  • Page 1 Prestige Series LCD Monitor Prestige PS341WU (3DA1)
  • Page 2: Table Of Contents

    Contents Copyright and Trademarks Notice ��������������������������������������������������������������������������iii Revision ������������������������������������������������������������������������������������������������������������������iii Technical Support ���������������������������������������������������������������������������������������������������iii Safety Instructions ���������������������������������������������������������������������������������������������������iv CE Conformity ���������������������������������������������������������������������������������������������������������vi FCC-B Radio Frequency Interference Statement ���������������������������������������������������vi WEEE Statement ���������������������������������������������������������������������������������������������������vii Chemical Substances Information �������������������������������������������������������������������������vii RoHS Statement ����������������������������������������������������������������������������������������������������vii Getting Started �������������������������������������������������������������������������������1-1 Package Contents ������������������������������������������������������������������������������������������������ 1-2 Installing the Monitor Stand ����������������������������������������������������������������������������������...
  • Page 3: Copyright And Trademarks Notice

    Preface Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co�, Ltd� All rights reserved� The MSI logo used is a registered trademark of Micro-Star Int’l Co�, Ltd� All other marks and names mentioned may be trademarks of their respective owners� No warranty as to accuracy or completeness is expressed or implied�...
  • Page 4: Safety Instructions

    Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the device or user’s manual should be noted� ◙ Refer servicing to qualified personnel only. Keep the User’s Guide that comes with the package for future reference� To prevent fire or shock hazard, keep this device away from humidity and high temperature�...
  • Page 5 Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper disposal, take-back, recycling, and disassembly of MSI products�...
  • Page 6: Ce Conformity

    1� this device may not cause harmful interference, and 2� this device must accept any interference received, including interference that may cause undesired operation� MSI Computer Corp� 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www�msi�com...
  • Page 7: Weee Statement

    Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products�...
  • Page 9: Getting Started

    Getting Started This chapter provides you with the information on hardware setup procedures� While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity� IMPORTANT The illustrations are for reference only� Your monitor may vary in appearance�...
  • Page 10: Package Contents

    Package Contents 1� Monitor 2� Stand 3� Stand Base with Screw 4� Wall Mount Screws x4 5� Stand Screws x4 6� Power Cord 7� HDMI Cable 8� Type C Cable 9� DisplayPort Cable 10� Y-type Audio Cable 11� USB Upstream Cable (to enable the USB ports on the monitor) 12�...
  • Page 11: Installing The Monitor Stand

    Getting Started Installing the Monitor Stand IMPORTANT • Place the monitor on a soft, protected surface to avoid scratching the display panel� • Avoid pressing the monitor when installing the monitor stand�...
  • Page 12 1� Align the latches of the stand to the monitor� 2� Tighten the stand with the stand screws� 3� Connect the base to the stand and tighten the base screw to secure the base� IMPORTANT The holes for installing the stand can be also used for wall mount� Please contact your dealer for proper wall mount kit�...
  • Page 13 Getting Started 4� Adjust the angle of the stand� Align the latches to place the VESA cover and I/O cover�...
  • Page 14: Adjusting The Monitor

    Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment apabilities� IMPORTANT • Do not use any sharp objects on the monitor� • Avoid touching the display panel when adjusting the monitor� 100mm...
  • Page 15: Monitor Overview

    Getting Started Monitor Overview...
  • Page 16 Power Jack HDMI 2�0 Port DisplayPort 1�4 USB-C Port This port can send simultaneously video signal and power stream up to 5V/3A� It doesn’t support data transmition function� USB3�1 Gen1 Type B Upstream Port For USB Upstream Cable� IMPORTANT To Monitor Check the package for USB Upstream Cable and connect it to the PC and monitor�...
  • Page 17 Getting Started Headphone Jack Navi Key Kensington Lock Macro Key To activate Creator OSD� Power Button Magnetic Area Cord Sleeve Paperweight...
  • Page 18: Connecting The Monitor To Pc

    Connecting the Monitor to PC 1� Turn off your computer. 2� Connect the HDMI/DisplayPort cable from the monitor to your computer� 3� Connect the power cord to the monitor power jack� (Figure A) 4� Plug the power cord into the electrical outlet� (Figure B) 5�...
  • Page 19: Getting Started

    Getting Started This chapter provides you with the information on hardware setup procedures� While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity� IMPORTANT The illustrations are for reference only� Your monitor may vary in appearance�...
  • Page 20: Navi Key

    Navi Key The monitor comes with a Navi Key, a multi-directional control that helps navigate the On-Screen Display (OSD) menu� Navi Key The Navi Key default settings are as follows� Hot Key Basic Operations Navi Key (When OSD menu is OFF) (When OSD menu is ON) OSD Main Menu ■...
  • Page 21 OSD Setup Hot Key Basic Operations Navi Key (When OSD menu is OFF) (When OSD menu is ON) Pro Mode ■ Press Middle Button ■ Selecting function to confirm selection menus and items and exit� ■ Allowing upward ■ Press Up and Down adjustment in function Buttons to adjust�...
  • Page 22 Users may enter the OSD Menu to customize their own Navi Key Hot Keys. More Hot Key options are as below� Navi Key Hot Key Options Operations Brightness ■ Press Middle Button to save value and exit� ■ Press Up and Down Buttons to adjust� ■...
  • Page 23: Osd Setup Via Navi Key

    OSD Setup OSD Setup via Navi Key Press the Middle button of Navi Key to launch the On-Screen Display (OSD) main menu� Use the Up, Down, Left, Right buttons to tune the desired function menus to suit your personal preferences� h Professional 1st Level Menu 2nd/ 3rd Level Menu...
  • Page 24 1st Level Menu 2nd/ 3rd Level Menu Description Alarm Clock Location Left Top ■ Users can adjust Alarm Clock in any Mode� Right Top ■ After setting the time, press the Middle Left Bottom Button to activate the timer� Right Bottom ■...
  • Page 25 OSD Setup 1st Level Menu 2nd/ 3rd Level Menu Description Image Enhancement OFF ■ Image Enhancement enhances image edges to improve their acutance� Weak ■ Users can adjust Image Enhancement Medium in any Mode� Strong Strongest Response Time Normal ■ Users can adjust Response Time in any Mode�...
  • Page 26 1st Level Menu 2nd/ 3rd Level Menu Description Saturation 0-100 ■ Default is 50 for all Saturation items shipment setting, end user can adjust Green 0-100 these flexibility, unless otherwise Blue 0-100 specified. Cyan 0-100 ■ Default is 0 for the Black-White mode Magenta 0-100 only�...
  • Page 27 OSD Setup h PIP/PBP 1st Level Menu 2nd Level Menu Description ■ Default is OFF for shipment setting, end user can adjust it flexibility, unless otherwise specified. Source ■ While Audio Switch function implement, the Audio PIP Size Source will changed to Digital� Location ■...
  • Page 28 h Setting 1st Level Menu 2nd Level Menu Description Language 繁體中文 ■ Language factory default is English� ■ Users have to press the Middle Button to confirm English and apply the Language setting� Français ■ Language is an independent setting� Users’ own Deutsch language setting will override the factory default�...
  • Page 29: Appendix

    Appendix IMPORTANT All information is subject to change without prior notice�...
  • Page 30: Specifications

    Specifications Model Prestige PS341WU (3DA1) Size 34 inch Panel Type Resolution 5120 x 2160 @60Hz Aspect Ratio 21:9 Brightness (nits) 450 (VESA Certified DisplayHDR™ 600) Contrast Ratio 1200:1 Refresh Rate 48~60Hz Response Time Input Interface ■ HDMI Port 2.0 x2 ■...
  • Page 31 Appendix Model Prestige PS341WU (3DA1) Environment Operating Temperture: 0°C to 40°C Humidity: 20% to 90%, non-condensing Altitude: 0 ~ 5000m Storage Temperture: -20°C to 60°C Humidity: 10% to 90%, non-condensing * Based on CIE1976 test standards.
  • Page 32: Preset Display Modes

    Preset Display Modes Prestige PS341WU (3DA1) Resolution HDMI 1/ 2 Type C 640 x 480 @ 60Hz 800 x 600 @ 60Hz 1024 x 768 @ 60Hz 1152 x 864 @ 60 Hz 1280 x 720 @ 60 Hz 1280 x 800 @ 60 Hz 1280 x 960 @ 60 Hz 1280 x 1024 @ 60 Hz 1600 x 1000 @ 60 Hz...
  • Page 33: Troubleshooting

    Appendix Troubleshooting The power LED is off. ■ Press the monitor power button again� ■ Check if the monitor power cable is properly connected� No image� ■ Check if the computer graphics card is properly installed� ■ Check if the computer and monitor are connected to electrical outlets and are turned on�...
