Summary of Contents for Midland G10
- Page 1 VHF TRANSCEIVER › INSTRUCTION GUIDE PUT YOURSELF IN ACTION...
-
Page 3: Table Of Contents
Index Programming software (optional) Content Main characteristics Main controls and parts of the radio Operations Power on/off and volume adjustment Transmission Monitor Scan Squelch Battery recharge Maintenance Troubleshooting Technical specifications Midland G10 instruction guide... -
Page 4: Programming Software (Optional)
Midland G10 is a multi-task VHF transceiver. Combining the latest technology in radio communication along with a sturdy me- chanical frame, G10 is the ideal and effective solution for the professionals who need to stay in touch with the working team (in construction sites, buildings, shows, trade fairs or hotels) or for leisure users that just want to keep up with friends and family. -
Page 5: Main Controls And Parts Of The Radio
Main controls and parts of the radio Midland G10 instruction guide... - Page 6 PTT: push this button to transmit, release it to receive. Function key 1: hold down this button to activate the Monitor function. Function key 2: not programmed by default External Speaker/Mic Jack- allows the connection with external devices such as headsets, microphones. Midland G10 instruction guide...
-
Page 7: Operations
If the PTT is pressed, you will transmit on the latest busy channel. Whenever any signal is detected, the scanning will stop on a busy channel. If the PTT is pressed, you will transmit on the latest busy channel. Midland G10 instruction guide... -
Page 8: Squelch
This feature is set to 120 sec by default. Battery recharge G10 is equipped for using a 7,4V Li-ion rechargeable battery pack which can be re- charged connecting the socket of the AC/DC wall adaptor to a mains power socket and inserting the jack of the wall adaptor into the desktop charger plug. - Page 9 Keep the Radio dry. Rainwater or damp will corrode electronic circuits. • If it appears that the Radio diffuses peculiar smell or smoke, please shut off its power immediately and take off the charger or battery from the Radio. • Do not transmit without antenna. Midland G10 instruction guide...
-
Page 10: Troubleshooting
(televisions, computers, etc.) The autonomy of Commission time is too high. Try reducing the transmission time the battery pack is and/or using a low power. limited Midland G10 instruction guide... -
Page 11: Technical Specifications
Max frequency deviation ≤2,5KHz@12,5KHz; ≤5KHz@25KHz Audio distortion ≤2% Adjacent channel power < 65 dB Receiver RF sensitivity <-119dBm@20 dB SINAD Audio distortion ≤2% Audio response 500Hz ÷ 3KHz The use of this transceiver is subject to a licence. Midland G10 instruction guide... - Page 12 Prodotto o importato da: CTE INTERNATIONAL s.r.l. Via. R.Sevardi 7- 42124 Reggio Emilia Italia www.cte.it - www.midlandeurope.com L’uso di questo apparato può essere soggetto a restrizioni nazionali. Prima dell’uso leggere attentamente le istruzioni. Produced or imported by: CTE INTERNATIONAL s.r.l. Via.
