- Page 1 RLT254CDSO 25.4CC GRASS TRIMMER ORIGINAL INSTRUCTIONS Important! It is essential that you read the instructions in this manual before assembling, maintaining and operating the product.
- Page 2 English (Original Instructions) SYMBOLS Important: Some of the following symbols may be used on your product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. Explanation Safety alert Read and understand all instructions before operating the product, follow all warnings and safety instructions.
- Page 3 English (Original Instructions) Squeeze the throttle lock and throttle trigger to run. Wait 10 seconds. Conforms to all regulatory standards in the country in the EU where the product is purchased. EurAsian Conformity Mark Ukrainian mark of conformity Guaranteed sound power level Pull the starter rope.
-
Page 4: Intended Use
English (Original Instructions) Safety performance, and dependability have been given ■ Never start or run the engine in a closed or poorly top priority in the design of your grass trimmer. ventilated area; breathing exhaust fumes can kill. ■ Clear the work area before each use. Remove all INTENDED USE objects such as rocks, broken glass, nails, wire, or string that can be thrown or become entangled in the... -
Page 5: Grass Trimmer Safety Warnings
Keep string head below waist level. Never cut with Never use cutting means or attachments which are the string head located over 76 cm or more above the not specified by RYOBI in this manual. This includes ground. the use of metal multi-piece pivoting chains and flail- blades. -
Page 6: Residual Risks
English (Original Instructions) RESIDUAL RISKS Starter grip Throttle lock Even when the product is used as prescribed, it is still Ignition switch impossible to completely eliminate certain residual risk Throttle trigger factors. The following hazards may arise in use and Rear handle the operator should pay special attention to avoid the Front handle... -
Page 7: Operation
English (Original Instructions) securely. WARNING ATTACHING THE GRASS DEFLECTOR If any parts are damaged or missing do not operate the product until the parts are replaced. Failure to heed this See Fig. 2. (b) warning could result in serious personal injury. ■... -
Page 8: Mixing The Fuel
English (Original Instructions) flames. Do not inhale fuel vapour. Do not smoke. FILLING THE TANK ■ Do not let petrol or lubricant come in contact with your skin. WARNING ■ Keep petrol and lubricant away from the eyes. If petrol Check for fuel leaks. -
Page 9: To Stop The Engine
11. Allow the engine to warm up for 10 seconds. WARNING 12. Set the choke level to choke position. Only use the RYOBI OES18 electrical starter. Use of any other starter may damage the engine and cause serious TO START A WARM ENGINE BY ELECTRICAL personal injury. -
Page 10: Maintenance
English (Original Instructions) OPERATING THE GRASS TRIMMER NOTE: If the string is worn too short, you may not be able to advance the string by tapping it on the ground. If so, See Fig. 5. stop the engine, and manually advance the line. Hold the product with the right hand on the rear handle ADVANCING THE CUTTING LINE MANUALLY and the left hand on the front handle. -
Page 11: Line Replacement
English (Original Instructions) LINE REPLACEMENT Check: Cutting attachment Before each use must not rotate in idle mode ² See Fig. 8. Check fuel hose Before each use ■ Ensure the product is in the off position. Check all hose connections Before each use ■... -
Page 12: Spark Plug Replacement
English (Original Instructions) ■ Replace the air filter (fits only one way). ■ Replace the air filter cover. NOTE: The filter should be replaced annually for best performance. FUEL CAP WARNING A leaking fuel cap is a fire hazard and must be replaced immediately. -
Page 13: Troubleshooting
English (Original Instructions) TROUBLESHOOTING IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM, CONTACT YOUR AUTHORISED SERVICE DEALER. PROBLEM POSSIBLE CAUSE SOLUTION Engine will not start. 1. No spark. 1. The spark plug may be damaged, remove it and check for dirt and cracks. Replace with a new spark plug. 2. - Page 14 English (Original Instructions) PROBLEM POSSIBLE CAUSE SOLUTION Engine starts, runs, Idle speed screw on carburetor Contact a servicing dealer. accelerates but will not idle. requires adjustment Line will not advance. 1. Line welded to itself. 1. Lubricate with silicone spray. 2.
-
Page 15: Specification
English (Original Instructions) SPECIFICATION Noise emission (in accordance with ISO 22868) Grass Trimmer RLT254CDSO A-weighted emission sound pressure level at the operator Weight position - Without fuel, cutting attachment - Idling 72.4 dB (A) 4.06 kg and harness - Racing 94.1 dB (A) - Page 16 For servicing, the product must be sent or presented to a RYOBI authorised service station listed for each country in the following list of service station addresses. In some countries your local RYOBI dealer undertakes to send the product to the RYOBI service organisation.
- Page 17 AUTHORISED SERVICE CENTRES ACD PLANT LTD C J Sinclair Limited ToolTech Industrial Equipment 145 Southbank Road 44 Victoria Road 227 E Dunhill Road, Macosquin Coundon St Peters Coleraine, Co Londonderry Coventry, West Midlands Broadstairs, Kent BT514LQ CV6 1FG CT10 2UG Phone: 028 70359493 Phone: 02476 594348 Phone: 01843 869400...
-
Page 18: Declaration Of Conformity
Max-Eyth-Straße 10, 71364 Winnenden, Germany Herewith we declare that the product Grass Trimmer Brand: RYOBI Model number: RLT254CDSO Serial number range: 46208702000001 -46208702999999 is in conformity with the following European Directives and harmonised standards 2006/42/EC, 2014/30/EU, 2000/14/EC, 2005/88/EC, 2016/1628/EU, 2011/65/EU, EN ISO 11806-1:2011, EN ISO 14982:2009, EN 50581:2012 Measured sound power level: 107.2 dB (A) - Page 20 Techtronic Industries GmbH Max-Eyth-Straße 10, 71364 Winnenden, Germany 960405044-03...
