- Page 1 GTTLIIP 200290 VoIP INTERFACE FOR GT SYSTEM INSTALLATION MANUAL GB358IP-1 -06.09.18– Edition notice V1.0...
- Page 2 * We will under never conditions be liable for for any damages or losses resulting from this product’s contents or specifications. 4. For power supply, use Aiphone power supply model or * Please note that images and illustrations depicted in this manual may model specified for use with system.
- Page 3 Package contents : [1] Installation manual [2] User manual [3] GTTLIIP cabinet [4] Power supply [5] Fast installation manual GTTLIIP can be installed: - on desktop or - wall mounted (use for example two screws type M3,5). GTTLIP must be installed as far as possible from humidity or heating source. 06.09.18 –...
- Page 4 State lighting ON : POWER ON OFF : POWER State lighting State GTTLIIP Led green fixed During initialization 1 flash per second Correct functioning 3 flashes per second GTTLIIP did not find an IP address (DHCP did not work). GTTLIIP started with an address 192.168.0.100 4 flashes per second GTTLIIP has no connection with proxy server 5 flashes per second...
- Page 5 1 – GTTLIIP wiring 06.09.18 – V1.0...
- Page 6 Connections Panel function: - LAN: Ethernet port, - External Power supply 12VDC +/- 10% linear regulated: position + (12VDC), - (0V). (Consumption: 380mA in work, installed not far from 3 meters from GTTLIIP). - Connection with bus on : - R1-R2 : audio cable, - B1-B2 : vidéo cable.
- Page 7 Connecting GTTLIIP system Several type of installation are available for GTTLIIP. 2 – Physical connection 2.1- Behind a modem router usually called Box by Internet provider like livebox, freebox, … Connect GTTLIIP directly on the LAN/Ethernet plug of the modem router with Ethernet straight cable (not supplied).
- Page 8 If there is no more LAN/Ethernet port available on your equipment, you will have to add a Switch 10/100Mbits/s (multiport Ethernet). 06.09.18 – V1.0...
- Page 9 2 : Enter the numbers and the names for apartments with the keypad of your panel or with the tool of configuration GT for Windows (enable on Aiphone.fr) 3 : When the panel is in sleep mode, dial # and then the administrator identification code (by default = 1111).
- Page 10 Attention if you stay pressed on the bell button, a long beep will be emitted and your interface will not be programmed. Ne maintenez pas appuyé le bouton de la sonnette sous peine d’effacer la mémoire pour ce numéro. (Bip long) 7 : Return to your interface to press on again the button GT PROG so that your interface gets out of the programming mode.
-
Page 11: Automatic Entry
2- Launch the application ‘AiphoneGT’ The welcome screen opens. 3- Automatic entry 4- Manual entry User name : GT180000_1 to GT140801_5 Password : specified on Fast installation manual Domain : sipgt.tliip.com And click on ‘Apply’ When the icon becomes green, your application is operational. You can launch a call by pressing the call button of the panel. - Page 12 4 – Advanced settings on GTTLIIP: Allows to indicate one or several e-mail addresses to receive photos further to a call of the panel. Allows to program relays and call settings. Launch your web browser (Internet Explorer, Firefox, …) and in the address field of browser, enter ‘http://gt.tliip.com’.
- Page 13 The welcome screen of GTTLIIP appears: The screen displays information onto the state of the connections with the proxy and with the server Astérisk. 4.1-E-mail address programming (Click on ‘Resident’) To enter an E-mail address to receive photo during a call, click on ‘Resident’. If you select ‘Always’...
- Page 14 To modify the parameters for relays of GTTLIIP, click Timing’. The following page appears: 4.2-Programming of operating parameters (Click on Timing) This window allows the programming of parameters for relays and calls. When the user confirms the option 'Terminate Call on Contact', the communication will end after the opening of the door.
- Page 15 • Operating temperature: 0°C - 40°C (32°F – 104°F). • Cleaning: use a soft duster with neutral detergent. Do not use cleaner or duster abrasive. • Dimensions : 9,5 x 7,1 x 2,17 (h) inch. • Weight : 0,4 pounds Connections : (1) Ethernet Network (2) GT Bus...
- Page 16 Photos and descriptions not contractual Distributed by AIPHONE Printed in France 06.09.18 – V1.0...
