- Page 1 RLT254SSEON GRASS TRIMMER ORIGINAL INSTRUCTIONS Important! It is essential that you read the instructions in this manual before assembling, operating, and maintaining the product. S ubject to technical modifications.
- Page 2 English (Original Instructions) SYMBOLS Important: Some of the following symbols may be used on your product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOLS EXPLANATION Safety alert Read and understand all instructions before operating the product, follow all warnings and safety instructions.
- Page 3 English (Original Instructions) Set the choke lever to “FULL” choke position. Set the choke lever to "HALF" choke position. Press the primer bulb 10 times. Waiting time:10 seconds. Guaranteed sound power level 110 dB 74 dB Sound pressure level at idle Pull: Quick release tab Squeeze the throttle lock and throttle trigger to run.
-
Page 4: Intended Use
English (Original Instructions) Safety, performance, and dependability have been given ■ Never start or run the engine in a closed or poorly top priority in the design of your grass trimmer. ventilated area; breathing exhaust fumes can kill. ■ Clear the work area before each use. Remove all INTENDED USE objects such as rocks, broken glass, nails, wire, This grass trimmer is intended to be used only by... -
Page 5: Trimmer Safety Warnings
Never use cutting means or attachments which are ■ The Grass trimmer is fitted with a harness. Carefully not specified by Ryobi in this manual. These items adjust the harness to fit comfortably and help to are known to break up during use and present a high support the weight of the machine at your right side. -
Page 6: Transportation And Storage
English (Original Instructions) warm. It is reported that cold weather is a major factor ■ Store the product in a cool dry and well-ventilated contributing to Raynaud's Syndrome. place that is inaccessible to children. ■ After each period of operation, exercise to increase ■... -
Page 7: Packing List
English (Original Instructions) 46. String head housing WARNING 47. Latch To prevent accidental starting that could cause 48. String head cover serious personal injury, always disconnect the 49. Bump knob engine spark plug wire from the spark plug when 50. Hex bolt assembling parts. -
Page 8: Operation
English (Original Instructions) operate this tool until the parts are replaced. INSTALLING THE LINE IN THE PRO CUT II™ HEAD Failure to heed this warning could result in ■ Use monofilament line diameter 2.7 mm. Use original serious personal injury. manufacturers replacement line for best performance. - Page 9 English (Original Instructions) clean container approved for petrol. refueling site before starting engine. NOTE: It is normal for smoke to be emitted from a new ■ This engine is certified to operate on unleaded petrol engine during and after first use. intended for automotive use with an octane rating of 91 ([R + M] / 2) or higher.
-
Page 10: To Stop The Engine
11. Allow the engine to run for 10 seconds. 12. Set the lever to position. Only use the Ryobi OES18 electrical starter. Use of any other starter may damage the engine and cause TO START A WARM ENGINE BY ELECTRICAL serious personal injury. -
Page 11: Maintenance
English (Original Instructions) CUTTING TIPS REPLACEMENT FOR REEL EASY STRING HEAD (See Fig. 6) (See Fig. 9a) ■ Do not push into the grass to be cut. Move from side to Removing the old string head side, moving forward a little at the end of each sweep. ■... -
Page 12: Cleaning The Spark Arrestor
English (Original Instructions) the side of the string head and push until string comes ■ Replace the air filter (fits only one way). out through eyelet on the other side. Continue to push ■ Replace the air filter cover. string through the string head until the middle section NOTE: The air filter should be replaced annually for the of the string is inside the string head and string outside best performance. -
Page 13: Troubleshooting
English (Original Instructions) TROUBLESHOOTING IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM, CONTACT YOUR AUTHORISED SERVICE DEALER. PROBLEM POSSIBLE CAUSE SOLUTION Engine will not start. No spark. The spark plug may be damaged, remove it and check for dirt and cracks. -
Page 14: Specification
English (Original Instructions) SPECIFICATION Model RLT254SSEON Weight - Without fuel, cutting attachment and harness 5.65 kg - Without fuel and harness, with Reel Easy string head 6.20 kg Fuel tank volume 620 cm Cutting swath - String head 457 mm Engine displacement 25.4 cm... -
Page 15: Replacement Parts
English (Original Instructions) REPLACEMENT PARTS Part Part number Reel Easy string head with cutting line LTA-042 Pro Cut II™ string head with cutting line LTA-039 Cutting line for Pro Cut II™ string head RAC1209... - Page 16 Imported by: Techtronic Industries (Australia) Pty. Ltd. 31 Gilby Road, Mt. Waverley, VIC 3149, Australia Techtronic Industries New Zealand Ltd. 2 Landing Drive, Mangere, Auckland, New Zealand 2022 960405038-02...
