Controls

Features and appearance will vary.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
A
Controls
A. Timer Button
Program a time from (1-hour to 24-hours) for the air
conditioner to turn Off or On. When a Time Delay is
programmed, the Timer indicator light will illuminate.
While the air conditioner is operating:
1. Press the Timer button.
2. Press the Up/Down arrow buttons to select the
number of hours you want the air conditioner to
continue to operate before turning Off.
NOTE: Wait approximately 5 seconds for the Turn-Off
time to be saved.
While the air conditioner is off:
1. Press the Timer button.
2. Press the Up/Down arrow buttons to select the
number of hours you want the air conditioner to
remain off before turning On.
NOTE: Wait approximately 5 seconds for the Turn-On
time to be saved.
To cancel the timer:
• Press the Timer button once, the hours remaining will
flash, press the timer button again and the timer will
be canceled.
B. Fan Speed Button
The fan speed can be adjusted from Low speed to
High speed when the air conditioner is either in Cool
or Fan mode.
NOTE: The fan speed cannot be adjusted when the
unit is in DEHUM mode.
• Press the Fan Speed button to toggle among the two
speeds. The corresponding fan speed indicator will
illuminate.
C. Remote Control Signal Receiving Window
Aim the Remote Control at this window so the Control
will receive the signal.
D. CONTROL PANEL DISPLAY
Displays the Set Temperature in degrees Fahrenheit
or degrees Celsius, or the hours remaining in a
Time Delay. The corresponding indicator light will
illuminate.
E. Up and Down Arrow Buttons
Adjusts the Temperature or Hours in Time Delay.
4
D
C
B
E
G
F
To Set the Temperature:
The temperature can be set between 62ºF and 86º F
(17ºC and 30º C) when the air conditioner is in Cool
mode.
1. Press the Mode button until the Cool mode is
selected.
2. Press the Up Arrow or Down Arrow buttons to select
the Temperature.
NOTE: The temperature cannot be set when the air
conditioner is in either Fan or Dry mode.
F. Mode Button
Press the Mode button to toggle among the operating
options. The corresponding indicator will illuminate:
Cool – Cools the room to the set temperature
ECO – Cycles fan to cool economically
Dehum – Reduces the humidity in the room
Fan – Circulates the air in the room without cooling
G. Power Button
Turns ON/OFF power to the air conditioner.
NOTE: Turning o power by pressing the Power button
does NOT disconnect the appliance from the power
supply.
• Press the Power button. The Power indicator will
illuminate.
REMOTE CONTROL
1. Insert the two batteries (provided).
2. Aim the remote control at the signal receiver on the
control panel to operate the air conditioner.
H. Sleep Button
Increases the set temperature by 2ºF (1ºC) after
2-hours, and then increases the temperature by an
additional 2ºF (1ºC) after another 2-hours.
NOTE: The fan will operate at Low speed and cannot
be adjusted while in Sleep mode. Press the Sleep
button to enter Sleep mode. The Sleep indicator will
illuminate.
To Cancel Sleep Mode:
• Press the Sleep button or the Mode button (Cool, Fan
or Dry) on the remote control.
I. ºC/ºF Button
• Press the ºC/ºF button to toggle between displaying
the temperature in degrees Fahrenheit or degrees
Celsius. The corresponding indicator will illuminate.
High Cool
H
Low TEMP Dehum
I
Sleep Fan
C / F
TIMER POWER
49-5000135
