4-239-335-12 (2)
Micro Hi-Fi
Component
System
Operating Instructions
Owner's Record
The model and serial numbers are located on the bottom of the unit. Record the serial
number in the space provided below. Refer to them whenever you call upon your Sony
dealer regarding this product.
Model No. _______________
Serial No. _______________
CMT-EP303
CMT-EP305
© 2002 Sony Corporation
Advertisement
Table of Contents
Related Manuals for Sony CMT-EP305
Summary of Contents for Sony CMT-EP305
-
Page 1: Operating Instructions
Owner’s Record The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. _______________ Serial No. - Page 2 WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. Do not install the appliance in a confined space, such as a bookcase or built-in cabinet.
-
Page 3: Table Of Contents
Table of Contents List of Button Locations and Reference Pages Main unit ... 4 Remote control ... 5 Getting Started Hooking up the system ... 6 Inserting two size AA (R6) batteries into the remote ... 7 Setting the clock ... 7 Loading the CD ... -
Page 4: List Of Button Locations And Reference Pages
List of Button Locations and Reference Pages How to use this page Use this page to find the location of buttons and other parts of the system that are mentioned in the text. Main unit ALPHABETICAL ORDER A – P Cassette compartment qd (12) CD 4 (8, 9, 13) Display Window 5 (8, 9, 10) -
Page 5: Remote Control
Remote control ALPHABETICAL ORDER A – P CD/REMAIN ql (7, 8, 9, 13, 15, CLOCK/TIMER + 8 (7, 14, 15) CLOCK/TIMER – qd (7, 14, 15) CLOCK/TIMER/SLEEP SET 1 (7, 14, 15) MEGA BASS qs (14) MUSIC MENU qa (14) MUTING q;... -
Page 6: Getting Started
Getting Started Hooking up the system Do the following procedure 1 to 2 to hook up your system using the supplied cords and accessories. FM antenna Front speaker (Right) 1 Connect the front speakers. Connect the speaker cords to the SPEAKER terminals as shown below. -
Page 7: Inserting Two Size Aa (R6) Batteries Into The Remote
Inserting two size AA (R6) batteries into the remote When the remote no longer operates the system, replace both batteries with new ones. Note If you do not use the remote for a long period of time, remove the batteries to avoid possible damage from battery leakage. -
Page 8: Loading The Cd
Loading the CD Press Z PUSH OPEN/CLOSE down to open the lid of the CD compartment. Place a CD with the label side up on the compartment. Press Z PUSH OPEN/CLOSE down to close the lid of the CD compartment. Playing the CD —... -
Page 9: Programing The Cd Tracks
Programing the CD tracks — Program Play You can make a program of up to 28 tracks in the order you want them to be played. Press CD (CD/REMAIN on the remote), then place a CD. Press ENTER/PGM (TUNER MEM/ ENTER/PGM on the remote) repeatedly until “00 PR.01”... -
Page 10: Tuner
Tuner Presetting radio stations You can preset up to 24 stations for FM and AM. You can then tune in any of those stations simply by selecting the corresponding preset number. There are two ways to store the station presets. Automatically tune all of the stations that can be received in your area and then store them... -
Page 11: Listening To The Radio
Other Operations Do this Tune in a station with a Follow the procedure weak signal described in “Setting presets through manual tuning”. Change the preset Start over from step 1. number Set another station to Start over from step 1. an exsisting preset After step 3, press number... -
Page 12: Tape
Tape Loading a tape Press xZ . Insert a tape in deck with the side you want to play/record facing forward. Insert with the side you want to play/ record facing forward. Playing a tape You can use TYPE I (normal) tape. Load a recorded tape. -
Page 13: Recording To A Tape
Recording to a tape — CD Synchro Recording/Recording Manually You can record from a CD or radio. You can use TYPE I (normal) tape. Steps Recording from a CD (CD Synchro Recording) Load a blank tape. Press CD (CD/REMAIN on the remote). Load the CD you want to record. -
Page 14: Sound Adjustment
Sound Adjustment Adjusting the sound Reinforcing the bass sound — MEGA BASS You can listen to music with stronger bass tones. Press MEGA BASS. “MEGA BASS” appears in the display and the bass is reinforced. Press again to cancel MEGA BASS. Selecting the preset effect from the music menu Press MUSIC MENU repeatedly to select... -
Page 15: Waking Up To Music
Waking up to music — Daily Timer You can wake up to music at a preset time. Make sure you have set the clock (see “Setting the clock” page 7). Prepare the sound source you want to play. • CD: Place a CD. •... -
Page 16: Display
First, check that the power cord is connected firmly and the speakers are connected correctly and firmly. Should any problem persist, consult your nearest Sony dealer. General The clock indication does not show the correct time. • A power interruption occurred. Set the clock and timer settings again. - Page 17 The remote does not function. • There is an obstacle between the remote and the system. • The remote is not pointing in the direction of the system’s sensor. • The batteries have run down. Replace the batteries. The color irregularity on a TV screen persists. •...
-
Page 18: Additional Information
• When you move the system, take out any discs. If you have any questions or problems concerning your stereo system, please consult your nearest Sony dealer. Notes on CDs • Before playing, clean the CD with a cleaning cloth. -
Page 19: Specifications
To save a tape permanently To prevent a tape from being accidentally recorded over, break off the cassette tab from side A or B as illustrated. Break off the cassette tab of side A If you later want to reuse the tape for recording, cover the broken tab with adhesive tape. - Page 20 Specifications (continued) Tape player section Recording system 4-track 2-channel stereo Frequency response 50 - 13 000 Hz (±3 dB), using Sony TYPE I cassette Wow and flutter ±0.15% W.Peak (IEC) 0.1% W.RMS (NAB) ±0.2% W.Peak (DIN) Tuner section FM stereo, FM/AM superheterodyne tuner...
