- Page 1 QUICK START GUIDE SPIRIT ® April 10, 2019 Copyright 2019 Lincoln Electric® Cutting Systems...
-
Page 2: Table Of Contents
Table of Contents Page: Contents Title Page Table of Contents Machine Overview, Torchmate 5100, Front Machine Overview, Torchmate 5100, Side Machine Overview, Torchmate 5100, Rear Overview, Spirit II Powering up the Torchmate 5100 Running a Job Running a Job, continued Overview, Plasma Console Overview, Plasma Console, continued Overview, Plasma Console, continued... -
Page 3: Machine Overview, Torchmate 5100, Front
Machine Overview, Torchmate 5100, Front This section will provide a brief overview of the components of your Torchmate 5100 machine Front: 1. Emergency Stop button 2. Lifter Station 3. Tool Mounting Plate 4. Gantry 5. Drive Enable button 6. Emergency Stop button 7. -
Page 4: Machine Overview, Torchmate 5100, Side
Machine Overview, Torchmate 5100, Side This section will provide a brief overview of the components of your Torchmate 5100 machine Cable Carrier Side: 1. Touchscreen/Human Machine Interface (H.M.I.) 2. Z Axis Motor 3. Remote Arc Start control box (FlexCut® 200 and Spirit II systems only) 4. -
Page 5: Machine Overview, Torchmate 5100, Rear
Machine Overview, Torchmate 5100, Rear This section will provide a brief overview of the components of your Torchmate 5100 machine Rear: 1. Touchscreen/Human Machine Interface (H.M.I.) 2. Linear Rail/Helical Gear Rack (X axis) 3. X axis servo motor 4. Cable Carrier (X axis) 5. - Page 6 Spirit II Plasma Overview The Kaliburn® Spirit II plasma cutters come as up to four separate components. A Power Supply, an Automatic Gas Control box, a Remote Arc Start console, and a Cooling Tower (Spirit II 400 only). The Remote Arc Start console comes attached to the back of the gantry, the remaining 2-3 components are positioned near the machine’s cable carrier exit.
-
Page 7: Powering Up The Torchmate 5100
Powering up the Torchmate 5100 To power up your Torchmate 5100 CNC machine, the following items need to be powered up; Machine and Plasma Unit. The machine will power the controller, computer, and touchscreen. The switch is located on the backside of the machine. Once switched on, the computer and all the electronics will power up. -
Page 8: Running A Job
Running a Job For your first machine cut, we highly recommend cutting the Factory provided test cut program, and comparing it to the sample that was cut in the factory. This will help verify that the machine is operating to factory specifications. Datum: When you first turn on the machine, it will already be configured and ready to run. -
Page 9: Running A Job, Continued
Running a job (continued) Follow the steps below to Jog the tool around the table Incremental Jog: Pressing one of the arrows on the screen will move the torch- body in the direction you are pressing, the amount of distance specified in the “Increment Distance”... - Page 10 Plasma Console Plasma Console: (Spirit II) The Spirit II plasma cutter allows you or the G-Code program to set variables for the plasma cutter. All of the plasma cut- ter buttons and information screens are only displayed on the HMI Plasma Console, there are no buttons, regulators, etc. on the Spirit II plasma cutter.
- Page 11 Plasma Console, continued View Torch Parts The View Torch Parts screen displays all 6 “consumable” portions of the Spirit II torch. The part numbers for the chosen material type and thickness are displayed when this screen is accessed. Outer Retaining Cap 2.
- Page 12 Plasma Console, continued System - Status The Status button will display the current status of the Spirit II plasma cutter to quickly determine if the machine is ready to cut. • DC Power - This light is only lit Green when the plasma cutter is actually cutting •...
- Page 13 Performing Your First Test Cut (straight torch NON BEVEL) The LINE SPEED TEST.gm and 5100 Test Cut.gm is provided to determine the proper feed rate in IPM to cut the terial thickness to the amperage you have set on the plasma power supply. These have been included in your pre-load- ed first cut on the Torchmate 5100 models.
-
Page 14: Performing Your First Test Cut, Bevel
Performing Your First Test Cut (BEVEL) The LINE SPEED TEST.gm and 5100 Test Cut.gm is provided to determine the proper feed rate in IPMs to cut the material thickness to the amperage you have set on the plasma power supply. These have been included in your pre loaded first cut on the Torchmate 5100 models. -
Page 15: Customer Assistance Policy
Lincoln Electric Cutting Systems is a responsive manufacturer, but the selection and use of specific products sold by Lincoln Electric Cutting Systems is solely within the control of, and remains the sole respon- sibility of the customer.
