INSTRUCTION MANUAL
VHF MOBILE TRANSCEIVER
iF9511S
iF9511T
This device complies with Part 15 of the FCC Rules.
Operation is subject to the condition that this device does
not cause harmful interference.

Advertisement

Table of Contents
loading

Related Manuals for Icom IC-F9511S

Summary of Contents for Icom IC-F9511S

  • Page 1 INSTRUCTION MANUAL VHF MOBILE TRANSCEIVER iF9511S iF9511T This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

  • Page 2: Explicit Definitions

    This NEVER instruction manual contains important operating instructions connect the transceiver to a power source of for the IC-F9511S/T VHF MOBILE TRANSCEIVERS. more than 16 V DC such as a 24 V battery. This connection will ruin the transceiver. NEVER...

  • Page 3: About Apco Project 25

    # 5 , 5 8 1 , 6 5 6 , # 5 , 5 1 7 , 5 1 1 , # 5 , 4 9 1 , 7 7 2 , # 5 , 2 4 7 , 5 7 9 , operating continuously for long periods. #5,226,084, #5,195,166. For U.S.A. only CAUTION: Changes or modifications to this transceiver, not ex- pressly approved by Icom Inc., could void your authority to operate this transceiver under FCC regulations.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT ................i EXPLICIT DEFINITIONS ............i PRECAUTIONS ..............i ABOUT APCO PROJECT 25 ..........ii TABLE OF CONTENTS ............iii 1 PANEL DESCRIPTION ..........1–8 n Front panel ..............1 n Function display ............2 n Programmable function keys ........3 2 BASIC OPERATION ..........9–13 n Turning power ON ............9 n Channel selection ............9...

  • Page 5: Panel Description

    • Input the Individual ID code for digital operation. e DIAL or UP/DOWN KEYS t BUSY INDICATOR • IC-F9511S: DIAL L ights green while receiving a signal, or when the squelch Rotate to select an operating channel, etc. is open.

  • Page 6: Function Display

    PANEL DESCRIPTION n Function display y POWER SWITCH [POWER] Push to turn the power ON and OFF. • The following functions are available at power ON as options: - Automatic scan start - Password prompt - Set mode 1 3 6 . 1 N a r u TRANSMIT INDICATOR L ights red while transmitting.

  • Page 7: Programmable Function Keys

    [DOWN], [P0], [P1], [P2], [P3] and [P4] programmable func- according to the pre-programming. tion keys. Consult your Icom dealer or system operator for details con- u CALL CODE MEMORY INDICATOR cerning your transceivers programming. A ppears when the call code memory is selected.
  • Page 8 PANEL DESCRIPTION ZONE KEY SCAN B START/STOP KEY Push this key, then select the desired zone using [CH Up]/ ➥ Push to start and cancel scanning operation. In case of [CH Down]. transmission during scan, pauses scanning. Scanning re- sumes after a specified time period has passed after the What is “zone”?—The desired channels are assigned transmission is finished.
  • Page 9 PANEL DESCRIPTION PUBLIC ADDRESS KEY HIGH/LOW KEY While in the hailer mode, push this key for the audio output Push to select the transmit output power temporarily or per- via the hailer amplifier. Ask your dealer for details. manently, depending on the pre-setting. While in the normal mode, the audio output via the cable •...
  • Page 10 PANEL DESCRIPTION RE-DIAL KEY TX CODE CHANNEL SELECT KEY Push to transmit the last-transmitted DTMF code. Push to enter the ID code channel selection mode directly. Then set the desired channel using [CH Up]/[CH Down]. CALL KEYS (p. 11) Push to transmit a 2-tone ID code. •...
  • Page 11 PANEL DESCRIPTION TONE/NAC CH SELECT KEY SCRAMBLER/ENCRYPTION KEY (LMR (P25 Conventional) operation only) (LMR (P25 Conventional) operation only) ➥ While in the analog mode operation, push to select the ➥ While in the analog mode operation, push to toggle the continuous tone channel using [CH Up] or [CH Down] to voice scrambler function ON and OFF.
  • Page 12 PANEL DESCRIPTION D For Digital mode operation only INDIVIDUAL KEY ➥ Push to enter the individual ID code selection mode direct- ly. Then select the desired individual ID code using [CH Up]/ [CH Down]. (p. 12) ➥ Push to stop the beep emission when receiving a matched individual ID code.

  • Page 13: Basic Operation

    BASIC OPERATION n Turning power ON n Channel selection q Push [ ] to turn the power ON. Several types of channel selections are available. Methods w If the transceiver is programmed for a start up password, may differ according to your system set up. input the digit codes as directed by your dealer.

  • Page 14: Call Procedure

    BASIC OPERATION n Call procedure n Receiving and transmitting Receiving: When your system employs tone signaling (excluding CTCSS and DTCS), the call pro cedure may be necessary prior to q Push [ ] to turn the power ON. voice transmission. The tone signalling employed may be a se- w Push [CH Up] or [CH Down], or rotate [CH Up/Down] to lective calling system which allows you to call specific station(s) select a channel, in sequence.
  • Page 15 BASIC OPERATION D Transmitting notes D TX code channel selection • Transmit inhibit function If the transceiver has [TX Code CH Select] assigned to it, The transceiver has several inhibit functions which restrict the indication can be toggled between the operating channel transmission under the following conditions: number (or name) and TX code channel number (or name).
  • Page 16 BASIC OPERATION D Individual ID code selection D DTMF transmission (Digital mode operation only) If the transceiver has [DTMF Autodial] assigned to it, the If the transceiver has [Individual] assigned to it, the indication automatic DTMF transmission function is available. Up to 8 can be toggled between the operating channel number (or DTMF channels are available.

  • Page 17: User Set Mode

    BASIC OPERATION n User set mode e Push [ ] again to exit set mode. User set mode is accessed with [User Set Mode] and allows you to set seldom-changed settings. In this case you can “customize” the transceiver operation to suit your prefer- ences and operating style.

  • Page 18: Connection And Maintenance

    SPEAKER JACK Supplied speaker SP-22 placement. Connect a 4–8 ø (IC-F9511T only. IC-F9511S have external speaker. a built-in speaker.) y DC POWER RECEPTACLE Connects to a 12 V DC battery. Pay atten- tion to polarities. NEVER connect to a 24 V battery.

  • Page 19: Supplied Accessories

    CONNECTION AND MAINTENANCE n Supplied Accessories • Function name stickers Microphone Microphone hanger Microphone There are no names on the programmable function keys and screw set hanger cable since the functions can be freely assigned to these keys. Attach the supplied function name stickers as below to the appropriate keys for easy recognition of that key’s assigned function.

  • Page 20: Mounting The Transceiver

    CONNECTION AND MAINTENANCE n Mounting the transceiver n Antenna The universal mounting bracket supplied with your trans- A key element in the performance of any communication ceiver allows overhead mounting. system is an antenna. Contact your dealer about antennas • Mount the transceiver securely with the 4 supplied screws and the best places to mount them.

  • Page 21: Options

    OPTIONS • RMK-2 separation kit OPC-607/OPC-608/OPC-609 separation cable Allows you to install the transceiver main unit separately from the front panel for operating convenience. • SP-5/SP-10/SP-22 external speakers Input impedance : 4 Ω Max. input power : 5 W SP-5 : Large speaker for good audio quality.

  • Page 22: Safety Training Information

    48 centimeters separation distance. In order to During transmissions, your Icom radio generates RF energy that can ensure this distance is met, the installation of the antenna must be possibly cause interference with other devices or systems.
  • Page 23 MEMO...
  • Page 24 A-6625?-1US Printed in Japan © 2007 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
