Sony LBT-XGR600 Parts List

LBT-XGR66/XGR600
SERVICE MANUAL
Ver 1.0 2003. 03
• LBT-XGR66/XGR600 are composed of following models.
As for the service manual, it is issued for each component model, then, please refer to it.
COMPONENT MODEL NAME FOR LBT-XGR66/XGR600
COMPACT DISC DECK RECEIVER SYSTEM
SPEAKER SYSTEM
SPECIFICATIONS
General
Power requirements
North American models: 120 V AC, 60 Hz
Other models: 120 V, 220 V or
230 – 240 V AC, 50/60 Hz
Adjustable with voltage selector
Power consumption
USA models:
LBT-XGR600: 190 watts
Other models:
LBT-XGR66: 290 watts
Dimensions (w/h/d) (Main Unit) Approx. 355 x 425 x 451 mm
Mass (Main Unit)
LBT-XGR600: Approx. 13.0 kg
LBT-XGR66: Approx. 15.1 kg
Supplied accessories: AM loop antenna (1)
FM lead antenna (1)
Speaker cords (2)
Speaker pads (8)
Remote Commander (1)
Batteries (2)
Design and specifications are subject to change without notice.
Sony Corporation
9-877-212-01
2003C0200-1 Home Audio Company
Published by Sony Engineering Corporation
© 2003.03
LBT-XGR66 LBT-XGR600
HCD-XGR66 HCD-XGR600
SS-XGR66 SS-XGR600
PARTS LIST
Part No.
1-477-078-11
1-501-374-12
1-775-512-32
1-793-184-22
4-210-254-02
4-228-953-01
4-245-987-11
4-245-987-21
4-245-987-31
COMPONENT Hi-Fi STEREO SYSTEM
US Model
Description
ACCESSORIES
************
COMMADER, STANDARD (RM-SR6)
ANTENNA, LOOP (AM)
CORD, SPEAKER CONNECTION (1.5m)
CONNECTOR (F TYPE ADAPTOR)
CUSHION (FOOT)
COVER, BATTERY (for RM-SR6)
OPERATING INSTRUCTIONS (ENGLISH)
OPERATING INSTRUCTIONS (FRENCH) (XGR66)
OPERATING INSTRUCTIONS (SPANISH) (XGR66)
http://getMANUAL.com
LBT-XGR600
E Model
LBT-XGR66
Remark
