans  The computer can be configured to conserve power by means of power plans (Con- Resuming trol Panel > Power Options). You can use (or modify) an existing power plan, or Operation create a new one. Table 3 - 1, on The settings may be adjusted to set the display to turn off after a specified time, and page 3 - 11...
  • Page 88 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.

  • Page 89: Power-Saving States

    Power Management Power-Saving States  You can use power-saving states to stop the computer’s operation and restart where Wake On LAN you left off. Windows 10 uses the Sleep, Hibernate and Shut Down power-saving Support states. Wake-On-LAN is only supported from Sleep or Sleep Hibernate states...

  • Page 90: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 91: Configuring The Power Buttons

    Power Management Configuring the Power Buttons  The power/sleep button (Fn + F12 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
  • Page 92 Power Management Adding Hibernate/Sleep to the Power Menu Add Hibernate/Sleep to the Power Menu as follows. Go to the Power Options (Hardware and Sound) control panel. Click “Change settings that are currently unavailable” Click Choose what the power buttons do. Click to put a check in the Hibernate/Sleep box under Shutdown settings.

  • Page 93: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F12 key combo). Power Status Icon Color To Resume Table 3 - 1 Power Off Press the Power Button Resuming Press the Power Button...
  • Page 94 Power Management Ctrl + Alt + Delete Key Combination You can use the CTRL + ALT + DEL key combination from almost any of the Win- dows 10 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Sign out, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu ap- pears to display Sleep, Shut down, and Restart.

  • Page 95: Settings Menu Power Controls

    Power Management Settings Menu Power Controls The Settings item in the Start Menu (or via the Action Center) gives you access to a number of power settings control panels which enable you to quickly adjust power options. Click System to access the menu including the power option settings. Figure 3 - 8 Figure 3 - 9 Settings...
  • Page 96 Power Management Battery Saver Battery in Settings will display the battery level, and by clicking Battery usage by app you can see the current state of battery usage by application etc. The Battery saver can be level can be adjusted to be turned on if the battery level falls below a certain level to limit background activity and push notifications.
  • Page 97 Power Management Power & Sleep Power & sleep gives you quick access to Screen and Sleep settings. Click Addi- tional power settings to go to the main power options control panel. Figure 3 - 11 Settings > Power & Sleep Settings Menu Power Controls 3 - 15...

  • Page 98: Battery Information

    Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.

  • Page 99: Power Slider Settings

    Power Management Power Slider Settings  Better Best Battery Saver Battery Saver Better Battery Performance Performance Note that some Win- dows features and back- ground applications may behave differently, or may be blocked, when the system is in Battery Saver mode (check with For DC Only For AC &...

  • Page 100: Conserving Battery Power

    Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 101: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ”...

  • Page 102: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances Caution • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.

  • Page 103: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 104 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 16 Power Options Advanced Settings - Battery • Low battery level = 0% •...
  • Page 105 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
  • Page 106 Power Management 3 - 24...

  • Page 107: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities  This chapter deals with installing the drivers and utilities essential to the operation or Driver Installation & improvement of some of the computer’s subsystems. The system takes advantage of Power some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.

  • Page 108: Driver Installation

    Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. Click the message “Tap to choose what happens with this disc.” Click Run autorun.exe. Click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. Figure 4 - 1 - Drivers Installer Screen 1 4 - 2 Driver Installation...
  • Page 109 Drivers & Utilities Check the driver installation order from Table 4 - 1, on page 4 - 4 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below. Click to select the driver you wish to install, (you should note down the drivers as you install them). Follow the instructions for each individual driver installation procedure as listed on the following pages.
  • Page 110 Drivers & Utilities Win 10 (64-bit) Driver Page # Win 10 (64-bit) - Optional Items Page # Chipset Page 4 - 7 Setting Up SATA Mode (Optane™ or AHCI) Page 6 - 2 Intel Video (VGA) Page 4 - 7 Wireless LAN Module Page 6 - 8 NVIDIA Video (VGA)

  • Page 111: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.

  • Page 112: User Account Control

    Drivers & Utilities User Account Control  If a User Account Control prompt appears as part of the driver installation procedure, click Continue or Driver Installation General Guidelines Allow, and follow the installation procedure as direct- The driver installation procedure outlined in this Chapter (and in Chapter 7 Options &...

  • Page 113: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure 5. Click the Start menu in Windows to access the Microsoft Store App tile under Explore. Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button). 6. Click the Sign in icon and select Down- loads and updates.

  • Page 114: Nvidia Video (Vga)

    Drivers & Utilities NVIDIA Video (VGA) 1. Click 3.Install NVIDIA VGA Driver > Yes. Note: If the computer enters a deep sleep mode during installation, you will be prompted to plug in a network 2. Click AGREE AND CONTINUE (button) to cable, and click OK, to continue installation.

  • Page 115: Intel® Hid Filter Driver

    Drivers & Utilities Intel® HID Filter Driver Audio 1. Click 8.Install HID Filter Driver > Yes. 1. Click 11.Install Audio Driver > Yes. 2. Click Next. 2. Click Next. 3. Click Yes to accept the license. 3. Click Finish to restart the computer. 4.
  • Page 116 Drivers & Utilities After installing the audio driver the system will not re-  turn to the Drivers Installer screen. To install any of the optional drivers, eject the Device Drivers & Utili- Windows Update ties + User’s Manual disc and then reinsert it (or dou- After installing all the drivers make sure you enable Win- ble-click the disc icon in My Computer), and click dows Update in order to get all the latest security up-...

  • Page 117: Optional Drivers

    Drivers & Utilities Optional Drivers See the pages indicated in Table 4 - 1, on page 4 - 4 for the driver installation procedures for any modules in- cluded in your purchase option. Models A & B Figure 4 - 3 - Optional Drivers Installer Screen Note that you need to install both the WLAN &...
  • Page 118 Drivers & Utilities 4 - 12...

  • Page 119: Bios Utilities Overview

    BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software BIOS screens pictured (Basic Input/Output System). these pages are intend- ed for guidance in set- If your computer has never been set up, or you are making important changes to the ting up your system’s BIOS.

  • Page 120: The Insyde Bios Utility

    BIOS Utilities The Insyde BIOS Utility  Each time you turn on the computer the system takes a few seconds to conduct a in- BIOS Settings cluding a quick test of the on-board RAM (memory). Warning As the boot process proceeds, the computer will tell you if there is anything wrong. Incorrect settings can If there is a problem that prevents the system from booting, it will display a system cause your system to...

  • Page 121: Uefi Boot

    BIOS Utilities UEFI Boot UEFI (Unified Extensible Firmware Interface) is an advanced firmware standard supporting fast startup. With UEFI Boot prompts at boot to press F2 (to access the BIOS) or F7 (to access Boot options) will not appear. However you can still press F2 to enter the setup, or F7 to choose the preferred boot device, if you press the key immediately the system boots up.

  • Page 122: Insyde Bios Start Screen

    BIOS Utilities Insyde BIOS Start Screen On accessing the BIOS you will be presented with the Start Screen with 5 menu icons, date and time information, CPU temperature information and navigation and Help icons at the bottom of the screen. You can use the Touchpad, an attached mouse, or the cursor/arrow keys to navigate the menus and press Enter to access the submenu.

  • Page 123: Insyde Bios Start Screen Options

    BIOS Utilities Insyde BIOS Start Screen Options: • Continue: Press Enter here or click Continue to carry on with the boot process and load the operating system. • Boot Manager: Press Enter here or click Boot Manager to access the Boot Manager utility.

  • Page 124: Boot Manager

    BIOS Utilities Boot Manager Figure 5 - 2 Boot Manager  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change When you turn the computer on it will look for an operating system from the devices and revision, therefore listed in this menu, and in this priority order.

  • Page 125: Boot From File / File Explorer

    BIOS Utilities Boot From File / File Explorer Figure 5 - 3 Boot From File (File Explorer) If you need to boot from a file (e.g. on a USB flash drive) then access this menu and use the cursor keys to select the device or file (you can press Enter to explore for a file on an attached device).

  • Page 126: Administer Secure Boot

    BIOS Utilities Administer Secure Boot Figure 5 - 4 Administer Secure Boot Secure Boot prevents unauthorized operating systems and software from loading during the startup process. You can select a trusted UEFI file to execute the BIOS, make sure that you Enforce Secure Boot, Erase all Secure Boot Settings or Restore the Factory Settings.
  • Page 127 BIOS Utilities You can also make custom changes to the Key Management database if required by accessing the advanced secure boot options for Platform Key (PK Options), Key Ex- change Key (KEK Options), Allowed Signatures Database (DB Options) and For- bidden Signatures Database (DBX Options).

  • Page 128: Setup Utility - Main Menu

    BIOS Utilities Setup Utility - Main Menu Figure 5 - 6 Main (Upper) SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of an HDD on the computer’s SATA Ports. 5 - 10 Setup Utility - Main Menu...
  • Page 129 BIOS Utilities OffBoard SATA/NVme Controller Configuration (Main Menu) Pressing Enter opens the sub-menu to show the configuration of any devices on the off board SATA/NVme Controller if applicable. System Time & System Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.

  • Page 130: Setup Utility - Advanced Menu

    BIOS Utilities Setup Utility - Advanced Menu Figure 5 - 8 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to enable/disable Setup Menus, Flexicharger, GPU Performance Scaling, Intel(R) Speed Shift Technology, VT-d UEFI OS Fast Boot and Intel Software Guard Extensions. 5 - 12 Setup Utility - Advanced Menu...
  • Page 131 BIOS Utilities Figure 5 - 9 Advanced Chipset Control Menu Setup Utility - Advanced Menu 5 - 13...
  • Page 132 BIOS Utilities FlexiCharger Enable (Advanced Menu > Advanced Chipset Control)  The sub-menu here allows you to enable/disable the FlexiCharger. The FlexiCharg- er may be set to automatically start charging your battery when the battery reaches FlexiCharger Warning a certain capacity level (e.g. you could start the battery charge level at 40%). You can then set the level to stop charging (e.g.
  • Page 133 BIOS Utilities Intel(R) Speed Shift Technology (Advanced Menu > Advanced Chipset Control) Use this menu item to enable/disable Intel® Speed Shift Technology. You will also need to install the driver for Intel Speed Shift Technology (see “Intel® Speed Shift Technology Driver” on page 6 - 26).
  • Page 134 BIOS Utilities SATA Mode (Advanced Menu)  The SATA (Serial ATA) control is configured to operate in AHCI (Advanced Host ™ Controller Interface) mode or in Intel RST Premium With Intel Optane System Intel® Optane Acceleration (for Intel Optane ) mode. ™...

  • Page 135: Setup Utility - Security Menu

    BIOS Utilities Setup Utility - Security Menu  Security Menu The changes you make here affect the access to the BIOS utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords...
  • Page 136 BIOS Utilities Note: To clear existing supervisor passwords press Enter and type the existing pass-  word, then press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. To clear a user password just Password Warning click on Clear User Password.
  • Page 137 BIOS Utilities TPM Configuration (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select TPM Configuration and press En- ter to access the sub-menu. Press Enter to access the Security Device Support menu and select Enable to support TPM.

  • Page 138: Setup Utility - Boot Menu

    BIOS Utilities Setup Utility - Boot Menu Figure 5 - 13 Boot Menu & EFI  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual...
  • Page 139 BIOS Utilities UEFI Setting (Boot Menu) The Unified Extensible Firmware Interface (UEFI) specification provides a clean in- terface between operating systems and platform firmware at boot time. In contrast to BIOS, UEFI defines a set of standard boot and runtime services. The Network Stack item can be enabled/disabled as an option under UEFI Setting and PXE Boot capability can be enabled/disabled and configured here.

  • Page 140: Setup Utility - Exit Menu

    BIOS Utilities Setup Utility - Exit Menu Figure 5 - 15 Exit Menu Click Exit Saving Changes (or press F10) to save all changes made and exit the BI- OS. Choosing Exit Discarding Changes will wipe out any changes you have made to the Setup and exit the BIOS.

  • Page 141: Modules & Options Overview

    Modules & Options Chapter 6: Modules & Options  Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.

  • Page 142: Setting Up Sata Mode (Optane™ Or Ahci)

    Modules & Options Setting Up SATA Mode (Optane™ or AHCI)  AHCI Mode SATA Mode Advanced Host Controller Interface (AHCI) is an interface specification that allows Selection the storage driver to enable advanced serial ATA features such as Native Command The SATA mode selec- Queuing (for maximum hard disk efficiency and performance).

  • Page 143: Intel® Optane™ Setup Procedure

    Modules & Options Intel® Optane™ Setup Procedure  After initial setup make sure you install the Intel Rapid Storage Technology driver - see “IRST Driver Installation” on page 6 - 37). Optane SSD Module Removal You need to setup Intel Optane before installing your Windows 10 operating ®...
  • Page 144 Modules & Options Select SATA Mode (see page 16), press <Enter> and select “RAID Mode.”. Figure 6 - 1 SATA Mode Set to RAID Select “Save and Exit”. As the computer restarts press <F2> to enter the BIOS again. 10. Go to the Advanced menu and you will now see the Intel(R) Rapid Storage Technology (Advanced menu) item.
  • Page 145 Modules & Options (Note this item only appears after you have restarted and accessed the BIOS again after having set SATA Mode to RAID) Figure 6 - 3 Inte(R) Rapid Storage Technology Setting Up SATA Mode (Optane™ or AHCI) 6 - 5...
  • Page 146 Modules & Options 11. Select “Save and Exit”, however ensure that the condition in the bulleted point  below is met before doing so. • Make sure the Windows 10 OS DVD is in the DVD drive, as the computer starts Creating a Windows up it will automatically boot from the Windows 10 OS DVD (you will be Partition for Optane...
  • Page 147 Modules & Options 23. After installing the Intel® Rapid Storage Technology application you can access Device Manager (right-click the Start menu and select Device Manager). 24. Click Disk drives to check the Optane drive. Figure 6 - 4 Device Manager Setting Up SATA Mode (Optane™...

  • Page 148: Wireless Lan Module

    Modules & Options Wireless LAN Module  If your purchase option includes a Combination Wireless LAN & Bluetooth mod- Wireless Device ule (either Intel® or Qualcomm Atheros) then install the driver for the appropriate Operation Aboard module as instructed below. Aircraft The use of any portable Make sure that the module is on (i.e.

  • Page 149: Intel® Wlan Driver Installation

    Modules & Options Intel® WLAN Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install WLAN Driver > Yes. 4.

  • Page 150: Wlan Configuration In Windows 10

    Modules & Options WLAN Configuration in Windows 10 You can configure a wireless connection using one of the following options, how- ever make sure the Wireless LAN module is turned on (and not in Airplane Mode) before configuration begins. Click the Wireless icon in the notification area of the taskbar.
  • Page 151 Modules & Options Enter a network security key (password) if required, and click Next. You can choose to share or connect to devices or not. When you are connected to the network access point it will display Connected status Select any connected network and click Disconnect to disconnect from a connected access point.
  • Page 152 Modules & Options You can click the Airplane Mode button to turn the mode On or Off. 10. You need to either use Airplane Mode, or to turn the WLAN module off aboard aircraft. 11. If you click on Network Settings to bring up Network & Internet for a more comprehensive list of network and internet settings including Wi-Fi (can be turned on/off), Airplane mode (Airplane mode and Wireless devices can be turned on/off) VPN, Dial-up, Ethernet and Proxy.

  • Page 153: Bluetooth & Wlan Combo Module

    Modules & Options Bluetooth & WLAN Combo Module  If your purchase option includes a Combination Wireless LAN & Bluetooth mod- Wireless Device ule (either Intel® or Qualcomm Atheros) then install the driver for the appropriate Operation Aboard module as instructed below. Aircraft The use of any portable Make sure that the module is on (i.e.

  • Page 154: Intel Bluetooth Combo Driver Installation

    Modules & Options Intel Bluetooth Combo Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. 2. Click Option Drivers (button). 3.
  • Page 155 Modules & Options Bluetooth Configuration in Windows Go to the Settings control panel and click Devices (or click the Bluetooth icon in the taskbar and click Add a Bluetooth Device). Click Bluetooth & other devices and make sure Bluetooth is On. Click Add Bluetooth or other device >...
  • Page 156 Modules & Options Double-click the device you want to pair with the computer and click Connect, if the PIN matches that on the device to which you wish to connect (you may need to click paid on the device). Figure 6 - 10 Bluetooth Connect 6 - 16 Bluetooth &...
  • Page 157 Modules & Options Select a device and click Remove Device to disconnect from any device (click Yes to confirm). Figure 6 - 11 Bluetooth Remove Device Bluetooth & WLAN Combo Module 6 - 17...

  • Page 158: To Make Your Computer Discoverable To Bluetooth Devices

    Modules & Options To Make your Computer Discoverable to Bluetooth Devices Go to the Settings control panel and click Devices (or click the Bluetooth icon in the taskbar and click Open Settings). Click Bluetooth & other devices and click More Bluetooth options. In Bluetooth Settings make sure that Allow Bluetooth devices to find this PC check box (Discovery) has a check inside it.

  • Page 159: Fingerprint Reader Module

    Modules & Options Fingerprint Reader Module  The fingerprint reader module provides a high level of security for your computer. Fingerprint Reader Make sure you have administrator’s rights to your computer, and have a Windows and Power Saving password enabled for full security protection. States There are two different fingerprint modules supplied with this model.

  • Page 160: Fingerprint Reader Driver Installation

    Modules & Options Fingerprint Reader Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. 2. Click Option Drivers. 3. Click 3.Install Fingerprint Driver > Yes. 4.

  • Page 161: Fingerprint Module Configuration

    Modules & Options Fingerprint Module Configuration  Click the Settings item in the Start Menu and then click Accounts and click Sign- PIN Code in options. You will need to add a Windows password (click Add under Password). You will be asked to add After you have added the password you will need to also add a PIN.
  • Page 162 Modules & Options You will be instructed to swipe the same finger across the reader a number of times (this may be in excess of 20 times). Try to present different parts of your finger in different positions (similar to the various positions you may use when using it, and if you see red at any point try a different position).

  • Page 163: Sound Blaster Audio

    Modules & Options Sound Blaster Audio Install the Sound Blaster AP to allow you to configure the audio settings to your requirements for the best performance in games, music and movies. Sound Blaster Audio AP Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc an attached DVD drive.
  • Page 164 Modules & Options 11. Click on Sound Blaster Connect and click on the resume icon to down- load the driver. 12. When just installed the Sound Blaster Connect will appear in the Win- dows Start menu. 6 - 24 Sound Blaster Audio...

  • Page 165: Sound Blaster Connect Application

    Modules & Options Sound Blaster Connect Application Run the Sound Blaster Connect control panel from the Start menu in Windows. Figure 6 - 15 Sound Blaster Connect (Windows Start Menu) Sound Blaster Audio 6 - 25...

  • Page 166: Sound Blaster Connect

    Modules & Options Sound Blaster Connect  The Sound Blaster Connect BLASTER X EXPERIEINCE home Dashboard con- Setup for External tains a number of preset audio configurations for your use. You can create your own Speakers/Headphones Library settings by clicking the plus icon in Library .

  • Page 167: Sound Blaster Connect - Sound

    Modules & Options Sound Blaster Connect - Sound The Sound page allows you to adjust the Personal settings for Reality 3D, Equal- izer, Acoustic Engine, Scout Mode and Environment. Sound Blaster Cinema 3 Reality 3D allows you to enable 5.1/71 surround sound for headphones or speakers for Music, Movie or Games (click the button to turn it on).
  • Page 168 Modules & Options The Equalizer allows you to manually adjust the Custom settings (click On to en- able the Equalizer). Figure 6 - 18 Sound Blaster Connect Sound (Equalizer) 6 - 28 Sound Blaster Audio...
  • Page 169 Modules & Options The Acoustic Engine offers a suite of playback technologies to enhance sound. Each playback technology has an On/Off button to allow you to enable/disable it, and most controls feature a dial to adjust the levels. Figure 6 - 19 Sound Blaster Connect Sound (Acoustic Engine)
  • Page 170 Modules & Options Sound Blaster Connect - Scout Mode Click on the power button to enable Scout Mode to enhance your ability to hear en- emies in games from a further distance away than would normally be possible. Figure 6 - 20 Sound Blaster Connect Sound (Scout Mode)
  • Page 171 Modules & Options Sound Blaster Connect - Environment These profiles add a sense of realism to the gaming experience. Figure 6 - 21 Sound Blaster Connect Sound (Environment) Sound Blaster Audio 6 - 31...
  • Page 172 Modules & Options Sound Blaster Connect - Voice Morph These profiles allow you to alter your voice in gaming or online chats. Figure 6 - 22 Sound Blaster Connect Voice (Voice Morph) 6 - 32 Sound Blaster Audio...
  • Page 173 Modules & Options Sound Blaster Connect - Setup Setup at the bottom left of the screen contains 2 headings (Speaker and Calibra- tion) which allow you to select the appropriate type of speakers or headphones for your system, and to adjust their calibration. Figure 6 - 23 Sound Blaster Connect Setup...
  • Page 174 Modules & Options Sound Blaster Connect - Settings Settings at the bottom left of the screen allows you to set the language and distance preferences and to check for the latest application updates. Click Reset in Recovery to return to the factory default settlings. Figure 6 - 24 Sound Blaster Connect...

  • Page 175: Intel® Software Guard Extensions Driver

    Modules & Options Intel Software Guard Extensions Driver ® Install the Intel® Software Guard Extensions Driver which provides a set of in- structions allowing user-level code a degree of security, and privacy, from the oper- ating system. Make sure that SW Guard Extensions is Enabled in the BIOS before installing the driver (see “SW Guard Extensions (SGX) - (Advanced Menu >...

  • Page 176: Intel® Speed Shift Technology Driver

    Modules & Options Intel Speed Shift Technology Driver ®  Install the Intel® Speed Shift Technology driver as outlined below. Speed Shift *P-States Technology allows operating system to hand off some or all control of the handing P-states are voltage-fre- of the computer’s *P-States to the processor.

  • Page 177: Intel® Rapid Storage Technology

    Modules & Options Intel Rapid Storage Technology ®  The Intel® Rapid Storage Technology driver supports your AHCI mode SATA IRST and M.2 PCI-e drive, or your Intel® Optane™ system. Install the Intel Rapid Storage Technolo- SSDs gy application (after installing all necessary drivers in the correct order) to support Note that Intel®...

  • Page 178: Intel® Rapid Storage Technology For Optane Systems

    Modules & Options Intel® Rapid Storage Technology for Optane Systems  Intel® Rapid Storage Technology application displays status information on your Intel® Optane™ configuration. Run the Intel® Rapid Storage Technology appli- Optane SSD Module Removal cation from the item in the Start menu. When the Intel®...

  • Page 179: Enabling Intel® Optane

    Modules & Options Enabling Intel® Optane™ Run the Intel® Rapid Storage Technology application. Click Enable. Figure 6 - 26 ® IRST - Intel ™ Optane Memory (Enable) Enable The system will pop-up a message and ask you to select a compatible fast drive (in this case there should only be one option).
  • Page 180 Modules & Options You will need to restart the computer after enabling Optane, and make sure the system is powered by the powered AC/DC adapter, and not by battery only. Click Yes to begin the process (this may take some time). You can click the Intel Optane Memory tab in the IRST control panel and click Reboot to restart the computer, or simply after the process has been completed restart the computer.
  • Page 181 Modules & Options After restarting can access Device Manager (right-click the Start menu and select Device Manager). Click Disk drives to check that the drive should read Intel Optane ******. Figure 6 - 29 Device Manager (Disk drives) Intel® Rapid Storage Technology 6 - 41...
  • Page 182 Modules & Options Run the Intel® Rapid Storage Technology application to check the status. Figure 6 - 30 ® IRST - Intel ™ Optane Memory (Enabled) 6 - 42 Intel® Rapid Storage Technology...

  • Page 183: Disabling Intel® Optane

    Modules & Options Disabling Intel® Optane™  If you need to disable Intel® Optane™ for any reason follow these instructions. Disabling Intel® Run the Intel® Rapid Storage Technology application. Optane™ Click Disable. Disable Intel® Optane™ if you want to reinstall/ reset the system, re- move the Optane SSD or update the IRST driv-...
  • Page 184 Modules & Options Restart the computer to complete the process.  Run the Intel® Rapid Storage Technology application. The Status of Intel® Optane™ Memory is indicated in the Window. HDDs & Intel® To enable Intel® Optane™ Memory follow the process indicated in “Enabling Optane™...
  • Page 185 Modules & Options Restart your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu and you will now see the Intel(R) Rapid Storage Technology (Advanced menu) item. You can and press <Enter> to check the information.
  • Page 186 Modules & Options 11. Click Disable. Figure 6 - 35 Intel(R) Rapid Storage Technology (Disable Optane) 12. You can click to either Enable or Disable “Preserve user data:” 13. Click on “Are you sure you want to disable?” and select Yes. Figure 6 - 36 Intel(R) Rapid Storage Technology...

  • Page 187: Pc Camera

    Modules & Options PC Camera When the PC Camera application is run the LED indicator to the left of the camera will be illuminated (see Figure 1 - 2 on page 1 - 6). Note that you need to use the Camera app in Windows to take pictures and capture video.

  • Page 188: Camera App

    Modules & Options Camera App Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Start menu by clicking on the Camera app icon (you can type “camera”...
  • Page 189 Modules & Options Click Settings to access the camera settings menu to select/deselect Pro mode, make adjustments for Photo Quality, Framing grid, Time lapse, Video Quality and Flicker reduction.  Camera Settings The Self Timer can be set to take Photos after 2, 5 or 10 sec- onds.
  • Page 190 Modules & Options With the Pro mode selected (in Settings ) you can access the Brightness button to adjust the brightness. Figure 6 - 40 Figure 6 - 41 Camera Brightness Camera Brightness Adjustment Adjustment (Pro mode) (Pro mode) 6 - 50 PC Camera...
  • Page 191 Modules & Options In Auto mode you can toggle HDR on or off. Figure 6 - 42 Camera HDR (Auto mode) PC Camera 6 - 51...

  • Page 192: Taking Pictures/Capturing Video

    Modules & Options Taking Pictures/Capturing Video Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Start menu by clicking on the Camera app icon (you can type “camera”...
  • Page 193 Modules & Options Captured photos and videos will be saved to the Photos app stored in the Start menu (type Photos into the search box if you cannot find the app). You can also access the photos from the Camera roll icon at the bottom right of the Camera app screen.

  • Page 194: Trusted Platform Module

    Modules & Options Trusted Platform Module (Optional) The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.

  • Page 195: Enabling & Activating Tpm

    Modules & Options Enabling & Activating TPM  Restart the computer. Enter the BIOS pressing F2 during the POST/startup. Clearing TPM Click to enter the Setup Utility and select the Security menu. Information Click TPM Configuration and select Enable for Security Device Support. You will then need to save the changes and restart the computer.

  • Page 196: Tpm Management In Windows

    Modules & Options TPM Management in Windows You can manage your TPM settings from within Windows: Go to the Control Panel. Click BitLocker Drive Encryption (System and Security). Click TPM Administration. Figure 6 - 46 BitLocker Drive Encryption (TPM Administration) 6 - 56 Trusted Platform Module...
  • Page 197 Modules & Options The TPM Management window allows you to configure the TPM within Windows. As TPM is usually administered within large enterprises and organizations, your system administrator will need to assist you in managing the information here. Figure 6 - 47 Trusted Platform Module (TPM) Management on...

  • Page 198: Tpm Actions

    Modules & Options TPM Actions Click Prepare the TPM and follow the instructions in the Wizard to prepare the TPM (this will probably require a restart of the computer and confirmation of the setting changes after restart by pressing the appropriate F key). After the restart the TPM will be prepared and you can then use the Actions menu to Turn TPM off, Change Owner Password, Clear TPM or Reset TPM Lockout.
  • Page 199 Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk. Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Click Turn on Bit Locker. Follow the on-screen instructions to setup BitLocker, and make sure you have a removable media (e.g.

  • Page 200: Module

    Modules & Options 4G Module  If you have included an optional LTE/4G (Long Term Evolution) module (see Wireless Device “Communication” on page D - 3 for specification details) in your purchase option, Operation Aboard you do not require a driver/application installation for Windows. Follow the in- Aircraft structions overleaf to install the SIM card (which will be supplied by your service The use of any portable...
  • Page 201 Modules & Options 4G Module SIM Card Installation  Insert the SIM card as illustrated below (pay careful attention to the orientation of the card as the gold contact side of the card should face upwards towards the top SIM Card of the computer) until it clicks fully into position.

  • Page 202: 4G Configuration In Windows 10

    Modules & Options 4G Configuration in Windows 10 You can configure a 4G connection as below, however make sure the system is not in Airplane Mode before configuration begins. You can connect to a 4G connection in much the same way as the WLAN connection. Click the Settings item in the Start Menu and then click Network and Internet.

  • Page 203: Troubleshooting Overview

    Troubleshooting Chapter 7: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 204: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 205: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 206: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 207: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 208 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 209: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
  • Page 210 Troubleshooting Problem Possible Cause - Solution The system will not wake up from a Wake on LAN is supported in AC mode only. power saving state (Sleep/Hibernate) When the system enters a power saving state the plugged in AC/DC adapter on network activity (Wake on LAN) even should be connected, and should remain connected, in order to allow the though I have plugged in the powered...
  • Page 211 Troubleshooting Problem Possible Cause - Solution Nothing appears on screen. The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + F12 (see “Configuring the Power Buttons” on page 3 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9.
  • Page 212 Troubleshooting Problem Possible Cause - Solution The sound cannot be heard or the volume The volume might be set too low. Check the volume control in the Volume is very low. Control Panel in the Windows notification area, or use the key combination Fn + F5 and F6 (see “Keyboard Shortcuts”...
  • Page 213 Troubleshooting Problem Possible Cause - Solution The system freezes or the screen goes The system’s power saving features have timed-out. Use the AC/DC adapter, dark. press the sleep (Fn + F12) key combination, or press the power button if no LEDs are lit.
  • Page 214 Troubleshooting Problem Possible Cause - Solution The Wireless LAN/Bluetooth modules The driver(s) for the module(s) have not been installed. Make sure you have cannot be configured. installed the driver for the appropriate module (see the instructions for the appropriate module in “Modules &...
  • Page 215 Troubleshooting Problem Possible Cause - Solution When using a Bluetooth headset the This is a common issue with Bluetooth headsets. To resolve this issue do the audio appears to be mono and not following (you will need to repeat this procedure after every boot up, restart, stereo.
  • Page 216 Troubleshooting Problem Possible Cause - Solution I can’t hear any sound from the You need to enable listening to the microphone in the audio control panel in microphone in my connected headset, order to hear any sound through your connected headset as follows: when trying to test the audio playback.

  • Page 217: Resolving The "Can't Connect To This Network" Issue With The 4G Module

    Troubleshooting Resolving the “Can’t connect to this network” issue with the 4G Module If you have issues connecting to the cellular network when you are attempting to use the 4G network then you may need to manually connect to the Internet access point name (APN). Usually the Internet APN is set automatically, however if your cellular data connection isn't working, you should try manually entering a new Internet APN based on your location and mobile operator.

  • Page 218: Intel® Optane™ Notes

    Troubleshooting Intel® Optane™ Notes Intel® Optane™ is a combination of a compatible memory device and Intel Rapid Technology software. This combination is designed to speed up your system performance. However note the following; • The SATA Mode should be set BEFORE installing an operating system, and after you have backed up all necessary files and data (see sidebar).

  • Page 219: Interface (Ports & Jacks) Overview

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 220: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description 2-in-1 Audio Jack Headphones may be connected through this jack. Note: Set your system’s volume to a reduced (Headphone-Out & level before connecting to this jack. In addition this jack also functions as a S/PDIF (Sony/Philips S/PDIF-Out Jack) Digital Interface Format) Out port allowing you to connect your DVD-capable PC to a Dolby AC- 3 compatible receiver for “5.1”...
  • Page 221 Interface (Ports & Jacks) Item Description Mini DisplayPort 1.3 The Mini DisplayPorts are miniaturized versions of the DisplayPort, which is a digital display interface standard that allows a digital audio/video interconnect, between the computer and its external display or a home-theater system. ...
  • Page 222 Interface (Ports & Jacks) Item Description USB 3.1 (USB 3.1 Gen 2 These USB ports are for low-speed peripherals such as keyboards, mice or scanners, and for Type C) Ports high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 223: Control Center Overview

    Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center & Flexikey® appli- cations. Control Center gives quick access to frequently used controls and settings. Click the Control Center icons The Control Center to toggle the appropriate function, or hold the mouse button down and move the dial control where applicable.
  • Page 224  Control Center Access To run the Control Center press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar. Close the Control Center by clicking the close icon in the top right of the panel. Flexikey®...
  • Page 225 Control Center Menus The Control Center contains 5 menu headings (System Monitor, Basic Setting, LED Device, FlexiKey and Extra Setting) in the top left of the Control Center. Click the menu headings and then click any of the buttons outlined on the following pages. The LED Device menu displayed will depend on whether you have a colored LED keyboard (see page ) or white LED keyboard (see page B - 10...

  • Page 226: System Monitor

    System Monitor The System Monitor tab provides information on the computer’s GPU and CPU. Figure B - 3 - System Monitor B - 4 System Monitor...
  • Page 227 Fan Speed Setting You can set the fan speed to Maximum (full power), Automatic or Custom from this menu item. The fan speed will adjust itself automatically to control the heat of the CPU. However you can adjust the setting to maximum if you prefer.
  • Page 228 Fan Speed - Max-Q (System Program) If your NVIDIA video adapter supports Max-Q (check with your distributor/supplier) technology you can set the fan to Max-Q. When the Max-Q setting is en- abled, and the system is operating within suitable power/performance parameters, the GPU will consume less power, produce less heat, and therefore the fans will not need to spin so much, resulting in a quieter system.

  • Page 229: Basic Setting

    Basic Setting The Basic Setting allows you to adjust the power mode and other system features. Figure B - 6 - Basic Setting & Power Modes Power Modes You can set a Power Mode by clicking the appropriate icon in the center of the Control Center. Each pow- er mode will affect Airplane Mode and PC camera power.
  • Page 230 Power Status The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness The Brightness icon will show the current screen brightness level.
  • Page 231 Caps Lock/Scroll Lock/Number Lock/Airplane Mode Click the button to toggle the appropriate lock mode and Airplane Mode. Note that Airplane Mode is not an indicator, and is not intended to display the current status (check the LED indicator), but a toggle and can be overridden by one of the power modes. Basic Setting B - 9...

  • Page 232: Led Device Menu - Colored Led Keyboards

    LED Device Menu - Colored LED Keyboards The Keyboard Backlight LED Device application can be accessed by pressing the Fn plus key (or by clicking LED Device in the top left of the Control Center). Use the KB Sleep Timer to select the amount of time the system for which the system is idle before the keyboard LED enters sleep mode (i.e.
  • Page 233 Color Swatch The color swatch in the middle of the screen allows you to select a range of colors for your keyboard backlight by clicking on the color required. Click to select any colors from the swatch to apply to the whole keyboard (un- der Keyboard All) or parts of the keyboard (under Keyboard Partial).
  • Page 234 LED Mode - Keyboard All/Keyboard Partial Click either of the headings on the left under LED Mode (Keyboard All or Keyboard Partial) to select how the colors will be applied. • Keyboard All - Simply click a color from the outer band of the swatch, or click one of the color mixes from the center of the swatch and it will be immediately applied to the whole keyboard.
  • Page 235 Keyboard Effects Click on Keyboard Effect (under LED Mode) and then click any of the Effect buttons to view the effects on the keyboard. Wave Breath Cycle Random Flash Dance Tempo Figure B - 10 - Keyboard Effects LED Device Menu - Colored LED Keyboards B - 13...

  • Page 236: Led Device Menu - White Led Keyboards

    LED Device Menu - White LED Keyboards Enable and then select the amount of time the system for which the system is idle before the keyboard LED en- ters sleep mode (i.e. the LED keyboard illumination will turn off to save power). You can also adjust the key- board brightness.

  • Page 237: Extra Setting

    Extra Setting The Extra Setting tab allows you to adjust the app skin color to your choice. Figure B - 12 - Extra Setting Extra Setting B - 15...

  • Page 238: Flexikey® Application

    Flexikey® Application Click FlexiKey in the top left of the Control Center to access the Flexikey® application. You can use the Fn + Backspace key combination to toggle the Flexikey® application on and off. Profiles The controls at the top right side of the application relate to Profiles. You can Add/Delete Profiles (you can maintain 12 active Profiles), Export and Import profiles by clicking on the appropriate icon.

  • Page 239: Flexikey® Application Features

    Flexikey® Application Features • EXPRESS KEY - This feature allows you to configure a single key to send multiple key combinations or to create more useful shortcut keys. This is useful in gaming or when using applications which have a complex set of keyboard shortcuts.

  • Page 240: Enabling Or Disabling Flexikey

    Enabling or Disabling Flexikey® You can enable or disable Flexikey® (and therefore any hotkeys or mouse profile functions currently in use) by using the Fn + Backspace key combination. Pressing this key combination will toggle you between the currently selected keyboard or mouse profile to the standard keyboard and/or mouse settings, and back again. An on screen icon will also pop-up to display the status of the application as it is toggled on/off.

  • Page 241: Keyboard Settings

    Keyboard Settings The keyboard settings allow you to configure actions for any single key (or a combination of keys). Click the key and then select the action type (Express Key, Launch App, Express Text or Disable) from the menu at the top of the page.

  • Page 242: Mouse Settings

    Mouse Settings When an external mouse is attached, the mouse settings allow you to configure actions for the left , right and middle buttons of the attached mouse, and also for any backward and forward buttons if appli- cable (on a gaming type mouse). Click the button number and then select the action type (Express Key, Launch App, Express Text or Disable) from the menu.

  • Page 243: Keyboard Settings - Express Key

    Keyboard Settings - Express Key To configure a single key to send multiple key combinations, or to create more useful shortcut keys, use Express Key. Enable and select the keyboard under your chosen profile, click on the chosen key to select it, and then click to select Express Key.
  • Page 244 In the following example we want to change an existing game key configuration which uses the left shift key for sprinting, and the W key for moving forwards, to use the left Ctrl key to combine this movement to sprint forward.
  • Page 245 Enabling Delay Time If you want to create a delay between key presses within the key combination, then you can use Enable Delay Time function to do so. Enable and select the keyboard under your chosen profile, click on the chosen key to select it, and then click to select Express Key.
  • Page 246 You can edit the delay between key presses by clicking in the Delay Time (MS) field and typing a new number for the delay between the key presses. Figure B - 20 - Time Record Between Key Presses If you want to remove any individual key click to select it, and then click the delete symbol.

  • Page 247: Keyboard Settings - Launch App

    Keyboard Settings - Launch App You can configure keys to launch any application or program as follows: Enable and select the keyboard under your chosen profile, click to select a key to launch the application, and then click to select Launch App. Click Browse...
  • Page 248 Navigate to the executable file of the application and click Open. The key will now be configured to open the selected application under your chosen Profile, and the key will appear in red. Figure B - 22 - Macro Keyboard - Key Set to Launch App If you want to remove any Launch App Key, select it and click on Restore.

  • Page 249: Keyboard Settings - Express Text

    Keyboard Settings - Express Text A single key can be set to send a string of text within any application using Express Text. Enable and select the keyboard under your chosen profile, click to select a key, and then click to select Express Text.
  • Page 250 Click the Record button in Send and press the keys to use if required (the Send key is the key used to in your target program to send a text message e.g the Enter key would be the most commonly used), or you can leave it blank if you prefer.

  • Page 251: Keyboard Settings - Disable

    Keyboard Settings - Disable You can use the program to disable any keys not required. Enable and select the keyboard under your chosen profile, click to select a key to disable, and then click to select Disable. The key will now be disabled. If you want to enable the key again, select it and click on Restore.

  • Page 252: Mouse Settings - Express Key

    Mouse Settings - Express Key To assign a mouse button click to send multiple key combinations (an external mouse must be attached), or to create more useful shortcut keys, use Express Key. Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Express Key.
  • Page 253 Click the Record button and then press the key or keys (in this case we will press Left Shift and W) required (make sure you press the key(s) required and do not click on them). Click the Record button again to complete the process and stop recording. Click on the key, and then click in the Tool Tips field and type to give the key combination a name e.g.

  • Page 254: Mouse Settings - Launch App

    Mouse Settings - Launch App You can assign a mouse button click to launch any application or program as follows: Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Launch App.
  • Page 255 Navigate to the executable file of the application and click Open. The mouse click will now be configured to open the selected application under your chosen Profile, and the button will appear in red. Figure B - 27 - Macro Mouse - Button Set to Launch App Mouse Settings - Launch App B - 33...

  • Page 256: Mouse Settings - Express Text

    Mouse Settings - Express Text A mouse button click can be set to send a string of text within any application using Express Text. Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Express Text.
  • Page 257 Click the Record button in Send and press the keys to use if required (the Send key is the key used to in your target program to send a text message e.g the Enter key would be the most commonly used), or you can leave it blank if you prefer.

  • Page 258: Mouse Settings - Disable

    Mouse Settings - Disable You can use the program to disable any mouse button clicks if not required. Enable and select the mouse under your chosen profile, click on a mouse button to select it, and then click to select Disable. The button click will now be disabled.

  • Page 259: Statistics

    Statistics The Statistics tab allows you to record keys used in any application, and to disable any infrequently, or unused, keys to save any accidental incorrect key presses. Click the Statistics Tab, and press the Record button to start recording the frequency of key presses for keys used. You can then go to the application for which you wish to use the profile, and use the application as per normal so that a standard set of keys used may be recorded.
  • Page 260 B - 38...

  • Page 261: Video Driver Controls Overview

    Video Driver Controls Appendix C: Video Driver Controls Overview  The basic settings for configuring the LCD are outlined in “Video Features” on Video Card Options page 1 - 26. The basic video features for this computer can be configured using the Intel(R) HD Graphics Control Panel, Windows Display Settings or NVIDA con- Note that card types, trol panel.

  • Page 262: Microsoft Hybrid Graphics

    Video Driver Controls Microsoft Hybrid Graphics Most notebook computers come with either a discrete or integrated graphics solu- tion. Discrete graphics solutions feature a dedicated Graphics Processing Unit (GPU) which are capable of playing games, watching HD video or running GPU-based ap- plications.
  • Page 263 Video Driver Controls How Switchable Technology works When the system is powered up and is displaying just the desktop, the dGPU will be powered off. In this case the system is running in the same way as a system without a discrete graphics solution.

  • Page 264: Video Driver Installation

    Video Driver Controls Video Driver Installation  Intel Video (VGA) Video Card Options 1. Click 2.Install Intel VGA Driver > Yes. 2. Click Next > Yes > Next > Next. Note that card types, specifications and driv- 3. Click Finish to restart the computer. ers are subject to contin- 4.

  • Page 265: Nvidia Video (Vga

    Video Driver Controls NVIDIA Video (VGA) 1. Click 3.Install NVIDIA VGA Driver > Yes. 2. Click AGREE AND CONTINUE (button) to accept the terms of the license agreement. 3. Click Next. 4. Click Close to complete the installation. Note: After installing the video driver go to the Display/Display Settings control panel to adjust the video settings to the highest resolution.

  • Page 266: Nvidia Geforce Experience

    Video Driver Controls NVIDIA GeForce Experience  If you have a working internet connection (and you will need remain connected NVIDIA GeForce to the internet to run NVIDIA GeForce Experience) you can click the NVIDIA Experience GeForce Experience desktop icon (or App) to run the application.

  • Page 267: Configure Other Displays Using Project

    Video Driver Controls Configure Other Displays Using Project You can configure attached displays from Project. Attach your display to the appropriate port, and turn it on. Press the + P (or Fn + F7) key combination. Click on any one of the options from the menu to select PC screen only, Duplicate, Extend or Second screen only.

  • Page 268: Configuring An External Display In Windows

    Video Driver Controls Configuring an External Display In Windows The System > Display Control Panel in Settings may also be used to configure dis- plays. Attach your external display to the appropriate port, and turn it on. Click the Start Menu and click Settings > System (or right-click the desktop and select Display Settings).
  • Page 269 Video Driver Controls You can configure up to 4 displays from the System > Display menu.  4 Connected Displays Note that when 4 dis- plays are connected, only 2 displays may be configured in Duplicate mode. Figure C - 3 System >...

  • Page 270: Hdmi Audio Configuration

    Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Adjustment In some cases it will be necessary to go to the Sound control panel and manually The sound volume level configure the HDMI audio output as per the instructions below. can be clicking using the Go to the Sound control panel.
  • Page 271 Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure C - 5 HDMI Device Properties HDMI Audio Configuration C - 11...
  • Page 272 Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party application to play...

  • Page 273: Wireless Display

    Video Driver Controls Wireless Display  Wireless Display uses your Wireless LAN module/WLAN Bluetooth Combo mod- Compatible ule (you need to make sure that your video adapter/display device is compatible Adapters with your particular WLAN/Combo module) in conjunction with a compatible video adapter/display device (purchased separately) to allow you to display the For a list of compatible contents of the notebook display on another display (e.g.

  • Page 274: Wireless Display Configuration

    Video Driver Controls Wireless Display Configuration Note that no driver or application is required for wireless display in Windows 10. Press the + P key combination. Click Connect to a wireless display (see overleaf if this does not appear) at the bottom of the Project screen and follow the steps to connect to any wireless enabled display.
  • Page 275 Video Driver Controls Double-click any detected display device in the list. You may then need to input a pin number for the device to which you are connecting and click Next. The display will then connect (for specific settings for your display see the documentation supplied with your compatible adapter/display for full details).

  • Page 276: Nvidia Control Panel

    Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control Panel tab. Use the NVIDIA Control Panel to configure displays in Discrete mode. Access the NVIDIA Control Panel from the Start menu in Windows (or right-click the desktop and select NVIDIA Control Panel).
  • Page 277 Video Driver Controls Further menu items will appear in the NVIDIA Control Panel in Discrete mode, pro-  viding additional video configuration controls and tools which give access to fea- tures such as display configuration, 3D Settings etc. Navigating the Control Panel Navigate through the control panels in much...
  • Page 278 Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure C - 9 Help Menu C - 18 NVIDIA Control Panel...
  • Page 279 Video Driver Controls Customization Options  One of the most important aspects of hybrid technology is that it will switch between Display GPU the integrated GPU and discrete GPU seamlessly and automatically, and does not re- Activity Icon quire any input from the user. However customization options are offered for users who prefer to set their own parameters for GPU usage.
  • Page 280 Video Driver Controls Close the NVIDIA Control Panel.  Find the executable file icon of the application you want to run. Right-click the icon and select Run with graphics processor from the context iGPU or dGPU menu. Select either High-performance NVIDIA processor (dGPU) or Integrated Note the NVIDIA con- graphics (iGPU) to run the program with the selected GPU.

  • Page 281: Customization Options

    Video Driver Controls Global Settings  Global settings allows you to set the preferred graphics processor for overall use. Ideally this would be the iGPU for battery life, but this can be set to the dGPU if pre- Customization ferred. Options Go to the NVIDIA Control Panel.
  • Page 282 Video Driver Controls Program Settings Program settings allows you to make specific adjustments for installed applications. Go to the NVIDIA Control Panel. Click Manage 3D Settings (3D Settings) and select Program Settings (tab). Select a program to customize from the drop-down menu, or click Add to add any program that does not appear in the menu.

  • Page 283: Change Resolution

    Video Driver Controls Change Resolution You can Change Resolution for your attached displays from the NVIDIA control panel. Attach your external display to the appropriate port, and turn it on. Go to the NVIDIA Control Panel. Double-click Display (if the sub-menus are not visible), and then click Change resolution.

  • Page 284: Display Devices - Nvidia Cp

    Video Driver Controls Display Devices - NVIDIA CP Note that you can use an HDMI (High-Definition Multimedia Interface) cable con- nected to the HDMI-Out port and/or DisplayPort compatible cable connected to a DisplayPort 1.3 to connect an external display. See your external display device’s manual to see which formats it supports.
  • Page 285 Video Driver Controls  Display Mode Description Sound Blaster Single One of the connected displays is used as the display device Audio & HDMI Clone simply shows an exact copy of the Primary display desktop on the other Connection Clone display(s).

  • Page 286: Configuring An External Display (Nvidia

    Video Driver Controls Configuring an External Display (NVIDIA)  Clone the External Displays Display Not Shown Attach your external displays to the appropriate ports, and turn them on. If the attached display Go to the NVIDIA Control Panel. does not appear in the Double-click Display (if the sub-menus are not visible), and then click Set up “1.Select the displays multiple displays.
  • Page 287 Video Driver Controls Extending the Display  Attach your external displays to the appropriate ports, and turn them on. Go to the NVIDIA Control Panel. Changing the Double-click Display (if the sub-menus are not visible), and then click Set up Primary Display on multiple displays.
  • Page 288 Video Driver Controls The Primary display (the main window display) will be denoted by an asterisk the top right corner of the icon. To change the Primary display right-click the icon and select Make primary. Click Apply > Yes to save any changes. Figure C - 17 Switch Primary Display...
  • Page 289 Video Driver Controls You can drag the icons to match the desktop layout you want to use (e.g. you may want to extend the display to the right or left of the primary display). 10. Click Apply > Yes to save any further changes. Figure C - 18 Drag Display Icons...

  • Page 290: Hdcp Status

    Video Driver Controls HDCP Status If your external display is HDCP (High Bandwith Digital Content protection) com- patible then the NVIDIA control panel will display the HDCP system status. Figure C - 19 HDCP Status C - 30 HDCP Status...

  • Page 291: Adjust Video Settings

    Video Driver Controls Adjust Video Settings You can adjust video color and image settings from the Video sub-menus. Go to the NVIDIA Control Panel. Click “+” next to Video if its sub-items are not shown and then click either Adjust video color settings or Adjust video image settings.

  • Page 292: Configure Surround, Physx

    Video Driver Controls Configure Surround, PhysX ® NVIDIA PhysX is a physics engine that can use the GPU to accelerate game and ® ® 3D application performance. You can select the GeForce video card or CPU as a PhysX processor, or configure the computer to auto-select a PhysX processor ®...

  • Page 293: Set Digital Audio

    Video Driver Controls Set Digital Audio As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you can configure the audio output from the NVIDIA control panel and Sound control panel. The settings will depend upon the external HDMI display to which you have connected.

  • Page 294: Intel® Uhd Graphics Control Panel

    Video Driver Controls Intel UHD Graphics Control Panel ® Advanced video configuration options are provided by the Intel UHD Control ® Panel. Access the Intel Graphics Control Panel from the Start menu in Windows. Figure C - 23 Intel Graphics Control Panel (Windows Start Menu)
  • Page 295 Video Driver Controls You can right-click the Intel Graphics Control Panel in the Start menu and pin the control panel to the taskbar. Figure C - 24 Intel Graphics ® Control Panel (right-click to Pin to taskbar) Use the Ctrl + Alt + F12 key combination shortcut to open the Intel Graphics Control Panel.
  • Page 296 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu panel and adjusting the settings from the menus. Home Click the Home button to return to the main menu screen in any of the sub- menu screens.
  • Page 297 Video Driver Controls Display Click either Display Settings or Color Settings to make display adjustments, in- cluding configuration for any attached external displays.  Configuring External Displays Figure C - 26 Intel ® UHD When a single external display is Graphics attached to the HDMI or Display Ports, use the Display (page...
  • Page 298 Video Driver Controls The Custom Resolutions sub-menu allows you to adjust the display (or any at- tached display) to any width, height, refresh rate, color depth and underscan percent- age of your choice. Note that incorrect settings can cause system instability and even possible component damage, so this is adjusted at your own risk.
  • Page 299 Video Driver Controls This menu allows you to choose how 3D images are displayed. Performance gives the smoothest motion of images, Quality displays the most detail, Balanced Mode provides better computer performance with good quality and Custom allows you to configure the Anisotropic Filtering and Vertical Sync and features to your prefer- ences.
  • Page 300 Video Driver Controls Options and Support Hot Key Manager in Options and Support allows you to create hot keys for open- ing the application, rotating the display, scaling etc. Click Apply to save changes. Figure C - 29 Intel ® HD Graphics Control Panel Options and Support...
  • Page 301 Video Driver Controls Click the Options menu at the top of the screen to display the sub-menus. The In- formation Center provides details on System Information, the Built-In Display and any attached displays. Figure C - 30 Intel ® UHD Graphics Control Panel Options -...
  • Page 302 Video Driver Controls Video The Video menu allows you to brighten or darken movies, or to switch to vivid col- ors. The Preview image will display a sample image using the current settings. You can Save Profile and name the Profile to recall the settings at any time. Click Apply to save changes (select Color Enhancement, Image Enhancement, Image Scaling or Gamut Mapping from the menu).
  • Page 303 Video Driver Controls Click the Video menu at the top of the screen to display the sub-menus.The Image Enhancement menu allows you to adjust the Sharpness, Skin Tone Enhance- ment, Noise Reduction, Contrast Enhancement and Film Mode Detection. Click Apply to save changes. Figure C - 32 Intel ®...
  • Page 304 Video Driver Controls Power The battery life can be extended through dynamic control of the frame rate if Ex- tended Battery Life for Gaming is enabled. Settings can be selected for when the system is powered by battery or is plugged in. Figure C - 33 Intel ®...
  • Page 305 Video Driver Controls Profiles You can select one of the preset profiles (Brighten Video, Darken Video and En- hance Video Colors) from the menu on the left. Alternatively you can go through the menus to make adjustments to your preferences for Display, Color, Video, Op- tions and Support and Power (tick any boxes for the settings required), and then Save the settings to a profile (which may be imported or exported).
  • Page 306 Video Driver Controls C - 46...

  • Page 307: Specifications

    Specifications Appendix D: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your distributor/supplier for details.

  • Page 308: Core Logic

    Specifications Core Logic Pointing Device & Keyboard  Mobile Intel® HM370 Express Chipset Full Size White Illuminated LED Keyboard SO-DIMM Memory Types with Numeric Pad All SO-DIMM memory modules installed in the Display Full Size Color Illuminated LED Keyboard system should be identical (the same size and brand) in order to prevent unexpected system with Numeric Pad - (Option) 15.6”...

  • Page 309: Card Reader

    Specifications Card Reader Intel® Dual Band Wireless-AC 9560 Security (2*2 802.11 a/c) WLAN Bluetooth M.2 *Embedded Multi-In-1 Card Reader Security (Kensington® Type) Lock Slot 2230 Combo Module (Factory Option) - MMC/ RS MMC BIOS Password Intel® Dual Band Wireless-AC 9462 - SD/ Mini SD / SDHC/ SDXC up to UHS-II Trusted Platform Module 2.0 (Factory (1*1 802.11 a/c) WLAN...

  • Page 310: Indicators

    Specifications Indicators LED Indicators - Power/Suspend, Battery, HDD, Airplane Mode, Camera BIOS One 128Mb SPI Flash ROM INSYDE BIOS Environmental Spec Temperature ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90% Dimensions &...

Table of Contents
