Technical specifications
Table 15 RF382R technical specifications
Inductive interface to the MDS
Transmission frequency
Transmit power
Supported transponders (reader air interface)
Antenna
HOST interface
Baud rate
Read distances of the reader
Minimum distance between two RF382R Scanmode readers 200 mm
Cable length reader - HOST
Maximum data transmission rate
transponder (tag) - reader (reading)
Functions
Power supply
Display elements
Plug connector
Housing
● Dimensions (in mm)
● Color
● Material
Mounting
Ambient temperature
● Operation
● Transport and storage
Degree of protection to EN 60529
Shock to EN 60721-3-7 Class 7 M2
Vibration to EN 60721-3-7 Class 7 M2
Weight
MTBF (Mean Time Between Failures)
Approvals
Current consumption
Max. power consumption (DC input)
10
13.56 MHz
Approx. 0.7 W
Transponder to ISO 15693
Integrated, horseshoe shape
RS232
38400 baud
See Chapter Field data for MDS and SLG (Page 6)
max. 30 m
600 byte/s
Read transponder serial number
24 V DC
2-color LED
(operating voltage, presence, error)
M12 (8-pin)
● 160 x 80 x 41 (without M12 device connector)
● Anthracite
● Plastic PA 12
4 x M5 screws
● -25 °C to +70 °C
● -40 °C to +85 °C
IP67
50g
20g
approx. 550 g
1 x 10
h
6
Radio to R&TTE guidelines EN 300 330,
EN 301489, CE
typ. 140 mA
3.5 W
SIMATIC RF382R Scanmode
J31069-D0214-U001-A1-7618, 10/2009
