Kohler K-3396 Homeowner's Manual

Kohler K-3396 Homeowner's Manual

Professional cook sink
Hide thumbs
Table of Contents

Advertisement

Quick Links

Homeowners Guide
Professional Cook Sink
K-3396
1032055-5-A

Advertisement

Table of Contents
loading

Related Manuals for Kohler K-3396

Summary of Contents for Kohler K-3396

  • Page 1 Homeowners Guide Professional Cook Sink K-3396 1032055-5-A...

  • Page 2: Important Safety Instructions

    Underwriters Laboratory (UL). Some of the active safety features are as follows: The Kohler Cook Sink does not operate until the unit is turned on and the power is set. The Kohler Cook Sink has a red indicator that operates at about 140°...
  • Page 3 Do not touch hot surfaces. Use handles or knobs. Do not use outdoors. Thank You For Choosing Kohler Company Thank you for choosing the Bold Look of Kohler. Kohler craftsmanship offers you a rare combination of proven performance and graceful Kohler Co.

  • Page 4: How To Use This Manual

    Check the ″Service Parts″ section to determine the part numbers for any replacement parts necessary. Use the information on the back cover of this manual to contact Kohler Company to order parts, or for help if you cannot correct the problem. Care and Cleaning Stainless Steel Cook Sink Rinse your stainless steel sink thoroughly after each use.
  • Page 5 All Purpose, Formula 409 All Purpose, or Lysol ® ® ® Anti-Bacterial Kitchen Cleaner ™ If your stainless steel colored finish becomes excessively dirty, consider cleaning with Dow Scrubbing Bubbles Liquid or Bleach Free Soft ® Scrub ® Kohler Co. 1032055-5-A...

  • Page 6: Important Notes

    Before operating, fill the cooking vessel with a minimum of 2 quarts (1.9 L) of water (1/4 full). Drain water immediately after cooking. Do not completely drain water from the cooking vessel while the unit is on. 1032055-5-A Kohler Co.
  • Page 7 Important Notes (cont.) Do not store anything, especially flammable materials, near the underside of the cooking vessel. Do not use steel wool on the cooking vessel or cookware. Do not cut food in the cookware. Kohler Co. 1032055-5-A...

  • Page 8: Preparing To Cook

    Close the drain by turning the drain knob clockwise to the closed position. Fill the cooking vessel at least 1/4 full with water. Turn the trim ring so that the steam escape groove faces toward the sink basin or other drainage area. 1032055-5-A Kohler Co.
  • Page 9 The cook sink has over-temperature protection. If the sink’s temperature increases above about 250° F (121° C), all 10 power setting LEDs start flashing. If the temperature remains high for more than two minutes, the cook sink stops heating automatically. Refer to the Kohler Co. 1032055-5-A...
  • Page 10 If desired, push and turn the drain knob counterclockwise for a short period of time to drain excess water. Turn the knob clockwise when the water has drained. If desired, add more water in order to make up for any losses. 1032055-5-A Kohler Co.

  • Page 11: After Cooking

    When cooking is completed, press the power switch to stop cooking. Observe that all 10 power setting LEDs are extinguished. Turn the drain knob counterclockwise to open the drain. Rinse the unit out with mild soap and water after each use. Kohler Co. 1032055-5-A...

  • Page 12: Service Parts

    97450 Trim Ring S1-97090 1036350 1036276 Mounting Ring Cooking Basin Sensor Kit 87774 Spring 63270 Washer 97467 Seal 7257 Mount Kit (4 ea.) 97475 Spacer 97400 **Finish/color code must be specified when ordering. Service Parts 1032055-5-A Kohler Co.
  • Page 13 1004466 Locknut 1036352 Housing 1004466 Locknut 1004646 Panel 97698 Screw **Finish/color code must be specified when ordering. Kohler Co. 1032055-5-A...
  • Page 14 1022494 Drain Knob 1036758 Bezel 96967 Seal 1032630 Panel 1036768 97484 Controller Assembly Screw 1022621 Junction Box 1032298 Screw 1022625 Controller Plate 1022620 Junction Box Cover 86810 Ground Screw **Finish/color code must be specified when ordering. 1032055-5-A Kohler Co.
  • Page 15 Cable Mounting Clip 41550 38744 Gasket Washer 1008219 38745 Screw Wave Washer 38744 1004470 Washer Ball and Trip 1004988 Lever Assembly Cable Mounting Bracket 38745 Wave Washer 41950** Tailpiece 1011041 Cable Bracket **Finish/color code must be specified when ordering. Kohler Co. 1032055-5-A...

  • Page 16: Troubleshooting Table

    C. If the problem persists, contact a Kohler Authorized Service Representative. Water drains A. The drain or trap is probably plugged.
  • Page 17 Instructions″ section. If you can’t correct the problem on your own, contact your local Kohler dealer. If you need to locate a Kohler Authorized Service Representative in the United States, call our Customer Service Department at 1-800-4-KOHLER (1-800-456-4537). For general information, call one of the following numbers: In the U.S.A., call 1-800-4-KOHLER (1-800-456-4537)
  • Page 18 Dealer, Plumbing Contractor, Home Center or E-tailer, or by writing Kohler Co., Attn.: Customer Service Department, 444 Highland Drive, Kohler, WI 53044, USA, or by calling 1-800-4-KOHLER from within the USA, 1-800-964-5590 from within Canada and 001-877-680-1310 from within Mexico.
  • Page 19 It is recommended that at the time of purchase, you verify that all accessories and components are complete in this package. This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the date of purchase as shown on the invoice or receipt.
  • Page 20 Kohler Co. 3. This warranty does not cover the damages as a result of disaster such as fire or acts of God, including flooding, earthquake, or electric...
  • Page 21 1032055-5-...
  • Page 22 1032055-5-...
  • Page 23 1032055-5-...
  • Page 24 USA:1-800-4-KOHLER kohler.com ©2004 Kohler Co. 1032055-5-A...
