SERVICE MANUAL
Ver 1.0 2003. 03
• LBT-XGR88 is composed of following models.
As for the service manual, it is issued for each component model, then, please refer to it.
COMPONENT MODEL NAME FOR LBT-XGR88
COMPACT DISC DECK RECEIVER SYSTEM
SPEAKER SYSTEM
SPECIFICATIONS
General
Power requirements:
120V, 220V or
230 – 240 V AC, 50/60 Hz
Adjustable with voltage selector
Power consumption:
330 watts
Dimensions (w/h/d) (Main Unit):
Approx. 355 x 425 x 451 mm
Mass (Main Unit):
Approx. 17.0 kg
Supplied accessories:
AM loop antenna (1)
FM lead antenna (1)
Speaker cords (4)
Speaker pads (8)
Remote Commander (1)
Batteries (2)
Design and specifications are subject to change without notice.
Sony Corporation
9-877-209-01
2003C0200-1
Home Audio Company
Published by Sony Engineering Corporation
© 2003.03
LBT-XGR88
LBT-XGR88
HCD- XGR88
SS-XGR88
PARTS LIST
Part No.
1-477-078-11
1-501-374-12
1-751-347-11
1-775-512-32
1-793-184-22
4-210-254-02
4-228-953-01
4-245-987-11
4-245-987-21
4-245-987-31
COMPONENT Hi-Fi STEREO SYSTEM
Description
ACCESSORIES
***********
COMMADER, STANDARD (RM-SR6)
ANTENNA, LOOP (AM)
CORD, SPEAKER (2.5m)
CORD, SPEAKER CONNECTION (1.5m)
CONNECTOR (F TYPE ADAPTOR)
CUSHION (FOOT)
COVER, BATTERY (for RM-SR6)
OPERATING INSTRUCTIONS (ENGLISH)
OPERATING INSTRUCTIONS (FRENCH)
OPERATING INSTRUCTIONS (SPANISH)
http://getMANUAL.com
E Model
Remark
