- Page 1 Digital Wireless Microphone System DWT-B01 DWR-S01D DWA-01D...
- Page 2 System Features DWT-B01 Digital Wireless Transmitter DWR-S01D Digital Wireless Receiver DWA-01D Digital Wireless Adapter Specifications & Accessories...
- Page 3 A Breakthrough for a New Level of Sound Quality and operational Convenience Since their first introduction in 1974, Sony has been continuously developing a rich range of wireless microphone systems to offer superb audio performance, highly stable transmission and flexible simultaneous multi-channel operation. Nowadays, it can be clearly seen that the industry is migrating from Standard Definition (SD)
-
Page 4: System Features
24-bit/48 kHz sampling digital audio signals in a specific frequency bandwidth that meets the wireless-communication regulations of each country. Utilising an original Sony codec, based on Sony’s many years of experience in engineering audio products, the system delivers a wide dynamic range of more than 106 dB, a wide frequency response of 20 Hz to 20 kHz and an excellent system latency of 3.6 ms. - Page 5 Not all services are available in all countries. If you’d like to find out more about what we do, who we do it for and how we do it, visit www.sonybiz.net or contact your local Sony office. Audio RF Signal...
- Page 6 System Features Easy-to-see, Full Dot-matrix OLED (Organic Light-Emitting Diode) Display The DWT-B01 transmitter and DWR-S01D receiver have an easy-to-see OLED display, providing a variety of information such as operating channel/frequency, AF input level, RF output level and battery status. The quick response of the OLED display enables real- time operating conditions, such as the audio level meter, to be displayed clearly and accurately.
- Page 7 The transmitter will operate continuously for approxi- mately four* hours when using two Sony AA-size alkaline batteries at 25 °C (77 °F) and 10 mW output power. The operating time may vary depending on the operational environment.
- Page 8 Sony professional cam- corders – such as the HDCAM Digital Betacam ™ and MPEG IMX using the DWA-01D adapter. When used with a camcorder that has AES/EBU inputs, full-digital audio recording is also possible. PDW-700 XDCAM HD Camcorder ™...
- Page 9 DIGITAL WIRELESS RECEIVER 20 ( ⁄ 80 (3 ⁄ 31.3 (1 88 (3 ⁄ ⁄ An Introduction to Digital Wireless Microphone Technology is now available. Contact your local Sony office to request a copy or download a PDF version from www.sonybiz.net/go-digital...
- Page 10 Sony professional camcorders, such as HDCAM, XDCAM, XDCAM HD, Digital Betacam and MPEG IMX camcorders. In addition, the DWA-01D adapter can be used with the current analogue wireless receiver WRR-855S/855B.* *1 Requires an optional mount bracket (A-8278-057B).
-
Page 11: Specifications
* The DWR-S01D receiver supports a 24 MHz band RF carrier frequency range. When using the DWR-S01D receiver in either the 590.125 to 607.875 MHz (TV 34 to 36 channels), 614.125 to 637.875 MHz (TV 38 to 41 channels) or 662.125 to 697.875 MHz (TV 46 to 51 channels) frequency range, please contact your nearest Sony office or authorized dealer. - Page 12 ©2007 Sony Corporation. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Features and specifications are subject to change without notice. All non-metric weights and measurements are approximate. Sony, HDCAM, XDCAM, Digital Betacam and MPEG IMX are trademarks of Sony Corporation.
