Original Issue Date: 3/08
Model: 6- -60 kW Residential and Light Commercial Generator Sets
Market: Residential/Commercial
Subject: Maintenance Service Kits GM62345, GM62346, GM62347, GM62348,
Introduction
This kit provides items necessary for general engine
maintenance and service on 6--60 kW residential and
light commercial generator sets listed in Figure 1.
Read the entire installation procedure before beginning
installation. Perform the steps in the order shown.
Generator Set
8RESV(L)
8.5RES
10/12RESV(L)
6VSG, 12RES(L), 14RES(A)(AL)(L)
15RES(A)/R(E)YG,
30RES(A)/R(E)YG
17/18RES(L),
20RES(A)(AL)(B)(C)(CL)(D)(L)
24RCL
30RCL, 38RCLB
38RCL
48RCL
48RCLA and 60RCL
Figure 1 Kits
INSTALLATION INSTRUCTIONS
GM83718, GM86771, GM89979, GM90365, GM90366, GM93396, and
GM100209
Service Kit Number
GM90365
GM62345
GM90366
GM62346
GM62348
GM62347
GM93396
GM100209
GM86771
GM83718
GM89979
Sales Kit Number
GM90365-SKP1-QS
GM62345-SKP1-QS
GM90366-SKP1-QS
GM62346-SKP1-QS
GM62348-SKP1-QS
GM62347-SKP1-QS
GM93396-SKP1-QS
GM100209-SKP1-QS
GM86771-SKP1-QS
GM83718-SKP1-QS
GM89979-SKP1-QS
TT-1445
7/16i
Advertisement
Table of Contents
Related Manuals for Kohler GM62345
Summary of Contents for Kohler GM62345
- Page 1 INSTALLATION INSTRUCTIONS Original Issue Date: 3/08 Model: 6- -60 kW Residential and Light Commercial Generator Sets Market: Residential/Commercial Subject: Maintenance Service Kits GM62345, GM62346, GM62347, GM62348, GM83718, GM86771, GM89979, GM90365, GM90366, GM93396, and GM100209 Introduction This kit provides items necessary for general engine maintenance and service on 6--60 kW residential and light commercial generator sets listed in Figure 1.
-
