Chamberlain Elite Series Wiring Diagrams

To reduce the risk of INJURY or DEATH:
• DISCONNECT power BEFORE installing or servicing operator.
• Replace ONLY with fuse of same type and rating.
• To be compliant with UL325 and industry safety guidelines, qualified monitored
external entrapment protection devices such as photoelectric sensors or edge
sensors are required to be installed with this operator at each entrapment zone.
Use ONLY LiftMaster approved entrapment protection devices (refer to the
accessory page of manual).
• See manual prior to servicing regarding maintenance and required safety testing.
Diagnostic Codes
TO VIEW THE CODES:
Press and hold ...then press and ...then press and hold OPEN
STOP... hold CLOSE... until "Er" shows.
The operator will show the code sequence number followed by the code number:
A SECOND LATER....
CODE SEQUENCE NUMBER CODE NUMBER
The first number shown is the most recent The second number shown after the code
code (example: "01"). The display will show sequence number is the code itself
the sequence of codes that occurred starting (31-99, example" "31").
with "01" and going up to code "20".
TO SCROLL THROUGH THE SAVED CODES:
Press the OPEN button to cycle to the most recent code ("01"). Press the CLOSE button
to cycle to the oldest code (up to "20").
CODE COLOR KEY:
LiftMaster System External Entrapment Protection
Installed System Inherent Entrapment Protection
Informational
MEANING SOLUTION
Main control board has experienced an Disconnect all power, wait 15 seconds, then reconnect
31 internal failure. power (reboot). If issue continues, replace main control
board.
Max-Run-Time Exceeded Error Attempt to run and review for duration and obstructions.
Max-Run-Time can be re-measured by saving one or
35
both of the limits again.
Product ID Error Was the control board just replaced? If so, erase limits,
enter limit setup mode and set limits. If not, disconnect
all power, wait 15 seconds, then reconnect power before
36
changing product ID harness.
Product ID Failure Unplug product ID harness then plug back in. Disconnect
all power, wait 15 seconds, then reconnect power before
37
replacing product ID harness.
Failure or missing EXIT loop Check loop wiring throughout connection. May be a
short in the loop, or an open connection in the loop
43
(LiftMaster Plug-in Loop Detector only).
Failure or missing SHADOW loop
44
Failure or missing INTERRUPT loop
45
Wireless edge battery low Replace batteries in wireless edge.
46
Power board fault Relay fault detected in the power board. Replace the
47
power board.
Run-Distance Error Limits are less than 4 feet apart or longer than what was
learned. Check limit positions and proper switch
50
function. Run-distance can be re-learned by setting the
handing again.
Brownout occurred AC/DC board supply dipped below allowable level.
Review power supply and wiring. If rebooting, ensure
53
enough time for discharge of power to force a fresh
boot.
Wireless Second Operator Communication Check the second operator for power. If OFF, restore
Error power and try to run the system. If powered, deactivate
54
the wireless feature and then re-learn the second
operator.
55 System AC Overvoltage Call utility.
56 System AC Undervoltage Check wiring and wire gauge to operator.
Limit Error - Stuck Switch Check switch for proper operation. Check harness for
57
shorts. Replace if defective.
58 Limit Error - Wrong Switch Check motor wiring.
Missing Power Board Check harness for shorts. Check for presence of power
59
board.
Minimum number of monitored entrapment Review monitored entrapment protection device
protection devices not installed. connections. Slide gate operators require a minimum of
60
two external safety devices; one in the close and one in
the open direction
CLOSE EYE/INTERRUPT held more than 3 Check wired input on main board; check for alignment or
61
minutes obstruction.
CLOSE EDGE held more than 3 minutes
62
OPEN EYE/EDGE held more than 3 minutes
63
CLOSE EYE/INTERRUPT held more than 3 Check wired input on expansion board; check for
64
minutes alignment or obstruction.
CLOSE EYE/EDGE held more than 3 minutes
65
OPEN EYE/EDGE held more than 3 minutes
66
Wireless edge triggered more than 3 minutes Check wired input for wiring issue or obstruction.
67
Wireless edge loss of monitoring Check wireless edge inputs.
68
Wireless edge triggered IF an obstruction occurred, no action required. If an
69
obstruction did NOT occur, check inputs and wiring.
CLOSE EYE/INTERRUPT triggered, causing IF an obstruction occurred, no action required. If an
reversal, preventing close, or resetting TTC obstruction did NOT occur, check alignment, inputs, and
70
wiring on main board.
CLOSE EDGE triggered, causing reversal,
71
preventing close, or canceling TTC
OPEN EYE/EDGE triggered, causing reversal
72
or preventing opening
CLOSE EYE/INTERRUPT triggered, causing IF an obstruction occurred, no action required. If an
reversal, preventing close, or resetting TTC obstruction did NOT occur, check alignment, inputs, and
73
wiring on expansion board.
CLOSE EYE/EDGE triggered, causing reversal
and preventing close or canceling TTC
74
OPEN EYE/EDGE triggered, causing reversal
75
or preventing opening
Close input (EYE/EDGE) communication fault Check inputs and communication method between
80
from other operator operators, either wired bus or radio. Ensure operator is
powered. May have to erase the wireless communication
Open input (EYE/EDGE) communication fault
81
and reprogram the two operators.
from other operator
Close input (EYE/EDGE) communication fault Check the connections between the main board and the
82
(expansion board) expansion board.
Open input (EYE/EDGE) communication fault
83
(expansion board)
Non-monitored device detected on the Make sure the attached edge is monitored. Non-
wireless safety system monitored contact closure devices are not supported. For
84
edges, check the proper orientation and connection of
the resistive end cap.
Force Reversal Look for obstruction, if no obstruction, check that the
mechanical assembly is engaged and free to move. Refer
91
to manual for Limit and Force Adjustment, and
Obstruction Test.
RPM / STALL Reversal Check for obstruction. If no obstruction, check the
operator cable wiring and that the operator arm is
93
engaged and free to move. Replace RPM assembly.
AC motor no start condition Motor failed to start. Check for an obstructed gate or
binding mechanism. Check start capacitor connections
95
and condition.
Current Sensor Fault A fault was detected on the current sensor. Make sure
the current sensor is connected to the main control
board. Check the current sensor harness for an open or
96
short. The operator will need a power cycle to resume
operation after correcting the fault. If the fault continues,
replace the power board.
99 Normal Operation No action required
CONTROL BOARD
ANTENNA
2 1 10 9 8 7 6 5 4 3 2 1 4 3 2 1 2 1 4 3 2 1
Red
Blue
Orange
Yellow
Green
Gray
Purple
Black
White
RESET
BUTTON
Red
PRODUCT ID
Black
SL585UL - Blue
SL595UL - Black
HORSE POWER ID
1/2 HP - White
1 HP - Brown
2 HP - Red
MOV ASSEMBLY
Connected across J1, J2, J3
1 2 3 4 5 6 7 8 9 3 2 1 2 1
J12
MOTOR
CURRENT White
TRANSFORMER
J14
(BLACK)
L1
12V J1
(WHITE)
J6 J11
L2
J2
Orange
12V
(PURPLE)
J8 J7
L3
J3 BRAKE
LINE IN
J10 J13
J4 J5
480V 240V/208V
575V
MOTOR
POWER BOARD
HARNESS
THREE PHASE
EXPANSION BOARD
PLUG-IN LOOP DETECTOR
Model LOOPDETLM
INTERRUPT LOOP
AUXILIARY
SHADOW LOOP
RELAY 1
EXIT LOOP
Jumper
N.C.
N.C.
COM
N.O.
ACCESSORY POWER
24VDC 0.5A Maximum
Connect external radios to DC
Blue
control board accessory power
Yellow
only.
Black
Red
ALARM
COM
120
240
N.C.
24 VAC
480
N.C.
575
PTC FUSE
TRANSFORMER
White
SOLENOID BRAKE
Blue
White
Brown
1
Purple
2
Purple
3
Brown
4
3 1
5
6
T3
7
8
Red
9
15 13
Purple
10
11
12
T2
Purple
T1
13
Blue
14
Yellow
15
These switches determine if the corresponding
photoelectric sensor or edge sensor will function
for the OPEN or CLOSE cycle.
WIRELESS EDGE KIT Model LMWEKITU
PHOTOELECTRIC SENSORS
PHOTOELECTRIC SENSORS
or EDGE SENSORS
SINGLE BUTTON CONTROL STATION
3-BUTTON CONTROL
STATION
N.C.
Jumper
These switches control how the Auxiliary Relays will function.
AUXILIARY SWITCH SETTINGS
RELAY 2
1 2 3 RELAY 1
OFF OFF OFF Relay always off Relay always off
OFF OFF ON Energizes at open limit Energizes at open limit
OFF ON OFF Energizes when not at Energizes when not at
close limit close limit
OFF ON ON Energizes when motor is on Energizes when motor is on
Energizes 3 seconds prior Energizes 3 seconds prior
ON OFF OFF
and during gate motion and during gate motion
ON ON OFF Not used Not used
ON OFF ON Energizes when gate is Energizes when gate is
tampered with tampered with
ON ON ON LEDs will blink cycle count Not used
575V THREE PHASE WIRING DIAGRAM
3-BUTTON CONTROL STATION
INTERRUPT LOOP
or
FIRE
PHOTOELECTRIC SENSORS
DEPARTMENT
for CLOSE cycle
ACCESS CONTROL
DEVICE
EXIT LOOP
OR
SHADOW LOOP
Shielded Twisted Pair Cable
(Primary/Secondary link to other
gate operator) Ground the shield of
the cable to the chassis ground of
each operator.
SOLENOID LOCK
(Optional)
OR
Not Provided
OPTIONAL ACCESSORY
WIRING
EXIT
ACCESSORY POWER
24VAC 2.2 AMPS MAX
Yellow
POWER BOARD
Blue
Three Phase
J12
MOTOR
CURRENT
J14
(BLACK)
L1
12V J1
HEATER
(WHITE)
L2
J2
12V (PURPLE)
L3
J3
LINE IN
J4
480V
Red
Black
Earth Ground Rod
MOTOR
Limit Switch Wiring
CONTROL BOARD
RPM & LIMITS ALA
SET
9 8 7 6 5 4 3 2 1
Limit Switch
Black
Red
4
3
Black
2
Green
1
RED/GREEN
Red light wired to AUX RELAY 1.
AUX RELAY 1 SWITCHES
GATE STATE
1 OFF 2 OFF
Red light OFF*
CLOSED
RELAY 2
OPENING Red light ON/FLASH
Red light OFF
OPEN
CLOSING Red light ON/FLASH
Defined Mid Stop
n/a
Undefined Mid
Red light ON
Stop
Timer more than
Red light OFF
5 seconds
Timer less than
Red light ON/FLASH
5 seconds
* For red light ON when gate is closed, set switch 1 on AUX RELAY 1 to ON
Models SL585UL and SL595UL
EDGE SENSOR
for CLOSE cycle
PHOTOELECTRIC
EDGE SENSOR
SENSORS
for OPEN cycle
OR
MAGLOCK
(Optional)
Not Provided
Power Wiring
TRANSFORMER
NOTE:The switch is located in the
J6 J11
electrical box for Model SL595.
J8 J7
BRAKE
J10
J5
240V/208V
575V
Attach
to metal
chassis
Green
JUNCTION BOX
INCOMING POWER
OPEN
CLOSE
Limit Switch
Blue
NC
NC
NO NO
Black
C
C
Yellow
4
RPM BOARD
3
2
1
LIGHT FUNCTIONALITY
Green light wired to AUX RELAY 2.
AUX RELAY 2 SWITCHES
3 OFF 1 ON 2 ON 3 ON
Green light OFF
Green light OFF
Green light ON
Green light OFF
n/a
Green light OFF
Green light ON
Green light OFF
