VAIO Digital Studio System Reference Manual

Replacing the Side Panel

To replace the side panel (PCV-RZ series model)

1
Align tabs on the side panel to the tracks on the chassis frame.
2
Gently slide the side panel onto the chassis, until the tabs lock the
panel into place.
Replacing the side panel (PCV-RZ series model equipped with Giga Pocket)
