Specifications

Due to continuous improvements and innovations, specifications may change without notice.
Item Specification
Input Voltage
Electrical
Power Consumption
Supported LED Nodes
Capability
Network Data
Playback Output
Dimensions
(Height x Width x Depth)
Weight
Physical
Operating Temperature
Operating Humidity
Certification
Certification
and Safety
Environment
* KiNET is the Ethernet lighting protocol from Philips Color Kinetics.
† Use PoE (Power-over-Ethernet) switches, or PoE injectors, when installing a
lighting system containing one or more Ethernet Controller Keypads.

Software Requirements

System
Specification
Requirements
Software Operating System
Memory
Hardware
Disk space
Light System Manager
Item
Controller, Light System Manager (Gen 5) 1000 Node
Controller, Light System Manager (Gen 5) 2000 Node
Controller, Light System Manager (Gen 5) 3000 Node
Controller, Light System Manager (Gen 5) 5000 Node
Controller, Light System Manager (Gen 5) 8000 Node
Controller, Light System Manager (Gen 5) 12000 Node
Controller, Light System Manager (Gen 5) 15000 Node
Accessories
Item
Ethernet Controller Keypad
PoE Injector (North America Power Cord)
PoE Injector (Europe Power Cord)
AuxBox
6
Light System Manager Product Guide
Details
100 – 240 VAC, auto-switching
180 W max.
Up to 15,000 LED nodes
KiNET Ethernet protocol* via standard Ethernet switch†
Light shows containing one or more visual effects
9.5 x 11.8 x 3.5 in (244 x 301 x 89 mm)
9.3 lb (4.2 kg)
32 – 95° F (0° – 35° C)
0 – 90%, relative humidity, non-condensing
UL / cUL, FCC, CE, C-Tick, CCC
Indoor / Dry location
PC
Windows 8 / Windows 7
256 MB RAM
10 MB free disk space
Item Number
103-000042-01
103-000042-02
103-000042-03
103-000042-05
103-000042-08
103-000042-12
103-000042-15
Use Item Number when ordering in North America.
Item Number
103-000023-00
109-000029-00
109-000029-01
103-000021-00
Mac
Mac OS X 10.6 or greater
256 MB RAM
10 MB free disk space
Philips 12NC
912400134287
912400134288
912400134289
912400134290
912400134291
912400134292
912400134293
Philips 12NC
910503700326
910503700383
910503700384
910503700224
9.5 in
241 mm
11.8 in
301 mm
10.6 in
270 mm
11.9 in
303 mm
Included in the Box
Light System Manager
Power cable
(2) Mounting brackets and (6) Mounting screws
Ethernet Controller Keypad
Ethernet Controller Keypad is a wall-
mounted triggering device that controls
up to eight light shows and lighting fixture
brightness at the touch of a button.
AuxBox
AuxBox instantly activates up
to eight light shows using any
remote triggering device with
a dry-contact closure.
1.6 in
41 mm
2.3 in
60 mm
10.2 in
260 mm
