- Page 1 CMOS 4 - BIT SINGLE CHIP MICROCOMPUTER Manual S5U1C63000H6 (S1C63 Family In-Circuit Emulator)
- Page 2 Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as, medical products.
- Page 3 Configuration of product number Devices 63158 0A01 Packing specifications 00 : Besides tape & reel 0A : TCP BL 2 directions 0B : Tape & reel BACK 0C : TCP BR 2 directions 0D : TCP BT 2 directions 0E : TCP BD 2 directions 0F : Tape &...
-
Page 4: Table Of Contents
3.3 Connection with Host Computer ..................5 3.4 Installing Peripheral Circuit Board (S5U1C63xxxP) ............6 4 Getting Started ......................7 5 Operations and Functions of the S5U1C63000H6 ............8 5.1 Outline of Operation ......................8 5.2 Break Function ........................9 5.3 Monitoring Terminals ...................... -
Page 5: Introduction
1 InTRODUCTIOn 1 Introduction S5U1C63000H6 (S1C63 Family In-Circuit Emulator) is a hardware tool to effectively develop software for the S1C63 Family, 4-bit single chip microcomputers. In combination with a peripheral circuit board (S5U1C63xxxP), it provides the development environment of the software using a personal computer as a host computer, which re- quires Windows 2000/XP. -
Page 6: S5U1C63000H6 Package
2 S5U1C63000H6 Package 2.1 Components This package is in common with all models of the S1C63 Family. After unpacking the S5U1C63000H6 package, check to see that all of the following components are included. Figure 2.1.1 shows the package structure. (1) S5U1C63000H6 (main unit) ..............1 unit (2) USB cable.................... -
Page 7: Component Specifications
380 mm (W) × 260 mm (D) × 225 mm (H) Package Dimension Materials W carton, cardboard 2.3 Environmental Condition for Operation Table 2.3.1 shows the environmental conditions to operate S5U1C63000H6 that has to be used. Table 2.3.1 Environmental Conditions Items Specifications Remarks Operating temperature 5 to 40°C... -
Page 8: Specifications Of The Operation Panels
Turns the S5U1C63000H6 power on and off. 12 Rear panel DC12V DC input connector This connector is used to connect the DC cable of the AC adapter for S5U1C63000H6. Be sure to use the AC adapter included in this package. 13 Rear panel CB... -
Page 9: Connection
Figure 3.1.1 Connection of AC Line 3.2 DC Cable Connect the DC output cable of the AC adapter to the DC12V connector located at the S5U1C63000H6 rear panel. 3.3 Connecting with Host Computer Connect between the host computer and the S5U1C63000H6 using the USB cable included in this package. -
Page 10: Installing Peripheral Circuit Board (S5U1C63Xxxp)
(2), (3) Figure 3.4.1 Installing Peripheral Circuit Board (1) Unfasten the screws located on the left and right sides of the front panel of the S5U1C63000H6 by turning them counterclockwise then remove the front panel. (2) Insert the peripheral circuit board into the slot and push it... -
Page 11: Getting Started
Execute the target program from the debugger. When the target program starts running, the EMU LED (red) lights to indicate that the S5U1C63000H6 enters emulation mode. When the SLP or HALT instruction is ex- ecuted, the SLP/HLT LED (yellow) lights. -
Page 12: Operations And Functions Of The S5U1C63000H6
S1C63000 CPU. The memory enables the register value inside the S1C63000 CPU to be real timely recorded. The program execution is traced in the emulation mode and the traced information is analyzed by the S5U1C63000H6 control processor in the standby mode. -
Page 13: Break Function
5 OPERaTIOnS anD FUnCTIOnS OF THE S5U1C63000H6 5.2 Break Function (1) Forced break The debugger on the host computer can forced break the emulation. This function is useful when the program counter does not proceed by executing the SLP or HALT instruction in a single step process. -
Page 14: Display During Execution And During Break
5.4 Display During Execution and During Break The S5U1C63000H6 control processor monitors the execution status of the S1C63000 CPU while the target pro- gram is running. It displays the S1C63000 CPU’s execution status in every 500 ms when the on-the-fly display mode is specified. -
Page 15: Target Interrupt And Break
5 OPERaTIOnS anD FUnCTIOnS OF THE S5U1C63000H6 5.6 Target Interrupt and Break When an interrupt in the target program and a break are simultaneously occurred, the target interrupt is prioritized. The break occurs after completing the stack operation of the interrupt. The program counter at the break shows the top address of the interrupt handler routine. -
Page 16: Trace Mode
CV or CVC command. 5.11 Measurement of Execution Time The S5U1C63000H6 has a function to measure the time from start to break of the target program or to count the number of bus cycles. This function is set by the MD command. -
Page 17: Self-Diagnostic Function
Tests if a break occurs normally by executing a run emulation for a few steps of instructions on the emula- tion memory. When the debugger is started up after the S5U1C63000H6 is turned on with the self-diagnostic mode enabled, the S5U1C63000H6 performs diagnosis for about one minute. After that, the debugger enters command waiting status. - Page 18 5 OPERaTIOnS anD FUnCTIOnS OF THE S5U1C63000H6 (3) Interrupt at single step operation Interrupts during single step operation can be enabled or disable using the MD command. Each operation is as follows. When interrupt is enabled If an interrupt request is generated while the target program is single stepping by the S or N command, the interrupt processing will be started when an instruction is executed, and the execution stops after fetching the vector address of the interrupt.
- Page 19 Figure 5.13.2 Example of Register Break The S5U1C63000H6 judges the register data at the points indicated with a “↑.” It judges that the A register is “5” at the point of <2>, and the register break condition is met at the same time. However, the S1C63000 CPU is executing the following “ld %a, 6”...
-
Page 20: Lcd Driver
(3) Drive capability of SEG and COM terminals The output drive capability of the SEG and COM terminals in the S5U1C63000H6 is different from that of the actual IC. The S5U1C6300H6 cannot be used for evaluating electrical characteristics. The system should be de- signed in consideration of the electrical characteristics described in the technical manual of each model. - Page 21 Cannot be connected SEG34 Cannot be connected SEG35 Cannot be connected SEG36 Cannot be connected SEG37 Cannot be connected SEG38 Cannot be connected SEG39 Cannot be connected SEG40 Cannot be connected SEG41 Cannot be connected EPSOn S5U1C63000H6 ManUal (S1C63 Family In-Circuit Emulator)
-
Page 22: Notes On Use
(2) Turning power on and off When turning the S5U1C63000H6 off and on again, wait at least 10 seconds before turning on. If power is turned on without an interval, the power-on-reset sequence may not be executed normally and the result is that the S5U1C63000H6 fails to function normally, or the circuit breaker on the S5U1C63000H6 may trip. -
Page 23: Maintenance And Warranty
When an error is detected in the diagnosis, the error message is displayed at the point <1> instead of “done.” If an error message is displayed, stop using the S5U1C63000H6, as it may have a hardware failure. This self-diagnostic test takes about one minute for its precise inspection until it is completed and the S5U1C63000H6 is ready to accept commands. -
Page 24: Troubleshooting
