Actiontec USB Home DSL Modem User Guide
Rear Panel
The Modem has four ports on its rear panel: Line, Phone, USB, and Power.
DSL Cable
(from Line Port
to DSL Outlet)
Line Port
The Line port is used to connect the Modem to the
Phone Port
The Phone port is used to connect a telephone to the Modem.
USB Port
The port is used to connect the Modem to a computer.
USB
Power Port
The Power port is used to connect the Modem's power adapter to a wall outlet.
Ph on e
Li ne
Phone Cable
(from Phone Port
(from USB Port
to Telephone)
to Computer)
4
Po w er
U SB
USB Cable Power Adapter
(from Power Port
to Power Outlet)
outlet.
DSL
