Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
Name / Model #1: HP Compaq dx2300 Business PC
Name / Model #2
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
EL-MF877-00
Template Revision A
Notes
With a surface greater than 10 sq cm
All types including standard alkaline and lithium coin
or button style batteries
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
Quantity
of items
included
in product
2 (1 sys
board, 1
P/S PCA
1
8, 11, or 6
Page 1

Advertisement

loading

Summary of Contents for HP Compaq dx2300

  • Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
  • Page 2: Power Supply

    Remove the four screws that secure the power supply to the chassis (1). b. Slide the power supply toward the front of the computer, and then lift it out of the computer. HP uses three different power supply vendors. See the instructions below to disassemble and remove required power supply components: POWER SUPPLY 1: a.
  • Page 3 g. Cut 11 capacitors from the PCA, as shown in Figure 14. POWER SUPPLY 3: a. Using dikes, cut the two plastic cable clamps that secures the cables to the power supply cover (see Figure 15). b. Using a phillips screwdriver, remove the six screws from the bottom that secure the cover to the power supply chassis (see Figure 15).
  • Page 4 FIGURE 1: Removing the access panel. FIGURE 2: Removing the system board FIGURE 3: Type 1 battery holder EL-MF877-00 Page 4 Template Revision A...
  • Page 5 FIGURE 4: Type 2 battery holder FIGURE 5: Type 3 battery holder FIGURE 6: Removing the power supply EL-MF877-00 Page 5 Template Revision A...
  • Page 6 FIGURE 7:POWER SUPPLY 1: Plastic cable clamp and screw locations FIGURE 8: POWER SUPPLY 1: Power supply cover screw locations FIGURE 9: POWER SUPPLY 1: Power supply PCA screw locations EL-MF877-00 Page 6 Template Revision A...
  • Page 7 FIGURE 10: POWER SUPPLY 1: Capacitors (8) to cut FIGURE 11: POWER SUPPLY 2: Plastic cable clamp and cover screw locations FIGURE 12: POWER SUPPLY 2: Plastic cable clamp and cover screw locations EL-MF877-00 Page 7 Template Revision A...
  • Page 8 FIGURE 13: POWER SUPPLY 2: Power supply PCA screw locations FIGURE 14: POWER SUPPLY 2: Capacitors (11) to cut EL-MF877-00 Page 8 Template Revision A...
  • Page 9 FIGURE 15: POWER SUPPLY 3: Plastic cable clamp and cover screw locations FIGURE 16: POWER SUPPLY 3: Power supply PCA screw locations EL-MF877-00 Page 9 Template Revision A...
  • Page 10 FIGURE 17: POWER SUPPLY 3: Capacitors (6) to cut EL-MF877-00 Page 10 Template Revision A...
