I Introduction

●This service manual is for the following product.
Paper Cutter PC-P430
●Prior consent
This service manual is intended for use when repairing and maintaining this
machine to keep it in top working condition. In order for you to safely perform
repair and maintenance work on this machine, please make sure that you fully
read and understand all of the notes related to safety that are written throughout
this service manual.
- Horizon International, INC. cannot accept responsibility for any loss, damage,
or injury as a result of unauthorized modification, misuse, or use outside
the machine's specifications, or any unsuitable or inadequate maintenance
performed by you or by authorized service personnel.
- Horizon International, INC. is continuously working to improve the design
and performance of all of its products. Consequently, the contents of this
service manual may be changed at any time in the future without prior notice.
Furthermore, Horizon International, INC. bears no additional liability for any
added contents.
- All rights with regards to copyrights are reserved. The copying or distribution
of any part or whole of this manual is strictly prohibited unless prior written
permission is obtained directly from Horizon International, INC.
●Directions are described as followings in this manual.
Left
Front
When you print this manual, use the newest Adobe Reader.
●Safety Precautions
●The meanings of symbols are following.
Rear
Right
1
- In order to perform repair or maintenance work safely on this machine, thoroughly
read all of the warnings and cautions related to safety that are written in this
service manual BEFORE commencing any operation. Failing to heed the safety
precautions in this manual may lead to accidents resulting in injury or death.
- The maintenance procedures and safety precautions described in this service
manual are only effective if the repair/maintenance procedures specified for this
machine are followed.
- Precautions that if not followed correctly may lead to accidents resulting in injury
WARNING
or death are indicated by this
- Precautions that if not followed correctly may lead to accidents resulting in
machine damage or malfunctions are indicated by this
- It is impossible for Horizon International, INC. to prevent all possible dangers
related to this product and its use. Therefore, the precautions shown in this
service manual and warning labels displayed on the product do not completely
warn against all possible dangers.
- Some of the diagrams in this service manual are drawn with covers removed to
describe the details or internal sections of the machine.
This will help you to avoid an incorrect operation which may cause
Important
problems with the machine, or make it necessary to go back to a
previous step.
Note
This indicates a helpful hint.
Additional
This indicates additional information which will help you to operate
Information
the machine efficiently.
This explains functional limitations and restrictions on the
Attention
operation of the machine.
Edited and Published by Horizon International, Inc.
140927/PC-P430/00E/HN/KJ US504013-00(001)
heading.
CAUTION
heading.
