- Page 1 Hart Scientific 5680/5682/5699 Metal Sheath Standard Platinum Resistance Thermometer User’s Guide Rev. 5C1301 Fluke-Direct .com info@Fluke-Direct.com 1.888.610.7664...
-
Page 2: Table Of Contents
Immersion Requirements ..... . 15 Thermal EMF ......15 Fluke-Direct .com info@Fluke-Direct.com... - Page 3 8 Troubleshooting......21 Troubleshooting ......21 Fluke-Direct .com info@Fluke-Direct.com...
- Page 4 International Electrical Symbols ..... 1 Figure 1 5680/5682/5699 Metal Sheath Platinum Resistance Thermometer ..5 Table 2 Specifications .
-
Page 5: Before You Start
Table 1 International Electrical Symbols Symbol Description AC (Alternating Current) AC-DC Battery CE Complies with European Union Directives Double Insulated Electric Shock Fuse PE Ground Hot Surface (Burn Hazard) Read the User’s Manual (Important Information) Fluke-Direct .com info@Fluke-Direct.com 1.888.610.7664... -
Page 6: Safety Information
5680/5682/5689 SPRT User’s Guide Symbol Description Canadian Standards Association OVERVOLTAGE (Installation) CATEGORY II, Pollution Degree 2 per IEC1010-1 re- fers to the level of Impulse Withstand Voltage protection provided. Equipment of OVERVOLTAGE CATEGORY II is energy-consuming equipment to be supplied from the fixed installation. -
Page 7: Authorized Service Centers
SPRT from the shipping box or case. Incorrect handling can damage the SPRT and void the warranty. • Keep the shipping container in case it is necessary to ship the SPRT. In- correct packaging of the SPRT for shipment can cause irreparable dam- age. Fluke-Direct .com info@Fluke-Direct.com 1.888.610.7664... -
Page 8: Introduction
(–189°C) to 480°C. The 5699 metal sheath SPRT covers the ITS-90 range from below the Triple Point of Argon (–189°C) to 661°C. The 5680 has a resis- tance of 25Ω at the triple point of water (0.01°C), the 5682 has a resistance of 100Ω... -
Page 9: Application
Quality Assurance requirements. Normally, an SPRT is recalibrated annually. Unless the SPRT is used only over a limited range, calibration over the full range of the SPRT (–200°C to 480°C for the 5680 and 5682, and –200°C to 661°C for the 5699) is recommended. For information on recalibrating your SPRT, contact a Hart Scientific Authorized Service Center (see Section 1.3) for calibration options, an RMA number, and current pricing. - Page 10 Whether the thermometer is returned for repair or warranty, please include a letter containing the following information • Description of the faulty operation and circumstances of failure. • Complete shipping instructions for the return of the thermometer to the customer. Fluke-Direct .com info@Fluke-Direct.com 1.888.610.7664...
-
Page 11: Specifications And Warranty
>1000MΩ at 20°C Construction The Model 5680/5682 SPRTs cover the range from –200°C to 480°C and the Model 5699 SPRT covers the range from –200°C to 661°C. The sensor ele- ments are crafted using high purity platinum wire wound in a strain free design on a specially designed support. -
Page 12: Warranty
User’s Guide Warranty Fluke Corporation, Hart Scientific Division (Hart) warrants this product to be free from defects in material and workmanship under normal use and service for a period as stated in our current product catalog from the date of shipment. -
Page 13: Installation
Lead Wire Identification The Model 5680/5682/5699 SPRTs are equipped with a five-wire cable. Four lead wires are used to cancel lead wire resistance. The fifth wire is a ground wire which is connected to the Inconel sheath. For best results, the readout de- vice should be equipped to handle four-terminal resistors. -
Page 14: Figure 2 Circuit Schematic
5680/5682/5689 SPRT User’s Guide shrink tubing. The green wire is the ground wire which should be connected to the ground. See Figure 2. White BLACK Black Yellow to ground connected to Inconel sheath GREEN Figure 2 Circuit Schematic Fluke-Direct .com info@Fluke-Direct.com... -
Page 15: Sprt Care And Handling Guidelines
DO use the correct drive current with the thermometer to prevent error in temperature or resistance. DO anneal the thermometer at 480°C for the 5680 and 5682, and at 661°C for the 5699 when it has been subjected to mechanical or temper- ature shock. - Page 16 5680/5682/5689 SPRT User’s Guide Model 5699 only 11. DO anneal the SPRT after delivery or when using at a temperature higher than 600°C. 12. DON’T take the SPRT out directly when it has been at a temperature higher than 500°C. Allow the SPRT to cool to a temperature less than 500°C before removing it to room temperature.
-
Page 17: Operation
SPRT. Likewise, connection to extension lead wires and readout instruments can be a source of thermal EMF. The thermal EMF is caused by a difference in tempera- Fluke-Direct .com info@Fluke-Direct.com... -
Page 18: Measuring Current
SPRT to stabilize and the heat to be dispersed into the surrounding medium will provide the most accurate results. The Model 5680/5682/5699 measurements are made at 1 mA and 1.4 mA. These measurements are then extrapolated to zero current. This can be done graphically by plotting i²... - Page 19 6 Operation Cooling Rates at High Temperatures SPRT can be safely removed from an instrument at 500°C or less and cooled to room temperature without concern for the cooling rate. Fluke-Direct .com info@Fluke-Direct.com 1.888.610.7664...
-
Page 20: Accessories
Case The SPRTs are shipped in a protective case. The SPRT should be stored in this case when not in use. The SPRT should be shipped in this case when returning (see Section 2.5, Return Procedure). Fluke-Direct .com info@Fluke-Direct.com 1.888.610.7664... -
Page 21: Troubleshooting
200 – 450°C. R will show an in- crease. To reduce the effects of oxidation, anneal the SPRT at 480°C (5680 and 5682) or 661°C (5699 only) overnight (12 hours). Measure the R again. Repeat the annealing, R... - Page 22 5680/5682/5689 SPRT User’s Guide Problem Solution Temperature readout different Measure the SPRT resistance at TPW. than expected, e.g. the heat • If the resistance of the SPRT is less than the rated resis- source is set at 300°C, the SPRT tance, there may be a short in the sensor.
